B
B-8
Table B-4 Backplane Connector (Connector J0200) (2 of 2)
Section 1 Section 2
A33 SY1DP_L<5> B33
A34 SY1D_L<49> B34
A35 VTT B35
A36 SY1D_L<53> B36
A37 VTT B37
A38 SY1D_L<56> B38
A39 SY1D_L<59> B39
A40 VTT B40
A41 SY1D_L<63> B41
A42 VTT B42
A43 STS1R0_L<2> B43
A44 VTT B44
A45 SY1GT_L B45
A46 VTT B46
A47 SY1GT0_L B47
A48 VTT B48
A49 BDID<0> B49
A50 Fan_Fail B50
A51 SyPwrRst_L B51
A52 SYSRST_L B52
A53 TPOP B53
A54 SCRST B54
A55 SCSEL B55
A56 SCSD<2> B56
A57 SCSD<5> B57
A58 SCSD<7> B58
A59 VDD B59
A60 VDD B60
SPARCserver 1000 System Board Manual—October 1994
Section 3
GND C33 SY1D_L<48>
GND C34 GND
SY1D_L<51> C35 SY1D_L<52>
GND C36 GND
SY1D_L<55> C37 SY1DP_L<6>
GND C38 GND
GND C39 SY1D_L<58>
SY1D_L<61> C40 GND
GND C41 SY1D_L<62>
SY1DQ_L<0> C42 GND
GND C43 SY1RQ_L<1>
SY1RQS_L C44 GND
GND C45 SY1RQP_L
SY1GTT_L<1> C46 GND
GND C47 SY1GTT_L<2>
SY1GTP_L C48 GND
BDID<1> C49 SYSECT
GND C50 AC_Fail
TXDA C51 GND
GND C52 SYRST_L
TPOM C53 TPIP
GND C54 GND
SCIO C55 SCSD<1>
GND C56 SCSD<3>
SCSD<6> C57 GND
SCDP C58 SCMSG
SCATN C59 SCBSY
SCREQ C60 SCCD
Section 4
D33 VCC
D34 SY1D_L<50>
D35 VCC
D36 SY1D_L<54>
D37 VCC
D38 SY1D_L<57>
D39 VCC
D40 SY1D_L<60>
D41 VCC
D42 SY1DP_L<7>
D43 VCC
D44 SY1RQO_L
D45 VCC
D46 SY1GTT_L<0>
D47 VCC
D48 SY1GTS_L
D49 VCC
D50 DiagMode_L
D51 VCC
D52 TPIM
D53 VCC
D54 SCSD<0>
D55 VCC
D56 SCSD<4>
D57 VCC
D58 VCC
D59 SCACK
D60 TERMPWR
