B.1 Connector Locations

Connector Pinouts

This appendix lists pinouts of connectors on the system board:
•
Keyboard and mouse connector
•
Serial port connectors A and B
•
SBus slots 1, 2, and 3
•
Backplane connector
•
SuperSPARC module slots A and B
Figure B-1 shows the backpanel and the top of the system board. The
backplane has diagnostic LEDs, cable connectors, and SBus card openings. The
top of the board has connectors for three SBus cards, two SuperSPARC
modules, and 16 SIMMs.
