PCI-DAC6702 and PCI-DAC6703 User's Guide
Pin Signal Name
1 AGND
2 VCH0
3 AGND0
4 VCH1
5 AGND1
6 VCH2
7 AGND2
8 VCH3
9 AGND3
10 VCH4
11 AGND4
12 VCH5
13 AGND5
14 VCH6
15 AGND6
16 VCH7
17 AGND7
18 AGND
19 VCH8
20 AGND8
21 VCH9
22 AGND9
23 VCH10
24 AGND10
25 VCH11
26 AGND11
27 VCH12
28 AGND12
29 VCH13
30 AGND13
31 VCH14
32 AGND14
33 VCH15
34 AGND15
35 n/c
36 n/c
37 n/c
38 n/c
39 PC 5V
40 DIO0
41 DIO1
42 DIO2
43 DIO3
44 n/c
45 DIO4
46 DIO5
47 DIO6
48 DIO7
49 n/c
50 GND
Note: DIO[7:0] signals are provided in two locations in order to provide flexibility for applications which
use the C100HD50-x ribbon cable.
Table 5-11. PCI-DAC6703 pin out
Pin
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
5-4
Specifications
Signal Name
AGND
n/c
AGND
n/c
AGND
n/c
AGND
n/c
AGND
n/c
AGND
n/c
AGND
n/c
AGND
n/c
AGND
AGND
n/c
AGND
n/c
AGND
n/c
AGND
n/c
AGND
n/c
AGND
n/c
AGND
n/c
AGND
n/c
AGND
DIO0
DIO1
DIO2
DIO3
DIO4
DIO5
DIO6
DIO7
n/c
n/c
n/c
GND
n/c
n/c
n/c
GND
