SBC84500 User's Manual
1.2

Specifications

Process:
Chipset:
Memory:
On-board IDE:
On-Board Multi I/O: One Floppy Port(Box-header) Supports
PS/2 KB /MOUSE:
Watchdog Timer:
2
233MHz National Semiconductor Geode
GX1 (other frequency processors are
manufacturer optional)
NS GX1 + CS5530A
1x144-pin SODIMM Max. 256MB SDRAM
(Please refer to Appendix C for more
information.)
PIO Mode 0-4, DMA Mode 0-1 and One
Channel up to 2 Devices (44-pin
Box-header)
Enhanced IDE ATAPI/16.6/33,LS-120
Bootable
up to 2 Device (LS-120 Bootable)
One SPP/EPP/ECP Parallel
Port(Box-header),(LS-120 Bootable)
Four 16550 UARTs Compatible Serial
Ports with +5V/+12V Power Output in
Pin 1(+5V) and Pin 9(+12V) via Jumper
Setting:
1 x RS-232 (COM1 as D-type)
1 x RS-232/422/485 Jumper Selectable
(COM2 Box-header)
2 x RS-232 (COM3/4 Box-header)
One IrDA (Pin-header) for Wireless
Communication
PS/2 Type (Mini-Din Connector)
System Reset Software Programmable
Timer Interval
64 Levels, 0.5~8 / 5~80 / 50~800 /
100~1600 Seconds
Introduction
