Page 1 Manual No. '10 HM-T-149 • TECHNICAL MANUAL AIR TO WATER HEAT PUMP INDOOR UNIT HMA100V HMA100VM HMS140V OUTDOOR UNIT FDCW71VNX FDCW100VNX FDCW140VNX TANK UNIT HT30 MT300 MT500...
Page 2: Table Of Contents
'10 • HM-T-149 Table of Contents 　 Emergencymode　　52 Safety precautions　　　53 Alarm indications Whathappensintheeventofanalarm?　　53 Recommendedactions　　53 Technical data Resettingalarms　　53 　　 7 Technical specifications Installation specifications　　 7 Installationrequirement　　...
Page 3: Table Of Contents
'10 • HM-T-149 Table of Contents 　　 Radiators - only heating Function check, components HMA100V-FDCW100VNX(71VNX)　 IndoorunitRelaytest-forcedcontrol　 HMS140V(MT300)-FDCW140VNX　　 DIP switch setting 　 Underfloor heating and cooling FDCW71VNX　 FDCW100VNX,140VNX　　 Fan convectors - heating and cooling 　...
Page 4: Safety Precautions
'10 • HM-T-149 When install the unit, be sure to check whether the selection of installation place, power supply specifications, usage limitation (piping length, height differences between indoor and outdoor units, power supply voltage and etc.) and installation spaces SAFETY PRECAUTIONS l We recommend you to read this “SAFETY PRECAUTIONS” carefully before the installation work in order to gain full advantage of the functions of the unit and to avoid malfunction due to mishandling. l The precautions described below are divided into and . The matters with possibilities leading to serious consequences such as death or serious personal injury due to erroneous handling are listed in the and the matters with possibilities leading to personal injury or damage of the unit due to erroneous handling including probability leading to serious consequences in some cases are listed in . These are very important precautions for safety. Be sure to observe all of them without fail. l Be sure to confirm no anomaly on the equipment by commissioning after completed installation and explain the operating methods as well as the maintenance methods of this equipment to the user according to the owner's manual. l Keep the installation manual together with owner’s manual at a place where any user can read at any time. Moreover if necessary, ask to hand them to a new user WARNING l Installation must be carried out by the qualified installer. If you install the system by yourself, it may cause serious trouble such as water leaks, electric shocks, fire and personal injury , as a result of a system malfunction. l Install the system in full accordance with the instruction manual. Incorrect installation may cause bursts, personal injury, water leaks, electric shocks and fire. l Use the original accessories and the specified components for installation. If parts other than those prescribed by us are used, It may cause water leaks, electric shocks, fire and personal injury. l When installing in small rooms, take prevention measures not to exceed the density limit of refrigerant inthe event of leakage. Consult the expert about prevention measures. If the density of refrigerant exceeds the limit in the event of leakage, lack of oxygen can occur, which can cause serious accidents. l Ventilate the working area well in the event of refrigerant leakage during installation.
Page 5 '10 • HM-T-149 l Do not open the service valves for liquid line and gas line until completed refrigerant piping work, air tightness test and evacuation. If the compressor is operated in state of opening service valves before completed connection of refrigerant piping work, air can be sucked into refrigerant circuit, which can cause bust or personal injury due to anomalously high pressure in the refrigerant. l Do not put the drainage pipe directly into drainage channels where poisonous gases such as sulphide gas can occur. Poisonous gases will flow into the room through drainage pipe and seriously affect the user’s health and safety l Only use prescribed optional parts. The installation must be carried out by the qualified installer. If you install the system by yourself, it can cause serious trouble such as water leaks, electric shocks, fire. l Do not run the unit with removed panels or protections. Touching rotating equipments, hot surfaces or high voltage parts can cause personal injury due to entrapment, burn or electric shocks. l Be sure to fix up the service panels. Incorrect fixing can cause electric shocks or fire due to intrusion of dust or water. l Do not perform any repairs or modifications by yourself. Consult the dealer if the unit requires repair. If you repair or modify the unit, it can cause water leaks, electric shocks or fire. l Do not perform any change of protective device itself or its setup condition. The forced operation by short-circuiting protective device of pressure switch and temperature controller or the use of non specified component can cause fire or burst. l Be sure to switch off the power supply in the event of installation, inspection or servicing. If the power supply is not shut off, there is a risk of electric shocks, unit failure or personal injury due to the unexpected start of fan. l Consult the dealer or an expert regarding removal of the unit. Incorrect installation can cause water leaks, electric shocks or fire. l Stop the compressor before disconnecting refrigerant pipes in case of pump down operation. If disconnecting refrigerant pipes in state of opening service valves before compressor stopping, air can be sucked, which can cause burst or personal injury due to anomalously high pressure in the refrigerant circuit. CAUTION l Carry out the electrical work for ground lead with care.
Page 6 '10 • HM-T-149 ・Locations with heavy snow. (If installed, be sure to provide base flame and snow hood mentioned in the manual) ・Locations where the unit is exposed to chimney smoke. ・Locations at high altitude. (more than 1000m high) ・Locations with ammonic atmospheres. ・Locations where heat radiation from other heat source can affect the unit. ・Locations without good air circulation. ・Locations with any obstacles which can prevent inlet and outlet air of the unit. ・Locations where short circuit of air can occur. (in case of multiple units installation) ・Locations where strong air blows against the air outlet of outdoor unit. It can cause remarkable decrease in performance, corrosion and damage of components, malfunction and fire. l Do not install the outdoor unit in the locations listed below. ・Locations where discharged hot air or operating sound of the outdoor unit can bother neighborhood. ・Locations where outlet air of the outdoor unit blows directly to plants. ・Locations where vibration can be amplified and transmitted due to insufficient strength of structure. ・Locations where vibration and operation sound generated by the outdoor unit can affect seriously. (on the wall or at the place near bed room) ・Locations where an equipment affected by high harmonics is placed. (TV set or radio receiver is placed within 5m) ・Locations where drainage cannot run off safely. It can affect surrounding environment and cause a claim. l Do not install the remote controller at the direct sunlight. It can cause malfunction or deformation of the remote controller. l Do not use the unit for special purposes such as storing foods, cooling precision instruments and preservation of animals, plants or art. It can cause the damage of the items. l Take care when carrying the unit by hand. If the unit weights more than 20kg, it must be carried by two or more persons. Do not carry by the plastic straps, always use the carry handle when carrying the unit by hand. Use gloves to minimize the risk of cuts by the aluminum fins. l Dispose of any packing materials correctly. Any remaining packing materials can cause personal injury as it contains nails and wood. And to avoid danger of suffocation, be sure to keep the plastic wrapper away from children and to dispose after tear it up. l Pay attention not to damage the drain pan by weld spatter when welding work is done near the indoor unit. If weld spatter entered into the indoor unit during welding work, it can cause pin-hole in drain pan and result in water leakage. To prevent such damage, keep the indoor unit in its packing or cover it. l Be sure to insulate the refrigerant pipes so as not to condense the ambient air moisture on them. Insufficient insulation can cause condensation, which can lead to moisture damage on the ceiling, floor, furniture and any other valuables. l Be sure to perform air tightness test by pressurizing with nitrogen gas after completed refrigerant piping work. If the density of refrigerant exceeds the limit in the event of refrigerant leakage in the small room, lack of oxygen can occur, which can cause serious accidents.
Page 7: Technical Data
'10 • HM-T-149 Technical data Technical data - -...
Page 8: Technical Specifications
'10 • HM-T-149 Technical data Specifications Technical specifications Specifications Indoor Model HMA100V HMA100VM HMA100V HMA100VM HMS140V Outdoor Model FDCW1VNX FDCW100VNX FDCW140VNX 1 phase 230V 50Hz/ 1 phase 230V 50Hz/ 1 phase 230V 50Hz/ Power source 3 phase 230V 50Hz 3 phase 230V 50Hz...
