Thermography System VarioCAM
9. Introduction
Please note that a new sub-directory is created after every restart of the thermography system and
subsequent data storage, as well as for every series measurement*, regardless of the contents of
directories already created beforehand. If additional data (VIS, audio, screenshot) is saved as additional
files, the number of possible thermal image files in one directory is reduced accordingly*.

9.2.1.2 Individual directory names

Fig. 81 Input of an individual directory name
If directory names should be applied regardless of the date, the check in the dialog field "automatic" has
to be removed and the desired directory name can be edited. For this purpose at least four letters or
special characters are required. The directory name is limited to 15 characters. In addition to the user
specified directory name, always two letters are added analogueue for automatic directory creation e.g.
AA. AB...AZ, BA, BB...BZ...ZZ. In this way 26x26 directory names with the same root name can be
created.
Individual directory names have only four characters, consisting of the indicators AA...ZZ of each
directory name and serial numbers from 00...99:
Fig. 82 Directory files with individual directory names
If more individual directory names are assigned to one memory card, identical file names can arise. It is
therefore recommended to keep the directory structure in the transmission of data from the memory card
to the evaluation computer.
9.2.2

Menu item "Load"

9.2.2.1 Loading individual files from file list or gallery

Fig. 83 Menu item "Load "
The "Load" menu item can be used in order to load thermograms and photos already saved to the
SDHC-card and to display these on the display and/or the viewfinder. The images to be displayed can be
selected using the sub-menu items "Single file" or "Gallery".
If the "Single file" sub-menu item is selected, the sub-directories and their contents contained on the
SDHC-card are initially displayed as lists. In order to navigate between directories and files,
User Manual
® HD
© InfraTec GmbH 2016
is used;
47
