SBC84500 User's Manual
2.4

Connectors

The onboard connectors link the SBC84500VEA to external devices such as
hard disk, floppy disk or printer. The following table lists the function of
each connector on the SBC84500VEA. Corresponding pin assignments are
described in Chapter 3.
Connector
J1
U25
LCD1
IDE1
CON1
JP6
FDD1
LAN1
KBMS1
COM1
COM2
COM3
COM4
VGA1
USB1,USB2
J2
CN1
PC104-1
PC104-2
SOMIMM1
JP7
JP4
JP3
10
Description
IrDA Connector
CompactFlash Socket
Flat Panel Connector
IDE Connector
Parallel Port
Power LED
FDC Connector
Ethernet Connector (1
)
st
K/B and PS/2 Connector
COM1
COM2
COM3
COM4
CRT Connector
USB Connector
Main Power Connector (+5V,+12V)
8 Bit Digital I/O Connector
PC/104 Connector
PC/104 Connector
SODIMM Socket
HDD LED
Hardware Reset
Audio Connector
