1.4 Continuous mode

Please note that the material has sufficient adhesion at the pressure
transducer roll or encoder roll to permit the exact speed by the
encoder.
It is only possible to print when respecting the operating conditions,
i.e. the speed has to be observed.
Figure 3
After starting a print order the printhead moves against the print
medium. The feed of material is registered by the encoder and then
evaluated. The printhead is in start position as long as the printing
onto the moving material is finished and then it moves back to its
home position.
In case the encoder is connected to the counter-pressure roll
or the encoder roll you have to observe that the material has
sufficient adhesion at the pressure roll or encoder roll to
guarantee an exact speed by the encoder.
Figure 4
