LED Indicators

There are LEDs located on the front panel of the Hardened PoE injector to display the power
status and network status.
Each LED state and color has its own specific meaning as defined in the table below.
Table 2.1: Hardened Switch Converter LED Definition
LED Indicator Label
PWR
System Power
PoE
PoE Power
Giga
RJ-45
Link/ACT
Link/ACT
SFP

DIP-Switch

The front panel DIP-Switch is used to configure the SFP
operating speed. The default position is Mode 2, 1000M.
Table 2.2: Hardened Switch Converter DIP-Switch Definition
Status
Mode 1
Mode 2
33585 Rev. G
SI-IES-111D-LRT and -121D-LRT User Guide
Description
Off Power off
Solid Green Power on
Off No PoE power output
Solid Green PoE power output OK
Link to 1000M bps network
Solid Amber
Not connected to network or not working
Off
at speed of 1000M
Solid Green Connected to network
Blinking Green Networking is active
Off Not connected to network
Off No SFP connection detected
Solid Green When there is a secure SFP connection
When there is transmission or reception of
Blinking Green
data occurring at speed of 100/1000Mbps
Description
100M
1000M