Page 9 '10 • HM-T-149 Technical data Specifications Indoor Model HMA100V HMA100VM HMA100V HMA100VM HMS140V Outdoor Model FDCW1VNX FDCW100VNX FDCW140VNX Height 1300 Width (+6 with valve cover) Depth (+80 with foot rail) (+80 with foot rail) Weight Color Stucco White Sound Power level* dB(A) 64.5...
Page 10 '10 • HM-T-149 Technical data Installation requirements Installation requirements HMA100V, HMA100VM HMS140V FDCW1VNX FDCW100VNX FDCW140VNX Max pressure, climate system 0.25 MPa (2.5 Bar) 65 ℃ Max temperature, climate system 65 ℃ Max temperature in indoor unit 65 ℃ Max temperature from external heat source Max supply temperature with compressor at outdoor temp.
Page 11 '10 • HM-T-149 Technical data Operating temperature range Operating temperature range Heating (All models) with immersion heater Outdoor air temperature (°C) NOTE 1. Avoid installing outdoor unit where wind blows stronger than 5m/s. In strong wind enviroment, operable temperature range is drastically narrowed i f wind protection is not used.
Page 12 '10 • HM-T-149 Technical data Capacity diagram Capacity diagram HMA100V—FDCW71VNX HMA100VM—FDCW71VNX Heating Maximum (Nominal capacity) Minimum Outdoor air temperature (°C) Condition Supply water temperature : 45ºC Water flow rate : 1376 ℓ /h Cooling Maximum (Nominal capacity) Minimum Outdoor air temperature (°C) Condition Supply water temperature : 7ºC...
Page 13 '10 • HM-T-149 Technical data Capacity diagram HMA100V—FDCW100VNX HMA100VM—FDCW100VNX Heating Maximum (Nominal capacity) Minimum Outdoor air temperature (°C) Condition Supply water temperature : 45ºC Water flow rate : 1548 ℓ /h Cooling Outdoor air temperature (°C) Condition Supply water temperature : 7ºC Water flow rate : 1376 ℓ...
Page 14 '10 • HM-T-149 Technical data Capacity diagram HMS140V—FDCW140VNX Heating Maximum (Nominal capacity) Minimum Outdoor air temperature (°C) Condition Supply water temperature : 45ºC Water flow rate : 2838 ℓ /h Cooling Maximum (Nominal capacity) Minimum Outdoor air temperature (°C) Condition Supply water temperature : 18ºC Water flow rate : 2838 ℓ...
Page 15 '10 • HM-T-149 Technical data Dimensions Dimensions Indoor unit HMA100V HMA100VM (42) 32 32 Symbol contents 95 65 52 XL1 Climate system supply 22 mm XL2 Climate system return 22 mm XL3 Cold water 22 mm XL4 Hot water 22 mm...
Page 16 '10 • HM-T-149 Technical data Dimensions HMS140V Symbol contents XL1 Climate system supply 28 mm XL2 Climate system return 28 mm XL13 Liquid line refrigerant 3 / 8˝ XL14 Gas line refrigerant 5 / 8˝ XL21 Tank circuit supply 28 mm XL22 Tank circuit return 28 mm XL14...
Page 17 '10 • HM-T-149 Technical data Dimensions HT30 XL24 XL23 Symbol contents XL23 Circulation supply G1 ext (1'') XL24 Circulation return G1 ext (1'') - 16 -...
Page 18 '10 • HM-T-149 Technical data Dimensions MT300 505050 Symbol contents XL3 Cold water G1 ext. (1'') XL4 Hot water G1 ext. (1'') XL8 External heat source in R1 int XL9 External heat source out R1 int XL23 XL23 Circulation supply G1 ext.
Page 19 '10 • HM-T-149 Technical data Dimensions MT500 φ759 XL24 XL23 φ668 Symbol contents G1 ext. （ 1˝ ） XL3 Cold water G1 ext. （ 1˝ ） XL4 Hot water XL8 External heat source in G1 int XL9 External heat source out G1 int XL23 Circulation supply 28 mm...
Page 20 '10 • HM-T-149 Technical data Dimensions Outdoor unit FDCW71VNX - 19 -...
Page 21 '10 • HM-T-149 Technical data Dimensions FDCW100VNX Cable gland - 20 -...
Page 22 '10 • HM-T-149 Technical data Dimensions FDCW140VNX - 21 -...
Page 33 （HT30，MT300，MT500）...
Page 39: Electrical Circuit Diagram
'10 • HM-T-149 Technical data Electrical circuit diagram Outdoor unit FDCW 71VNX POWER SOURCE 230V 50Hz TO INDOOR UNIT F(20A) T2 T1 Y/GN F6 (5A) PWB3 FM01 CNO2 (WH) (4A) 6 5 4 3 2 1 4 3 2 1 7 6 5 4 1 CNO1 CNW2...
Page 40 '10 • HM-T-149 Technical data Electrical circuit diagram FDCW 100VNX, 140VNX POWER SOURCE 1∼ 230V Y/GN TO INDOOR UNIT F (30A) F (8A) NOISE FILTER PWB3 F (4A) FM01 FM02 Note Do not connect any wires on the port1 on the outdoor unit. ＋...
Page 41: For Home Owners
'10 • HM-T-149 For Home Owners For Home Owners - 40 -...
Page 42 '10 • HM-T-149 For Home Owners Information about the installation Information about the installation Principle of operation Hydrolution Product information Hydrolution is a complete modern heat pump system that offers effective technical energy saving and reduced carbon dioxide emissions. Heat production is safe and economical with integrated hot water heater, immersion heater, circulation pump and climate system in the indoor unit.
Page 43 '10 • HM-T-149 For Home Owners Front panel, indoor module Front panel, indoor unit Addition. heat symbol Hot water symbol If the electrical addition is connected Hot water charging in progress. “I” Electrical step 1 Temporary Extra hot water operation in “A”...
Page 44 '10 • HM-T-149 For Home Owners Front panel, indoor module How to use the front panel All the most common settings are made from the panel such as comfort etc. that you require the heat pump system to fulfil. In order to make full use of it, certain basic settings must have been made (see page 45) and the installation in general is carried out according to the instructions.
Page 45 '10 • HM-T-149 For Home Owners Comfort setting heating Comfort setting heating General 1. “Auto” The indoor temperature depends on several factors. I ndoor unit automatically selects the operating mode by ■ S unlight and heat emissions from people and household taking the outdoor temperature into account. This means machines are normally sufficient to keep the house warm that the operating mode switches between “Heating”...
Page 46 '10 • HM-T-149 For Home Owners Comfort setting heating Default Heating curve setting Setting with diagrams The diagram shows the relation between the outdoor air The basic heating is set using Menu 2.1.2 and with the temperature in the area and the target supply water temperature “Heating curve offset” knob.
Page 47 '10 • HM-T-149 For Home Owners Comfort setting heating Readjusting the default settings Comfort setting with room sensor If the required room temperature is not obtained, readjustment If MH-RG10 is installed, operation mode is chosen not only by may be necessary. outdoor air temperature but also by room air temperature. Cold weather conditions Upper limit of the outdoor air temperature to operate in Heating mode can be set in Menu 8.2.3 Stop temp Heating. ■ W hen the room temperature is too low, the “Heating curve” value is increased in Menu 2.1.2 by one increment.
Page 48 '10 • HM-T-149 For Home Owners Comfort setting cooling Comfort setting cooling General In the default setting, cooling operation is not allowed. In order to activate, change the setting on the Menu 9.3.3 Cooling system to “On”. NOTE The climate system must manage cooling operation. Setting must be made by installer when commissioning the system.
Page 49 Under section 1.0 [N] Hot water temp. on page 93 there is a complete description of menu settings for hot water temperatures. Available volume <HMA100V, HMA100VM> Stop temp. HW (°C ) Hot water volume 8ℓ/min * This graph is based on the following conditions : Inlet water temperature : 15°C Outlet water temperature : 40°C...
