Thermography System VarioCAM
9. Introduction
pushing the button without exiting the dialogue. The current line can be deleted within the dialogue by
using the button; the dialogue is closed by pushing the
Along with the option of deleting individual ROIs in the respective editor by using the
created ROIs can be deleted simultaneously using the corresponding dialogue to be confirmed:
Fig. 121 Delete all

9.3.2.3 Rectangle R

A rectangle selected in the "Editor" sub-menu in the "New" menu item is initially displayed as a square in
the center of the image. Height and width can be changed using the joystick by changing the position of
the marked spot (see Fig. 123 and Fig. 124). If the position of the rectangle is to be changed, please
initially push the Enter button
moved using the joystick without any changes to its shape (see Fig. 125).
Fig. 123 Rectangle – change size

9.3.2.4 Ellipse E*

The measuring object "Ellipse" selected in the "Editor" sub-menu in the "New" menu item is initially
displayed as a circle in the center of the image. The shape can also be changed by using the joystick
(red mark on line, see Fig. 126), the position can be changed after pushing the Enter button (red mark in
the center of the circle, see Fig. 127). Another ellipse can be created using the
Fig. 126 Ellipse – change size
User Manual
® HD
Fig. 122 Dialog to confirm "Delete all ROIs"
. The rectangle is then highlighted by a red dot in its center and can be
Fig. 124 Rectangle – change size
Fig. 127 Ellipse – move
© InfraTec GmbH 2016
button.
Fig. 125 Rectangle – move
button.
Fig. 128 Ellipse – change size
button, all
59
