6.2.4 Chipset features setup

This setup function works mostly on board's chipset. This option is used to
change the chipset's configuration. Please, carefully change any default
setting, otherwise the system will run unstable.
ROM PCI/ISA BIOS (SBC84500)
SDRAM CAS lantency TIme
SDRAM Clock Ratio Div By
16-bit I/O Recovery (CLK)
8-bit I/O Recovery (CLK)
USB Controller
USB Legacy Support
Award BIOS Utility
SBC84500 User's Manual
CHIPSET FEATURES SETUP
AWARD SOFTWARE, INC.
: 3 T
: 4
: 5
: 5
: Enabled
: Disabled
ESC : Quit
F1 : Help
F5 : Old Values
F6 : Load BIOS Defaults
F7 : Load Setup Defaults
↑ ↓ → ←: Select Item
PU/PD/+/- : Modify
(Shift) F2 : Color
37