Page 50 ■ C lose the valve again. The climate system’s safety valve ■ T he heating system may need to be refilled after checking <HMA100V, HMA100VM> the safety valve, see the section “Filling the heating system”. Hot water heater safety valve The water heater’s safety valve sometimes releases a little water after hot water usage.
Page 51 '10 • HM-T-149 For Home Owners Maintenance Pressure gauge in indoor unit* Also remember: ■ O pen the thermostat valves completely (except in the The working range of the heating system is normally 0.5 – 1.5 rooms that are to be kept cooler for various reasons, e.g. bar when the system is closed. Check this on the pressure gauge bedrooms). (BP5). Thermostat valves in the radiators and floor loops can * H MS140V is not eguipped with safety valve nor pressure negatively affect the energy consumption. They slow the flow gauge. They are on tank. For details, see page 213.
Page 52 '10 • HM-T-149 For Home Owners Dealing with comfort disruption Dealing with comfort disruption Use the following list to find and remedy any heating or hot water problems. Symptom Cause Action Low hot water temperature or a lack of hot Circuit or main MCB tripped. Check and replace blown fuses. water Heat pump and immersion heater do not heat.
Page 53 '10 • HM-T-149 For Home Owners Dealing with comfort disruption The phenomena mentioned below are not malfunction. The air conditioning system Sounds of rustling or gurgling may be heard when the operation is started, when the compressor is sounds as if water is activated/deactivated during operation, or when the operation is stopped. These are the sounds of the draining from it.
Page 54 '10 • HM-T-149 For Home Owners Alarm indications Alarm indications Different types of alarms There are many monitoring functions integrated in Hydrolution To alert you to any malfunctions, the control computer transmits ■ A larms with automatic reset (do not need to be alarm signals that can be read from the front panel display. acknowledged when the cause has disappeared).
Page 55 '10 • HM-T-149 Installation Installation - 54 -...
Page 56: General
'10 • HM-T-149 Installation Outdoor unit installation Outdoor unit installation PSB012D955D ◎This installation manual deals with outdoor units and general installation specifications only. For indoor units, refer to the respective installation manuals supplied with the units. ● ◎Read this manual carefully before you set to installation work and carry it out according to the instructions contained in this manual. ●...
Page 57 ① ② ● ● '10 • HM-T-149 ● ● ● Installation Outdoor unit installation Indoor unit ● ● ● φ φ φ φ φ φ ● ● Ｈ ● ● ● ● ● ∼ ● ● Ａー...
Page 58 ℃ ℃ '10 • HM-T-149 ② ② Installation ＜＞ Outdoor unit installation ＜＞ ○ ○ ○ ○ φ φ ● ● ● ● ● ● ● ● ● ● ● ● ● ● ℃ ℃ ● ● ○ ○...
Page 59 ● '10 • HM-T-149 Installation Outdoor unit installation （X ）（X ） ● ● − ℃ ● ● ● ● ● ● ● ● ・・・ ℃ ・ ※ ● - 58 -...
Page 60 FASTEN THE SCREWS backs on to a bedroom or living room. ■ F or HMA100V and HMA100VM, ensure that there is approx. 500 mm free space in front of and 220 mm above the product for any future service.
Page 61 Indoor unit installation In the emergency mode, the valve position setting should be Dimensioning expansion vessel made as follows. Internal volume in HMA100V and HMA100VM for calculating expansion vessel is 280 ℓ . The expansion vessel’s volume must QM30 : Horizontal (Closed) be at least 5 % of the total volume.
Page 62 Installation Indoor unit installation 4. C onnect the current limiter, any centralised load control <HMA100V, HMA100VM> and external contacts as well as the cable between indoor unit and outdoor unit. Cable between indoor unit and tank should be connected for the system tank is speparated. See page 70.
Page 63: Dimensions And Pipe Connections
'10 • HM-T-149 Installation Outdoor unit installation Iutdoor unit installation Dimensions and pipe connections <HT30> <HMA100V, HMA100VM> XL23 XL24 32 32 (42) XL13 XL15 XL14 <MT300> <HMS140V> XL23 XL24 <MT500> XL14 XL22 XL21 XL13 HMA100 HMS140 Climate system supply 22 mm...
Page 64 ■ HT30 doesn't have a port for FL2. Safety valve should be Pump capacity diagram installed on site. <HMA100V, HMA100VM> ■ H MS140V needs to connect a buffer vessel on the hot water tank even if hot water supply is not necessary.
Page 65 '10 • HM-T-149 Installation Outdoor unit installation Iutdoor unit installation Connecting the hot water heater <MT500> Connecting hot water tank to HMS140V For HMS140V, it is necessary to connect hot water tank or baffer vessel. ■ T ank and its pipings to indoor unit must be installed XL24 indoors where the temperature wouldn’t drop below 15 °C in order to prevent pipings from icing.
Page 66 (Tapered thread, R1) MT300 (Tapered thread, R1) (Parallel screw, G1) Waste exchanger part (HMA100V, HMA100VM only) <HMS140V> Indoor unit has a waste at the exchange section. A hose routes HMS140V doen’t have a port to connect external heat source but any waste water past the product’s electronics to minimise the...
Page 67 '10 • HM-T-149 Installation Iutdoor unit installation Dockings Hydrolution with climate system and any external heat source MH-RG10 Distributionssystem Climate system Required safety Erf. säker- equipment hetsutr. BT 1 Tillsats External heat source Indoor unit Outdoor unit Symbol key NOTE Symbol Meaning Venting valve...
Page 68 '10 • HM-T-149 Installation Indoor unit installation Climate system Radiator system Under floor heating systems Fan convector system GP10 GP10 GP10 Extra Extra Extra Extra system Extra system Extra system system system system volume volume volume volym volym volym Ö ö...
Page 69 ■ I f the building is equipped with an earth-fault breaker, Hydrolution should be equipped with a separate one. Electrical components ■ C onnection must not be carried out without the permission <HMA100V, HMA100VM> of the electricity supplier and under the supervision of a qualified electrician. 5.5 mm ■ F or interconnection cable between indoor unit and outdoor...
Page 70 '10 • HM-T-149 Installation Indoor unit installation <HMS140V> <MT300> X101 X100 <MT500> AA22 S1 109 X101 -X101 -X100 X100 Explanation Symbol Type Scale length of <HT30> conductor (mm) HMA100 HMS140 X100 AA22 X101 Cable gland Cable gland Terminal block, incoming mains supply Terminal block, outgoing 15 (supply)
Page 71 The temperature limiter (FD1) cuts the current supply to the markings. electrical heater if the temperature rises up between 90 and 100°C and can be manually reset. <HMA100V, HMA100VM> 400 V 3NAC Resetting 400 V 3NAC The temperature limiter (FD1) is accessible behind the front cover. The temperature limiter is reset by firmly pressing in its...
Page 72 (kW) (Menu 8.3.2) HMA100V HMA100VM HMS140V Indoor unit C (factory setting) * Only applies to 3 phase connection. Connection between indoor unit and tank (HMS140V only) Setting max boiler temperature (R26 on AA22) Cable between indoor unit and tank must be connected between...
Page 73 See wiring diagram for complete wiring diagram of the PCB. Connect the current sensor to a multi-core cable in an enclosure <HMA100V, HMA100VM> next to the distribution box. Use unscreened multicore cable of at least 0.50 mm , from the enclosure to indoor unit.
Page 74 '10 • HM-T-149 Installation Indoor unit installation Contact for changing the room temperature External mixing valve (EP21-QN11, accessory) An external contact such as a room thermostat or a timer can Connection and function are described in the Installation be connected to indoor unit to change the flow temperature and instructions for accessory ESV 22. consequently the room temperature.
Page 75 '10 • HM-T-149 Installation Iutdoor unit installation Summary of the function of Current External sensor External thermostat (3phase thermostat the terminals on PCB AA22 only) on timer on timer system 1 system 2 Tariff A Tariff B L1 L2 L3 Outdoor sensor Optional other than...
