CYBEX 525C Owner's Manual page 16

Install console assembly to base assembly.
1. Hand thread two mounting screws into the base assembly.
1
2
3
The console assembly will need to be supported during steps 2 through 5.
2. Insert the display cable and optional A/V cable through the frame to the left side. Do not pinch
or damage the cables during assembly.
3. Place the console assembly in the correct position on the base assembly by sliding into
position onto the two mounting screws.
4. Hand thread the other two screws.
1
2
3
5. Securely fasten the four screws with a 1/2" socket wrench.
Cybex Owner's Manual
Item Description
1
2
3
4
4
5
5
1
2
3
16
Console assembly
13 Screws (2)
Base assembly
Optional A/V cable
Display cable
Item Description
Console assembly
13 Screws (4)
Base assembly
