Transition Networks SI-IES-111D-LRT and -121D-LRT User Guide
To remove the LC connector from the transceiver, follow the steps below:
1. Press the upper side of the LC connector from the transceiver and pull it out to release.
Figure 2.11: Remove LC connector
2. Push down on the metal loop and pull the transceiver using the metal loop.
Figure 2.12: Pull out from the SFP module
33585 Rev. G https://www.transition.com/ Page 14 of 24