Page 76 '10 • HM-T-149 Installation BT30 Indoor unit installation How to connect external circulation pump and heat source on X3 <HMA100V, HMA100VM> Open 3 4a 4b 5a 5b <HMS140V> How to connect external circulation pump How to connect external heat source...
Page 77 Close the filling valve (QM1). QM20 6. Open the valve to expansion vessel when air vent is completed (HMS140V only). <HMA100V, HMA100VM> QM20 Venting the climate system 1. Vent indoor unit through the safety valve (FL2) and the rest of the heating system through the relevant venting valves.
Page 78 '10 • HM-T-149 Installation Start-up and inspection NOTE NOTE Be sure to bleed air in the climate system completely. If it is not shown, set the Menu 8.1.1 to “ Service”. The circulation pump may become damaged. 4. Check the supply and return line temperatures in Menu 2.5. Adjust the circulation pump speed in Menu 2.1.5 so that the Filling the hot water coil difference between these temperatures is according to the...
Page 79 '10 • HM-T-149 Installation Start-up and inspection Checking external heat source controlled by the signal from indoor unit 1. Check if the signal wire is connected as instructed. 2. Select “Ext. 1 step” in Menu 9.2.8. 3. S elect operating mode “Add. heat only” by holding in the operating mode button for 7 seconds. 4.
Page 80 '10 • HM-T-149 Installation Start-up and inspection Basic Menu settings to be checked 1. Single heating application with a room sensor (MH-RG10) Extra system volume Overflow valve MH-RG10 BT 1 Fill in the altered set value on the blank cell of “Set value”. As for the set value which is already written in the cell, check if the setting is properly changed. 1. Initial settings Function Menu No. Default value Set value Check Remarks...
Page 81 '10 • HM-T-149 Installation Start-up and inspection 2. Dual heating application with a room sensor (MH-RG10) EP21-GP10 EP21 EP21-QN11 -BT2 EP21-BT3 GP10 MH-RG10 Överströmnings ventil Overflow valve BT 1 1. Initial settings Function Menu No. Default value Set value Check Remarks Language 8.1.2...
Page 82 '10 • HM-T-149 Installation Start-up and inspection Solar panels Solfång Solar panels 3. Single heating application with external heat source Ackumulator Accumulator Extra system volume Overflow valve MH-RG10 External heat source Oil/pellet b ALT 2 ALT. 2 GAS V. ALT. 1 ALT 1 boiler.
Page 83 '10 • HM-T-149 Control Start-up and inspection Checklist: Checks before commissioning Hot water Notes Checked Non-return valve Is it installed in right direction ? Safety valve Is it installed in cold water line ? Mixer valve Is it installed in right direction ? Heating Notes Checked...
Page 84 '10 • HM-T-149 Control Control - 83 -...
Page 85 '10 • HM-T-149 Control Control Control Display Changing parameters Operating symbols Value of the current parameter In order to change a parameter (value): 1. Access the required menu. I II III I II 2. Press button, the numerical value starts to flash. 5 0 .
Page 86: Menu Tree
'10 • HM-T-149 Control Control Menu tree 1.0 [N] Hot water temp. 1.1 [N] Max HW/Peroid time 1.2 [N] Start temperature HW 1.3 [N] Stop temperature HW 1.4 [U] Stop temperature XHW 1.5 [U] Heat pump stop XHW 1.6 [U] Max heat p. time XHW 1.7 [U] Interval XHW 1.8 [U] Next XHW action 1.9 [U] HW run time...
Page 87 '10 • HM-T-149 Control Control 2.0 [N] Supply temp. 2.1.0 [N] Heating settings 2.1.1 [N] Offset heating/Total 2.1.2 [N] Heating curve 2.1.3.0 [U] Own heating curve 2.1.3.1 [U] Supply temp.at +20 2.1.3.2 [U] Supply temp.at -20 2.1.3.3 [U] Buckling temperature 2.1.3.4 [U] Supply t.
Page 88 '10 • HM-T-149 Control Control 3.0 [N] Supply temp. 2 4.0 [N] Outdoor temp. 3.1 [N] Offset heating/Tot 2 4.1 [N] Outdoor avg. temp. 3.2 [N] Heating curve 2 4.2 [U] Outdoor filter time 3.3 [U] Min supply temp. 2 4.3 [U] Outdoor avg.
Page 89 '10 • HM-T-149 Control Control 7.0 [N] Clock 8.0 [N] Other adjustments 7.1 [N] Date 8.1.0 [N] Display settings 8.1.1 [N] Menu type 7.2 [N] Time 8.1.2 [N] Language 7.3.0 [U] Temp set back 7.3.1 [U] Set back time 8.1.3 [N] Display contrast 7.3.2 [U] Set back temp +/- 8.1.4 [N] Light intensity 7.3.3 [U] Heating system...
Page 90 '10 • HM-T-149 Control Control 9.0 [S] Service menus 9.1.0 [S] Heat pump settings 9.1.1 [S] DM start heating 9.1.2 [S] DM start cooling 9.1.3 [S] Stop Temp. heat low 9.1.4 [S] Stop Temp. heat high 9.1.5 [S] Stop Temp. cool low 9.1.6 [S] Stop Temp.
Page 91 '10 • HM-T-149 Control Control 9.0 [S] Service menus 9.3.10.0 [S] Floor drying setting 9.3.10.1 [S] Floor drying 9.3.10.2 [S] Period time 1 9.3.10.3 [S] Temp. period 1 9.3.10.4 [S] Period time 2 9.3.10.5 [S] Temp. period 2 9.3.10.6 [S] Return 9.3.11 [S] Supply pump exer.
Page 92 '10 • HM-T-149 Control Control 9.0 [S] Service menus 9.8.x.6 [S] Run time compressor 9.8.x.7 [S] Outdoor avg. 1min. 9.8.x.8 [S] Outdoor temp Tho-A 9.8.x.9 [S] Supply/Return temp 9.8.x.10 [S] Condensor out 9.8.x.11 [S] Hot water temp. 9.8.x.12 [S] CompFreq act/set 9.8.x.13 [S] Heat Ex Tho-R1 9.8.x.14 [S] Heat Ex Tho-R2 9.8.x.15 [S] Suction temp.
Page 93: Main Menus
'10 • HM-T-149 Control Control Main menus Menu 1.0 [N] Hot water temp. Menu 9.0 [S] Service menus The current hot water temperature in the vessel is shown here. This menu and its sub-menus are only shown on the display screen when access has been selected in Menu 8.1.1.
Page 94 '10 • HM-T-149 Control Control 1.0 [N] Hot water temp. Menu 1.1 [N] Max HW/Period time Menu 1.10.0 [S] HW charge act/set The time of the hot water period and the time for the whole Shows the actual and target values for the hot water charging period are shown here.
Page 95 '10 • HM-T-149 Control Control 2.0 [N] Supply temp. Menu 1.10.9 [S] HW reg value for xP Menu 2.1.0 [N] Heating settings Here you select the breaking point when the flow is no longer Heating settings are made in the sub-menus for this menu. linear to the control signal in the heating medium pump.
Page 96 '10 • HM-T-149 Control Control Control Menu 2.1.4 [U] Min supply heating Menu 2.2.3.3 [U] Return Return to Menu 2.2.3.0. The set minimum level for the supply temperature to the heating system is shown here. Menu 2.2.4 [N] Min supply cooling The calculated flow temperature never drops below the set The set minimum level for the supply temperature to the level irrespective of the outdoor temperature, heating curve or...
Page 97 '10 • HM-T-149 Control Control 3.0 [N] Supply temp. 2 Menu 3.1 [N] Offset heating/Tot 2 Menu 3.6.1 [U] Supply temp.at +20 The heating curve offset 2 is selected here. The supply temperature at an outdoor air temperature of +20 °C is selected here. The total offset of heat curve 2 is also shown here.
