Dynacode series
Insertion and removal
of Compact Flash card
File and/or
directory name
10.15
8

Compact Flash card

This print module series are equipped at the rear with a slot for
Compact Flash card. By means of this memory card you can
permanently save via interface graphics, text, layout data or
information from database.
In case of a malfunction of your original memory card we
recommend a copy of your most important data. Please use a
commercial Compact Flash reader for PC.
Insert Compact Flash card with contact side forwards to the slot that
was planned for it.
In order to prevent wrong insertion of cards, both sides of Compact
Flash cards have different guiding.
A small part of Compact Flash card is visible at the support at the
direct print module rear, so you can remove the card easily with hand.
Please note that we support only Compact Flash cards of type
1 at the moment. The use of micro drives is not intended at
this time.
The direct print module handles your Compact Flash card as a DOS
compatible file system.
After formatting Compact Flash card the STANDARD directory is
automatically available. After switching on the direct print module or
inserting Compact Flash card, this directory is the current one. Main
and sub-directories are indicated in <> (e.g. <Directory>).
The maximum length of directory is 254 characters. It is not
allowed to use the following characters neither in file nor in
directory names:
: \ " * / < > ? |
Press key to indicate the saved layouts onto the Compact Flash
card.
Press key to enter the Compact Flash card menu.
Press key to arrive at the next menu item.
Press key to return to the previous menu item.
Press key to select a menu and to confirm a query.
Press key and to browse the contents of the current directory.
Press key and to change to the indicated directory.
Before first use of Compact Flash card in your direct print
module we recommend to format the card in your direct print
module.
