Altronix AL400ULX Installation Manual page 8

Enclosure Dimensions (BC400):
AL400ULXX, AL400ULXXR, AL400ULXPD4, AL400ULXPD4CB,
AL400ULXPD8, AL400ULXPD8CB AL400ULXPD16, AL400ULXPD16CB
15.5" x 12" x 4.5" (393.7mm x 304.8mm x 114.3mm)
4.5"
(114.3mm)
1.25"
(31.75mm)
1.5"
(38.1mm)
2.0"
(50.8mm)
2.0"
(50.8mm)
5.0"
(127.0mm)
1.25"
(31.75mm)
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056
web site: www.altronix.com, e-mail: info@altronix.com. Lifetime Warranty, Made in U.S.A.
IIAL400ULX series
- 8 -
1.5" 4.615"
(38.1mm) (117.22mm)
1.1"
(27.94mm)
0.91"
(23.114mm)
1.5" 4.615"
(38.1mm) (117.22mm)
4.615"
(117.22mm) (38.1mm)
12.23"
(310.64mm)
4.615"
(117.22mm) (38.1mm)
E18P
1.5"
1.75"
(44.45mm)
1.375"
(34.925mm)
1.125"
(28.575mm)
(114.3mm)
1.1"
(27.94mm)
0.91"
(23.114mm)
15.5"
(393.7mm)
0.79"
1.1"
(20.06mm)
(27.94mm)
1.75"
(44.45mm)
1.5"
4.5"
1.25"
(31.75mm)
1.5"
(38.1mm)
5.0"
(127.0mm)
1.25"
(31.75mm)
MEMBER
AL400ULX series
