install two units with the same power type. The Factory Default is one power
module unit and one Fan Unit.
Power Slot B is installed a FAN unit
Power Slot A with AC Power Module
Rear Panel of the 16 Slots intelligent converter chassis
LED Indicators
All LED status indicators are located on the front panel of the modules. They
display real-time indication of system and operational status.
System Cabinet
CPU Panel
7
