Altronix AL400ULX Installation Manual page 7

Enclosure Dimensions (BC300):
AL400ULX, AL400ULXR, AL400ULPD4, AL400ULPD4CB, AL400ULPD8, AL400ULPD8CB
13.5" x 13" x 3.25" (342.9mm x 330.2mm x 82.55mm)
1.20"
(31mm)
1.40"
(36mm)
5.10"
(130mm)
(330mm)
5.10"
(130mm)
3.25"
(83mm)
1.0"
(25mm)
AL400ULX series
1.40" 4.85"
(36mm) (123mm)
0.75"
(19mm)
13.0"
1.0"
(25mm)
4.85"
(123mm)
12.5"
(318mm)
11.0"
(279mm)
10.5"
(267mm)
1.40"
(36mm)
1.20"
(31mm)
3.25"
(83mm)
0.75"
(31mm)
(19mm)
0.9375"
(24mm)
0.9375"
(24mm)
3.25"
(83mm)
3.25"
(83mm)
1.0"
(25mm)
1.0"
(25mm)
1.20"
1.40"
(36mm)
5.10"
(130mm)
6.5625"
(167mm)
- 7 -
