PCI-DAC6702 and PCI-DAC6703 User's Guide
Pinout – main I/O connector
The main I/O connector pinouts for each board are shown in the following tables. Note that the DIO[7:0]
signals are provided in two locations in order to provide flexibility for applications which use the
C100HD50-x ribbon cable.
Signal name
Table 2-2. PCI-DAC6703 connector pin out
Pin
AGND 1 • •
VCH0 2 • •
• •
AGND0 3
VCH1 4 • •
AGND1 5 • •
VCH2 6 • •
• •
AGND2 7
VCH3 8 • •
AGND3 9 • •
VCH4 10 • •
• •
AGND4 11
VCH5 12 • •
AGND5 13 • •
VCH6 14 • •
• •
AGND6 15
VCH7 16 • •
AGND7 17 • •
AGND 18 • •
• •
VCH8 19
AGND8 20 • •
VCH9 21 • •
AGND9 22 • •
• •
VCH10 23
AGND10 24 • •
VCH11 25 • •
• •
AGND11 26
VCH12 27 • •
AGND12 28 • •
VCH13 29 • •
• •
AGND13 30
VCH14 31 • •
AGND14 32 • •
VCH15 33 • •
• •
AGND15 34
n/c 35 • •
n/c 36 • •
n/c 37 • •
• •
n/c 38
PC 5V 39 • •
DIO0 40 • •
DIO1 41 • •
• •
DIO2 42
DIO3 43 • •
n/c 44 • •
DIO4 45 • •
• •
DIO5 46
DIO6 47 • •
DIO7 48 • •
n/c 49 • •
• •
GND 50
↓
PCI slot
Pin Signal name
51 AGND
52 n/c
53 AGND
54 n/c
55 AGND
56 n/c
57 AGND
58 n/c
59 AGND
60 n/c
61 AGND
62 n/c
63 AGND
64 n/c
65 AGND
66 n/c
67 AGND
68 AGND
69 n/c
70 AGND
71 n/c
72 AGND
73 n/c
74 AGND
75 n/c
76 AGND
77 n/c
78 AGND
79 n/c
80 AGND
81 n/c
82 AGND
83 n/c
84 AGND
85 DIO0
86 DIO1
87 DIO2
88 DIO3
89 DIO4
90 DIO5
91 DIO6
92 DIO7
93 n/c
94 n/c
95 n/c
96 GND
97 n/c
98 n/c
99 n/c
100 GND
2-5
Installing the PCI-DAC6700 Series
