Table Of Contents - aoyue Int701A++ Instruction Manual

This manual is designed to familiarize and instruct the
operator with the proper usage and maintenance of the
equipment. The "Care and Safety Precautions" section
explains the hazards of using any type of soldering or
reworking device. Please read carefully and observe the
guidelines in order to maximize usage and minimize the
risk of injury or accidents .

TABLE OF CONTENTS

Product Description ...................................................... 3
Specifications ............................................................... 4
Package Inclusion ........................................................ 5
Safety Precautions .......................................................
Assembly and Preparation
Control Panel Guide ..................................................... 8
Operating Guidelines ............................................. 9-11
Auto-Sleep Functions
Digital Calibration ................................................. 13-15
Care and Maintenance
Spare Parts List .......................................................... 22
Basic Troubleshooting Guide
2
6
........................................... 7
.................................................... 12
........................................... 16- 21
................................... 23
BASIC TROUBLESHOOTING GUIDE
PROBLEM 1: THE UNIT HAS NO POWER
1. Check if the unit is switched ON. Power switch located at the back.
2. Check the fuse. Replace with the same type if fuse is blown.
3. Check the power cord and make sure there are no disconnections.
4. Verify that the unit is properly connected to the power source.
PROBLEM 2: TEMPERATURE DISPLAY SHOWS "PEN"
Description: Soldering Iron digital display shows the message "Pen"
SOLUTION:
The soldering iron connecting with the main unit is not detected.
Reconnect soldering iron terminal to the main unit. Sensor connection may
be damaged, check for cord damage or sensor damage.
PROBLEM 3: TEMPERATURE DISPLAY SHOWS "Gun"
Description: Desoldering gun digital display shows the message "Gun"
SOLUTION:
The desoldering gun connecting with the main unit is not detected.
Reconnect desoldering gun terminal to the main unit. Sensor connection
may be damaged, check for cord damage or sensor damage.
PROBLEM 4: THE UNIT IS VERY NOISY
SOLUTION:
Make sure the screw at the center of the base of the main unit has been
removed. This holds the pump in place during transportation and needs to
be removed before using the equipment.
PROBLEM 5: UNIT SHOWS UNCONVENTIONAL BEHAVIOR
Description: Unit operates erratically.
SOLUTION1: Try to switch OFF the device and switch ON again. Unplug
the system from the main power source and plug in again when necessary
OTHER PROBLEMS NOT MENTIONED:
Contact the vendor.
23 23
