USB-3105 User's Guide
Humidity

Mechanical

Parameter
Dimensions (L × W × H)

Screw terminal connector

Parameter
Connector type
Wire gauge range
Pin Signal Name
1 VOUT0
2 NC
3 VOUT2
4 NC
5 AGND
6 VOUT4
7 NC
8 VOUT6
9 NC
10 AGND
11 VOUT8
12 NC
13 VOUT10
14 NC
15 AGND
16 VOUT12
17 NC
18 VOUT14
19 NC
20 AGND
21 DIO0
22 DIO1
23 DIO2
24 DIO3
25 DIO4
26 DIO5
27 DIO6
28 DIO7
0 to 90% non-condensing
Table 14. Mechanical specifications
Specification
127 × 89.9 × 35.6 mm (5.00 × 3.53 × 1.40 in.)
Table 15. Main connector specifications
Specification
Screw terminal
16 AWG to 30 AWG
Pin Signal Name
29 VOUT1
30 NC
31 VOUT3
32 NC
33 AGND
34 VOUT5
35 NC
36 VOUT7
37 NC
38 AGND
39 VOUT9
40 NC
41 VOUT11
42 NC
43 AGND
44 VOUT13
45 NC
46 VOUT15
47 NC
48 AGND
49 SYNCLD
50 DGND
51 NC
52 CTR
53 DGND
54 DIO CTL
55 DGND
56 +5V
18
Specifications