Page 98 '10 • HM-T-149 Control Control 4.0 [N] Outdoor temp. 5.0 [N] Heat pump Menu 4.1 [N] Outdoor avg. temp. Menu 5.1 [N] Number of starts The accumulated number of starts with the compressor in This menu shows the average outdoor temperature according outdoor unit is shown here.
Page 99 '10 • HM-T-149 Control Control 6.0 [N] Room temperature* Requires accessory and activation in Menu 9.3.6. Menu 5.15.0 [S] OU communication Readings regarding any communication errors can be made in Menu 6.1 [U] Room compensation the sub-menus to this menu. A factor is selected here that determines how much the Menu 5.15.1 [S] Com.
Page 100 '10 • HM-T-149 Control Control 7.0 [N] Clock Menu 7.5.0 [U] Vacation set back Menu 7.1 [N] Date Holiday settings are made in the sub-menus to this menu. The current date is set here. When the holiday function is active, the calculated supply line Menu 7.2 [N] Time temperature is reduced according to the setting and hot water charging can be switched off.
Page 101 '10 • HM-T-149 Control Control 8.0 [N] Other adjustments Menu 8.2.3 [U] Stop temp. heating Menu 8.1.0 [N] Display settings The average outdoor air temperature at which the heat pump (in Settings concerning language and menu type are set in the sub- auto mode) is to stop heat production.
Page 102: S]ServiceMenus
'10 • HM-T-149 Control Control Menu 8.3.7 [U] Return 9.0 [S] Service menus Return to Menu 8.3.0. Menu 9.1.0 [S] Heat pump settings Menu 8.5.0 [U] Period settings Settings for outdoor unit are made in the sub-menus to this Time periods for heating and hot water production are set in menu.
Page 103 '10 • HM-T-149 Control Control Menu 9.1.8 [S] Min CompFreq act/set Menu 9.2.4 [S] Reg. amplification Select the min compressor frequency here. Both actual and set P section for additional heat control. values are shown. Setting range: 0 – 10.0 FDCW71 FDCW100 FDCW140 Default value: 1.5...
Page 104 '10 • HM-T-149 Control Control Menu 9.3.4 [S] Heating system 2 Menu 9.3.9 [S] Operating state Usage of heating system 2 is defined in this menu. If “Off” is Describes the operating status of Hydrolution. selected in Menu 9.3.3 only “Off” or “Heat” can be selected Shutdown: Additional heater and heat pump are shutdown due (accessory required).
Page 105 '10 • HM-T-149 Control Control Menu 9.3.11 [S] Supply pump exer. Menu 9.3.16 [S] Type of HW sensor Pump operation can be deactivated here. Pump is in operation Here you can select whether to use hot water sensors that for 2 minutes 12 hours after last operation. manage higher temperatures (above 90 °C) or not.
Page 106 '10 • HM-T-149 Control Control Default value: Off Menu 9.5.7 [S] Program version Menu 9.6.3 [S] Max deltaF The current program software version in indoor unit is shown here. The parameter for the heat regulator’s max change of the target compressor frequency is selected here.
Page 107 '10 • HM-T-149 Control Control Menu 9.8.x.1 [S] Time Menu 9.8.x.3 [S] Run status Menu 9.8.x.2 [S] Alarm type Menu 9.8.x.4 [S] Run status last Error code is displayed. For details see page 146. Menu 9.8.x.5 [S] Run status time Alarm Cause Menu 9.8.x.6 [S] Run time compressor...
Page 108 '10 • HM-T-149 System description System description - 107 -...
Page 109: Principle Of Operation Hydrolution
'10 • HM-T-149 System description Principle of operation Principle of operation Hydrolution Function Hydrolution is a system that can produce heating, hot water and cooling. The principle during heating can be simplified as follows: 1. The refrigerant in outdoor unit retrieves heat from the outdoor air then compresses it, which increases the temperature further.
Page 110: Principle Of Operation
'10 • HM-T-149 System description Principle of operation Heating operation mode [Alternating mode] (When the heat load can be covered by the capacity of outdoor unit) 100% of hot water from water heat exchanger goes to radiator. Hot water in the tank is not used. QM31:open Water pump runs at constant speed set at commissioning.
Page 111 '10 • HM-T-149 System description Principle of operation Hot water operation mode (When the water temperature in tank is decreased below setting temperature) 100% of hot water from water heat exchanger goes to tank. QM31:closed (Take note that water flow going in/out tank is different from combined mode).
Page 112 '10 • HM-T-149 System description General General Outdoor unit Tho-A Temperature sensor, outdoor air Explanation Tho-D Temperature sensor, hot gas Tho-R1 Temperature sensor, heat exchanger out External QN11 Mixing valve Tho-R2 Temperature sensor, heat exchanger, in QN12 Shuttle valve for heating/cooling Tho-S Temperature sensor, suction gas Non-return valve...
Page 113: Radiators - Only Heating
'10 • HM-T-149 System description Radiators - only heating Radiators - only heating HMA100V - FDCW100VNX (71VNX) 4-way valve 63H1 High pressure switch Compressor motor Current sensor EEV-C Expansion valve, cooling EEV-H Expansion valve, heating FMo1 Fan motor Low pressure sensor...
Page 114: Hms140V(Mt300)-Fdcw140Vnx
'10 • HM-T-149 System description Principle of operation HMS140V (MT300)-FDCW140VNX Function Installation requirements The heat pump prioritises hot water charging. The compressor See page 9. output is adjusted according to the outdoor temperature. The circulation pump varies the flow to maintain a high charge temperature.
Page 115: Underfloor Heating And Cooling
'10 • HM-T-149 System description Underfloor heating and cooling Underfloor heating and cooling 4-way valve 63H1 High pressure switch Compressor motor Current sensor EEV-C Expansion valve, cooling EEV-H Expansion valve, heating FMo1 Fan motor Low pressure sensor Tho-A Temperature sensor, outdoor air Tho-D Temperature sensor, hot gas Tho-R1...
Page 116: Fan Convectors - Heating And Cooling
'10 • HM-T-149 System description Fan convectors - heating and cooling Fan convectors - heating and cooling 4-way valve 63H1 High pressure switch Compressor motor Current sensor EEV-C Expansion valve, cooling EEV-H Expansion valve, heating FMo1 Fan motor Low pressure sensor Tho-A Temperature sensor, outdoor air Tho-D...
Page 117: Dual System - Heating And Cooling
'10 • HM-T-149 System description Dual system - heating and cooling Dual system - heating and cooling 4-way valve 63H1 High pressure switch Compressor motor Current sensor EEV-C Expansion valve, cooling EEV-H Expansion valve, heating EP21-BT2 Temperature sensor, supply 2 FMo1 Fan motor EP21-BT3...
Page 118: Cooling
'10 • HM-T-149 System description Underfloor heating and fan convectors- heating and cooling Underfloor heating and fan convectors- heating and cooling 4-way valve 63H1 High pressure switch Compressor motor Current sensor EEV-C Expansion valve, cooling EEV-H Expansion valve, heating EP21-BT2 Temperature sensor, supply 2 FMo1 Fan motor...
Page 119: External Heat Source
'10 • HM-T-149 System description External heat source External heat source Function By connecting a solar heat collector via intermediate heat exchanger to indoor unit or tank, the solar heat can produce hot water and heating for the house. If the solar panel does not produce necessary heat, the outdoor unit and the imnersion heater generate heat.
Page 120 '10 • HM-T-149 System description External heat source ↑ Connected to X3:2 and X3:4 with the jumper wire on X3:2-3 removed. For details, see page 75. Function Hydrolution engages additional heat source when the compressor output is not sufficient for the house demand. When the additional heat source is connected, valves QM 30 and QM31 shift to the heating system.
Page 121 '10 • HM-T-149 System description External heat source ↑ Connected to X3:2 and X3:4 with the jumper wire on X3:2-3 removed. For details, see page 75. Function Hydrolution engages additional heat source when the compressor output is not sufficient for the house demand. When the additional heat source is connected, valves QM 30 and QM31 shift to the heating system.
