AXIOMTEK sbc84500 User Manual page 33

PIN No. PIN Name
SA6
49
SA5
51
SA4
53
SA3
55
57 SA2
SA1
59
SA0
61
GND
63
PC104-2: PC/104 Bus Pin Assignments
PIN No. PIN Name
GND
1
3 MEMCS16 *
IOCS16 *
5
IRQ10
7
IRQ11
9
IRQ12
11
IRQ15
13
15 IRQ14
DACK0 *
17
DRQ0
19
DACK5 *
21
DRQ5
23
DACK6 *
25
27 DRQ6
DACK7 *
29
DRQ7
31
+5V
33
MASTER *
35
GND
37
39 GND
Hardware Description
SBC84500 User's Manual
PIN No. PIN Name
IRQ3
50
DACK2 *
52
TC
54
SALE
56
58 +5V
OSC
60
GND
62
GND
64
PIN No. PIN Name
GND
2
4 SBHE *
LA23
6
LA22
8
LA21
10
LA20
12
LA19
14
16 LA18
LA17
18
MEMR *
20
MEMW *
22
SD8
24
SD9
26
28 SD10
SD11
30
SD12
32
SD13
34
SD14
36
SD15
38
40 NC
27
