Heartrate Control (E3 View Monitor Option) - CYBEX 525C Owner's Manual

9 - Heartrate Control (E3 View Monitor Option)

The Heartrate Control (HRC) workout requires a Polar® compatible heart rate transmitter belt (not
included).
The Heartrate Control (HRC) workout will attempt to bring the user to their target heartrate in 3-5
minutes, then keep them there for the duration of the body of the workout. A Cool Down is built in to
the end of the workout. HRC is run in Constant Power and thus defines watts.
The user selects a target heartrate, which defaults to 75% of max (max is 220-age). Limits should be
set to not allow a Target HR (THR) less than 60% of max or more than 94% of max.
The protocol starts in Stage II, with the entry point based on Target HR.
80 – 120 BPM = Step 6
•
121-127 BPM = Step 8
•
128-134 BPM = Step 10
•
135-up BPM = Step 12
•
A running pulse-to-pulse BPM value is continuously measured.
Every 15 seconds the user's pulse rate is sampled and a prediction function is evaluated (decision.)
This is subtracted from the target heartrate to form an error value which is scaled and added to the
current load value. There is a maximum rate of change of 15 steps per decision.
The workload equates to the speed of the workout. A chart of Step and Watts has been created. It has
four defined stages:
Stage 1 ramps the load from Step 1 to Step 5.
•
Stage 2 ramps the load from Step 6 through Step 18.
•
Stage 3 ramps the load from Step 19 through Step 39.
•
Stage 4 ramps the load from Step 40 through Step 100.
•
The user has limited control over the load in that the user's selections are not permanent. At the
next decision, a new load can be chosen by the software as described above to override any user
modifications.
If the user presses the UP
Utilize the Target Heartrate Setup selection screen and exit back to the workout in progress, making
the change to their target heartrate real-time.
Cybex Owner's Manual
or DOWN keys, they can modify their Target Heartrate real-time.
68