Page 122: Wood
'10 • HM-T-149 System description External heat source Wood Function By connecting a wood-fired boiler via accumulator tank to indoor unit or tank, hot water and heat to the house can be produced by If there is no heat in the accumulator tank, heat and hot water are produced by the heat pump or by internal electric heater according to the selected operating mode.
Page 123 '10 • HM-T-149 Service Service - 122 -...
Page 124: Operation Control Function By The Indoor Unit Controller
'10 • HM-T-149 Service Operation control function by the indoor unit controller Operation control function by the indoor unit controller Operation mode General The modes mentioned below can be chosen from the control panel. Hot water operation always has the first priority over heating/cooling. Mode Function (1) Auto...
Page 125 '10 • HM-T-149 Service Operation control function by the indoor unit controller - 124 -...
Page 126 '10 • HM-T-149 Service Operation control function by the indoor unit controller Mode transition in Auto/AutoC mode Change-over of Heating/Cooling/Hot water operation is controlled by detection with outdoor air temperature sensor (BT1) of the indoor unit. Threshold value depends on setting on Menu 8.2.3 – 8.2.5. Menu 8.2.3 Stop temp.
Page 127 '10 • HM-T-149 Service Operation control function by the indoor unit controller Exceptional case of mode transition In order to prevent water pipes on the system from freezing, there is some exception of mode transition when the outdoor air temperature (BT1) drops below 0°C. 1) In (4) Cooling or (5) Hot water mode;...
Page 128 '10 • HM-T-149 Service Operation control function by the indoor unit controller Supply water temperature control in heating Target supply water temperature can be seen in Menu 2.0 (for heating system 1) and 3.0 (for heating system 2). For dual system, the target temperature for downstream heating system must be lower than that for upstream heating system. Heating curve Heating curve is the basic principle to decide the target supply water temperature for heating.
Page 129 '10 • HM-T-149 Service Operation control function by the indoor unit controller Upper / Lower limit of the supply water temperature Regardless of the heating curve setting and the outdoor air temperature, target water temperature cannot exceed the min/max supply water temperature set in Menu 2.1.4 and 2.3 for heating system 1 or in Menu 3.3 and 3.4 for heating system 2.
Page 130 '10 • HM-T-149 Service Operation control function by the indoor unit controller Heating thermo-ON / OFF control The control by DM value is the basic principle to operate/stop the outdoor unit operation. DM (Degree-Minutes) value DM value is integrated value of the gap between the target and actual supply water temperature. Compressor required speed and electric heater ON/OFF are controlled by the DM value.
Page 131 '10 • HM-T-149 Service Operation control function by the indoor unit controller Exceptional processing of DM value In case the actual supply water temperature BT2 deviates from the target temperature drastically, DM value is sometimes forcibly overwritten to make the water temperature close to the target quickly. Forced outdoor unit operation In case the actual supply water temperature is lower than the target temperature and the gap is bigger than the value set in Menu 9.3.12 (Supply temp diff) when the outdoor unit is not operating, the DM value is overwritten to smaller value than in Menu 9.1.1 by 1,...
Page 132 '10 • HM-T-149 Service Operation control function by the indoor unit controller Supply water temperature control in coonling Principle such as cooling curve, cooling curve offset and upper/lower limit is the same as heating operation. Target supply water temperaure can be checked inMenu 2.0. Cooling curve can be chosen in Menu 2.2.2 Cooling curve Cooling curve is the basic principle to decide the target supply water temperature for cooling.
Page 133 '10 • HM-T-149 Service Operation control function by the indoor unit controller Cooling thermo-ON / OFF control Principle of the control such as DM value is the same as heating operation. DM (Degree-Minutes) value DM value is limited from -100 to +400 and does not exceed the limit. Operation state transition according to DM value According to the DM value, operating state is changed.
Page 134 '10 • HM-T-149 Service Operation control function by the indoor unit controller Hot water operation control Hot water operation is prioritized over heating and cooling. ON/OFF control Regardless of the DM value, hot water operation when tank water temperature (BT6) lowers below Start temp HW in Menu 1.2. It finishes when the tank water temperature reaches Stop temp HW in Menu 1.3.
Page 135 '10 • HM-T-149 Service Operation control function by the indoor unit controller Timing chart of DM value and supply water temperature Water temperature During this period, target water temperature is (Menu 9.6.7)-1.5°C Overshoot upper limit (Menu 9.6.7) Target water temperature by heating curve During Combined mode, target supply water temperature is set at 1K lower than the actual Actual supply water temp.
Page 136 '10 • HM-T-149 Service Operation control function by the indoor unit controller Protection control Current protection 1) Maximum current limit control for the outdoor unit (by indoor unit control) When the operation current of the outdoor unit comes close to the limit, request compressor speed is retained in order to keep the current.
Page 137: Operation Control Function By The Outdoor Unit Controller
'10 • HM-T-149 Service Operation control function by the outdoor unit controller Operation control function by the outdoor unit controller Determination of compressor speed (frequency) Maximum and minimum frequency under normal operating conditions (rps) Model FDCW71VNX FDCW100VNX FDCW140VNX Operation mode Cooling Heating Cooling...
Page 138 '10 • HM-T-149 Service Operation control function by the outdoor unit controller Minimum required frequency adjustment under outdoor air temperature (Tho-A) condition According to the outdoor air temperature, minimum required frequency is offset by as per below table. Model FDCW71VNX FDCW100VNX FDCW140VNX Cooling mode...
Page 139: Outdoor Fan Control
'10 • HM-T-149 Service Operation control function by the outdoor unit controller c) At 30 seconds after starting compressor, the target frequency changes to A rps and the compressor is kept operation at A rps as fixed frequency for B minutes Model Operation Mode A rps...
Page 140 '10 • HM-T-149 Service Operation control function by the outdoor unit controller Outdoor air temperature (°C) Heat exchenger temperature (°C) b) Lower limit Model Operation Mode Min.rpm Cooling FDCW71VNX Heating Cooling FDCW100VNX Heating Cooling FDCW140VNX Heating Fan speed control during cooling operation Fan speed is controlled every 15 seconds according to the outdoor heat exchanger temperature (Tho-R1,-R2), whichever the higher.
Page 141 '10 • HM-T-149 Service Operation control function by the outdoor unit controller Model 71-140 Defrosting Defrosting start conditions If all of the following defrosting condition A or condition B are met, the defrosting operation starts. Defrosting conditions A i) Cumulative compressor operation time after the end of defrosting has elapsed 37 [45] minutes (15 minutes in case the previous defrost operation is forcibly finished by indoor unit protection control) and the cumulative compressor operation time after the start of...
Page 142 '10 • HM-T-149 Service Operation control function by the outdoor unit controller Protective control/ anomalous stop control by compressor speed (frequency) Compressor discharge pipe temperature protection Protective control If the discharge pipe temperature (detected with Tho-D) exceed the setting value, the compressor speed (frequency) is controlled in order to suppress the rise of discharge pipe temperature.
Page 143 '10 • HM-T-149 Service Operation control function by the outdoor unit controller Heating high pressure protection Protective control i) If the liquid line temperature of water heat exchanger (BT15=Thi-L) or the condensing saturated temperature (CST), whichever the higher, exceeds the setting value, the compressor speed (frequency) is controlled to suppress the rise of high pressure.
Page 144 '10 • HM-T-149 Service Operation control function by the outdoor unit controller ③ However, when the control condition ① is established during the control of the compressor protection start Ⅲ , LP alarm is displayed and E49 is recorded in Error Log at the first stop of compressor and it enters the anomalous stop mode.
Page 145 '10 • HM-T-149 Service Operation control function by the outdoor unit controller Power transistor temperature control (FDCW100VNX, 140VNX only) This control monitors the power transistor temperature (TIP) from the start operation of compressor, and when the following condition is established, compressor speed (frequency) is controlled. Reduce compressor speed at every 1 minute.
