and in order to navigate within the directory lists and file lists.
using the Enter button
navigating to the left. A file, in turn, is selected by using the Enter button
file list, the preview image of the highlighted thermal image is displayed; and on the right bottom, a photo
is displayed (from IRB or *.jpg file). If the thermal image saved to the IRB contains further data, this is
indicated by the following letters in the left upper corner of the preview image:
■ V: photo, digital image (Visible)
■ A: audio file
■ S: image sequence, serial file
Fig. 84: Menu item "Load". dropped down
"Load" sub-menu
The button can be used in order to highlight files and directories; and the
delete files and directories. In order to avoid any accidental loss of data, the process of deleting files must
be confirmed in a dialogue:
Fig. 86 Dialog "Delete file"
The file selected from the file list (highlighted blue) is displayed (large) by using the Enter button
When the image is shown in its enlarged size, the right/left buttons
and/or previous image in the file list. If a photo is saved in the IRB, this photo is shown as a miniature
version to the left of the thermal image. The
image and photo. A voice comment contained in the IRB can be played by using the
loaded image can be deleted by using the
In order to exit the full screen display, use the button
images can be displayed again.
48
or navigating to the right; the file list of a sub-directory can be closed by
Fig. 85: Load single file: selection of thermogram and
button can be used to toggle the display between thermal
button.
