Figure 2-2
Removing the System Board
10. Holding the board by both of the extraction levers, gently slide the board
out of the card cage.
Caution – The board has a cutout on the right-hand side, therefore, the right
!
side of the board will clear the card guides before the left side. Grip the edges
of the board firmly or the board could fall and damage components.
11. Place the board on the ESD mat or in an antistatic bag.
2.2.2 Replacement
Note – To select a card cage slot for the system board, refer to Appendix C,
"General Rules for System Configuration."
2-4
SPARCserver 1000 System Board Manual—October 1994