Page 146 '10 • HM-T-149 Service Operation control function by the outdoor unit controller (with the operation command of fan speed 390rpm or higher), the compressor stops. When the outdoor fan speed drops to 100rpm or lower 5 times within 60 minutes and the compressor stops, Fan alarm is displayed and E48 is recorded in the Error Log and it enters the anomalous stop mode.
Page 147: Alarm List
'10 • HM-T-149 Service Alarm list Alarm list Alarm with automatic reset Alarm Alarm text on the Triggers alarm Resets alarm display When condenser supply (BT12) is less than 5°C. When condenser supply is greater than 14°C. Low condenser out High KF When condenser supply is greater than 60°C and When condenser supply is lower than 51°C.
Page 148 '10 • HM-T-149 Service Alarm list Alarm Alarm text on the Description May be due to display Aborted defrost - Insufficient water flow Occurs if alarm 78 occurs 10 times continuously during defrost operation. Also see the troubleshooting guide on page 158. S.
Page 149 '10 • HM-T-149 Service Alarm list May be due to Alarm Alarm text on the Description display S. fault Tho-D Sensor fault, hot gas in outdoor unit (Tho-D). - Open-circuit or short-circuit on sensor input - Sensor does not work (see “Temperature sensor” section) - Defective control PCB in outdoor unit Also see the troubleshooting guide on page 165.
Page 150: Hm-T-
'10 • HM-T-149 Service Alarm list Alarm Alarm text on the Description May be due to display S. fault Tho-S Sensor fault, suction gas in outdoor unit (Tho-S). - Open-circuit or short-circuit on sensor input - Sensor does not work (see “Temperature sensor” section) - Defective control PCB in outdoor unit Also see the troubleshooting guide on page 174.
Page 151: HotWaterAlarm
'10 • HM-T-149 Service Alarm list Hot water alarm The following alarms block hot water production via outdoor unit. The additional heat source is blocked completely. Alarm Alarm text on the Description May be due to display High HW temp. Too high temperature (>90°C) on hot water sensor - Contactor to internal electric heater defective (BT6).
Page 152 '10 • HM-T-149 Service Troubleshooting guide Troubleshooting guide 3 - Thermal cutout Measure the voltage through the temperature limiter (FD1). Can it be reset mechanically when Replace temperature Has the temperature limiter been the temperature is < 80°C? limiter. mechanically tripped? Was the hot water temperature Check the characteristics of the immersion heater...
Page 153 '10 • HM-T-149 Service Troubleshooting guide 4 - OU power failure Is the voltage supply OK? Check supply power voltage. Has miniature circuit breaker FA2 Turn on the breaker. tripped? Check contactor QA10 and wiring to the outdoor unit. - 152 -...
Page 154 '10 • HM-T-149 Service Troubleshooting guide 5 - Low condenser out Are the characteristics of the condenser Replace the sensor. out sensor (BT12) OK? Is the service valve on the Open it. water line open? Is the valve(s) (QM31 or QN11) Is the operation signal of the Replace the indoor relay board AA6.
Page 155: HighCondenserOut
'10 • HM-T-149 Service Troubleshooting guide 6 - High condenser out Are the characteristics of the condenser out Replace the sensor. sensor (BT12) OK? Check the flow over heat exchanger EP2 and settings for heating and hot water. - 154 -...
Page 156: AntiFreezeHx
'10 • HM-T-149 Service Troubleshooting guide 7 - Anti freeze HX Is the low pressure sensor Does the low pressure saturated temperature on the outdoor unit corrected Plug in the connector surely. correspond to the liquid line temperature (BT15)? properly? If the phenomena persists, Is the valve of the refrigeration Open it.
Page 157 '10 • HM-T-149 Service Troubleshooting guide 8 - High HW temp. 9 High AH temp. Is the characteristics of the sensor Peplace the sensor(s) (BT6, BT19) correct? Is there an external heat source? Is the heat source correctly set? Check the heart source. Check the contactors QA1, QA2, QA3 and replace if necessary.
Page 158 '10 • HM-T-149 Service Troubleshooting guide 10 - High Supply temp. 1, 11 High Supply temp. 2 Is the supply water temperature sensor for the relevant system correctly Connect it correctly. connected? Are the characteristics for the sensor OK? (See “Temperature Defective sensor - replace.
Page 159: AbortedDefrost
'10 • HM-T-149 Service Troubleshooting guide 14, 16 - Aborted defrost Is the water flow rate bigger than Is the water flow setting done Set on correct value. minimum flow rate? correctly? *Go to “No” for alarm 16. It occurs in case water flow is insufficient during defrost.
Page 160 '10 • HM-T-149 Service Troubleshooting guide 31 - S. fault HP Is the pressure sensor (BP4) Connect it correctly correctly connected? Is the saturated temperature of Does the pressure (external meter) balanced pressure same or similar Replace the refrigerant. correspond with the value to the outdoor air temperature displayed in the indoor unit? when the outdoor unit is stopping.
Page 161 '10 • HM-T-149 Service Troubleshooting guide 30 - S. fault Outdoor, 32 - S. fault Cond out, 33 - S. fault Liquid line, 34 - S. fault HW, 35 - S. fault 36 - S. fault supply 1, 37 - S. fault supply 2 Is the actual sensor correctly Connect it correctly.
Page 162 '10 • HM-T-149 Service Troubleshooting guide E35 - High HX temp Are the characteristics of the heat exchanger sensor (Tho-R1, R2) Replace defective sensor. - Is the air circulation at the outdoor Is the air circulation around the unit obstructed? outdoor unit done properly? - Is the installation space sufficient? - Is the heat exchanger clogged?
Page 163 '10 • HM-T-149 Service Troubleshooting guide E36 - Permanent Hotgas Are the characteristics of the Replace defective sensor. hot gas sensor (Tho-D) OK? Does the fault also occur during Insufficient amount of refrigerant. cooling? Recharge it. Check the operation data with Does the discharge pipe temperature logging tool.
Page 164: E37-S.FaultTho-R
'10 • HM-T-149 Service Troubleshooting guide E37 - S. fault Tho-R Is the heat exchanger’s temperature sensor (Tho-R1, R2) correctly Connect it correctly. connected? Are the characteristics of the heat Defective sensor - replace. exchanger’s temperature sensor (Tho-R1, R2) OK? Replace the control PCB.
Page 165: E38-S.FaultTho-A
'10 • HM-T-149 Service Troubleshooting guide E38 - S. fault Tho-A Is the outdoor sensor (Tho-A) Connect it correctly. correctly connected? Are the characteristics of the Defective sensor - replace. outdoor sensor (Tho-A) OK? Replace the control PCB. - 164 -...
Page 166 '10 • HM-T-149 Service Troubleshooting guide E39 - S. fault Tho-D Is the hot gas sensor (Tho-D) Connect it correctly. correctly connected? Are the characteristics of the hot Defective sensor - replace. gas sensor (Tho-D) OK? Replace the control PCB. - 165 -...
Page 167 '10 • HM-T-149 Service Troubleshooting guide E40 - HP alarm If the voltage supply to the outdoor unit is switched off and on too quickly, E40 may be displayed. This is normal. Are the service valves fully open? Open the service valves. Is the high pressure switch Has the high pressure switch Connect the switch correctly.
Page 168: E42-CurrentCut
'10 • HM-T-149 Service Troubleshooting guide E42 - Current cut Is the voltage supply OK? Check supply power voltage. Open the service valves. Are the service valves open? Is the high pressure during Check the amount of refrigerant. operation OK? Check the refrigerant circuit.
Page 169: E45-InverterCommunicationError
'10 • HM-T-149 Service Troubleshooting guide E45 - Inverter communication error Is the connection between the control PCB and the inverter Correct the connection. PCB ok? Are JSW10, 11 on the inverter Set JSW10, 11 to open. PCB all set to open? Check why the inverter PCB has Does the LED on the inverter PCB no power.
