aoyue Int701A++ Instruction Manual page 10

OPERATING GUIDELINES
7. Start using the soldering iron as soon as desired temperature is
reached.
8. To deactivate the SMOKE ABSORBER function, simultaneously press
both up and down button of the soldering iron temperature adjustment
button ("5" from the control panel).
9. To deactivate the soldering iron function press and hold the soldering
iron function button for 3 to 5 seconds ("3" from control panel).
10. Allow sufficient time for the soldering iron to cool down before keeping
in a safe storage.
E. DESOLDERING GUN
1. Connect the De-soldering gun connection assembly to the 8-pin
receptacle located at the front of the control panel ("8" from the
CONTROL PANEL GUIDE).
2. Follow the initial procedures ("A. INITIAL PROCEDURES").
3. Connect the vacuum tube to the Smoke Absorber Terminal or Vacuum
Cap ("7" from the control panel).
3. To activate the "DESOLDER GUN" function, press and hold the de-
soldering gun function button for 3 to 5 seconds ("6" from control
panel). The de-soldering gun temperature display will momentarily
show the current set temperature then switch to displaying the actual
temperature.
5. Adjust the desoldering gun temperature using the DESOLDERING GUN
TEMPERATURE ADJUSTMENT buttons ("6" from the control panel).
6. Allow the desoldering gun's tip and its barrel to heat up.
temperature can be reached within 5-6 minutes and its barrel would
obtain optimum temperature 5-9 minutes after the tip temperature has
been reached. If upon initial use solder gets stuck at the end of the
barrel, clean the barrel and wait a few more minutes for the barrel to
heat up.
10 10
Solder Iron Digital Temperature Calibration Example
● The external temperature sensor displays 250 degrees.
● The set temperature and displayed actual temperature of the soldering
iron is 300 degrees.
300 — 250 = 50. An additional adjustment of 50 degrees is required.
●
Upon entering calibration mode, the display shows "010", indicating a
calibration number of 10 is already present.
● Therefore 10+50= 60.
We adjust
●
Soldering Iron Temperature Adjustment button.
Save and exit calibration mode.
●
● The external temperature sensor would now display 298 to 302.
Desoldering Gun Digital Temperature Calibration Example
The external temperature sensor displays 300 degrees.
●
The set temperature and displayed actual temperature of the soldering
●
iron is 350 degrees.
300 — 350 = -50. An additional adjustment of –50 degrees is required.
●
Upon entering calibration mode, the display shows "010", indicating a
calibration number of 10 is already present.
Therefore 10-50= -40.
●
We adjust from "010" to "-40" by pressing the down button of the
●
Desoldering Gun Temperature Adjustment .
Save and exit calibration mode.
●
Tip
The external temperature sensor would now display 298 to 302.
●
NOTES:
Calibration will only make the newly calibrated point the most
●
accurate. Other temperature points may be a little off.
DIGITAL CALIBRATION
from "010" to "060" by pressing the up button of the
15 15