Page 170 '10 • HM-T-149 Service Troubleshooting guide E47 - Inverter A/F module over current Does the phenomenon persist after resetting power supply? Is the IC2 crocked or burn? Does the compressor operate? Is the vottage within DC380-390V Detween T26 and T27? Normal.
Page 171 '10 • HM-T-149 Service Troubleshooting guide E48 - Fan alarm Is there any foreign material Remove foreign material. obstructing the fan propeller? Replace the fan motor. If the Does the fan rotate freely when it is resistance between turned by hand? (Vm):red-(GND):blue is 1 kΩ...
Page 172: E49-LpAlarm
'10 • HM-T-149 Service Troubleshooting guide E49 - LP alarm Is the low pressure sensor Correct it. correctly connected? Check the value on the low pressure sensor, via indoor unit, in: (1) stationary compressor, (2) compressor operation. Is the value around 0 MPa, without significant change, both in states (1) and (2)? Check the insulation resistance on...
Page 173 '10 • HM-T-149 Service Troubleshooting guide Cont’d from previous page Are the service valves fully open? Open the service valves. Are the connections to the low pressure sensor and sensor for Connect it. suction gas temperature OK? Defective low pressure sensor Are the characteristics of the low pressure sensor and sensor for or sensor for suction gas...
Page 174: E51-InverterAndFanMotorError
'10 • HM-T-149 Service Troubleshooting guide E51 - Inverter and fan motor error Is the voltage DC 15 V between the Replace the inverter PCB. contacts CNI4:2-3 on the inverter PCB? Is the voltage DC 15 V on the Defective cable between control control PCB side after the contact PCB and inverter PCB.
Page 175 '10 • HM-T-149 Service Troubleshooting guide E53 - S. fault Tho-S Is the sensor for the suction gas temperature (Tho-S) correctly Connect it. connected? Are the characteristics for the Replace the sensor. suction gas sensor OK? Replace the control PCB. - 174 -...
Page 176: E54-S.FaultLpt
'10 • HM-T-149 Service Troubleshooting guide E54 - S. fault LPT Is the low pressure sensor Connect it. correctly connected? Does the pressure (external meter) Check the amount of refrigerant. correspond with the value Check the refrigerant circuit. displayed in the indoor unit? Replace the low pressure sensor.
Page 177: E57-LowRefrigerant
'10 • HM-T-149 Service Troubleshooting guide E57 - Low refrigerant Are the service valves fully open? Open the service valves. Is the connecton of the sensor for indoor heat exchanger Correct it. temperature (BT15) or for inlet water temperature (BT3) OK? Defective the sensors for Are the characteristics of the indoor heat exchanger...
Page 178: E59-InverterError
'10 • HM-T-149 Service Troubleshooting guide E59 - Inverter error Disconnect the outdoor fan motor connector and try to startup Does compressor startup? Defective fan motor→replace. Is power supply voltage OK? Check power supply. Check refrigerant amount and Is the pressure balance at starting refrigerant circuit.
Page 179: Function Check, Components
'10 • HM-T-149 Service Function check, components Function check, components Indoor unit Relay test - forced control Control conditions Forced control of the relays can be carried out in Menu 9.3.7.0. Menu 9.3.7.1 must be selected to “On” in order for the function to be activated.
Page 180 '10 • HM-T-149 Service Function check, components Relay functions Relay Component Name Status Function Connection Circulation pump, climate system -GP1 X1:2 K2, K3 Shuttle valve for Cooling/heating -QN12 K2-0, K3-0 K2-0, K3-1 X1:4 -QN11 Open Mixing valve X1:13 -QN11 Close X1:14 Mixing valve Reversing valve, climate system...
Page 181: Dip Switch Setting
'10 • HM-T-149 Service DIP switches, FDCW71VNX Dip switch setting FDCW71VNX (1) Control PCB Control PCB Factory setting Remarks Switches Parts No. CNTH SW3-1* * See below table CNI1 * See below table SW3-2* CNW2 Keep OFF SW3-3 Keep ON CNIP SW3-4 Keep ON...
Page 182: Fdcw100Vnx,140Vnx
'10 • HM-T-149 Service DIP switches, FDCW100VNX, FDCW140VNX FDCW100VNX, 140VNX (1) Control PCB Control PCB Factory setting Switches Remarks 100VNX 140VNX Keep as factory setting JSW1-1 CNA2 Keep as factory setting JSW1-2 Keep as factory setting JSW1-3 Keep as factory setting JSW1-4 Keep as factory setting SW4-1...
Page 183 '10 • HM-T-149 Service Component replacement Component replacement Indoor unit HMA100V, HMA100VM HMS140V - 182 -...
Page 184: Fdcw71Vnx
'10 • HM-T-149 Service Component replacement Component replacement Outdoor unit FDCW71VNX FDCW71VNX FDCW100VNX FDCW100VNX FDCW140VNX - 183 -...
Page 185 '10 • HM-T-149 Service Component replacement FDCW71VNX Fan and fan motor (FMo1) 1. Loosen the screws and Top panel (5 screws) remove the top panel and service panel first. 2. Loosen 5 screws and remove the front panel including fan grille. Front panel Service panel (5 screws)
Page 186 '10 • HM-T-149 Service Component replacement FDCW71VNX Fan and fan motor (FMo1) 6. Remove tapes and fan cable Control box Tapes Fan cable 7. Release 2 metal clamps 8. Loosen 4 screws and remove fan motor 2 metal clamps 4 screws Compressor (CM) 1.
Page 187 '10 • HM-T-149 Service Component replacement FDCW71VNX Compressor (CM) 2. Remove the top and inner insulations. 3 Cut off the strap and pull out the sensor (Tho-D) Tho-D Top insulation Inner insulation 4. Remove the terminal cover 5. Disconnect the fasten terminal connectors from compressor.
Page 188 '10 • HM-T-149 Service Component replacement FDCW71VNX Control PCB (PWB1) 1. Open the top panel 2. Open the control box cover. Control box Note: Be sure to do this work after elapsing 3 minutes from power OFF. 3. Loosen 4 screws Control PCB 4.
Page 189 '10 • HM-T-149 Service Component replacement FDCW71VNX Inverter PCB (PWB2) 1. Remove control PCB first Note: Be sure to do this work after elapsing 3 minutes from power OFF. 2. Disconnect the connectors 3. Pinch the head of locking support and remove inverter Inveter PCB CNG2 CN12...
Page 190 '10 • HM-T-149 Service Component replacement FDCW71VNX Noise filter PCB (PWB3) 1. Remove control PCB first Note: Be sure to do this work aftter elapsing 3 minutes from power OFF. 3. Cut straps CNW2 4. Disconect the connectors Noise filter PCB CNA2 and CNO2 on the noise filter PCB 5.
Page 191 '10 • HM-T-149 Service Component replacement FDCW100VNX Fan and fan motor (FMo1) 1. Loosen 4 screws and remove the fan grille 4 screws 2. Loosen the nut and remove the fan propeller 1 nut 3. Detach the clamps and cut Clamps off the straps 4.
Page 192 '10 • HM-T-149 Service Component replacement FDCW100VNX Fan and fan motor (FMo1) 5. Loose 4 screws 6. Remove the fan motor 4 screws Compressor (CM) 1. Loosen screws and remove the service panel and top 4 screws (short) panel. 2. Loosen 4 short screws and 4 long screws and then remove the bar for easy access to the compressor.
Page 193 '10 • HM-T-149 Service Component replacement FDCW100VNX Compressor (CM) 4. Remove the top insulation 5. Remove the terminal cover 6. Disconnect the fasten terminal connectors from compressor. U: Red cable V: White cable W: Blue cable Terminal cove r Top Insulation Tho-D 7.
Page 194 '10 • HM-T-149 Service Component replacement FDCW100VNX Compressor (CM) 9. Untie the strings and remove the insulations 10. Unscrew and disconnect the grounding cable 11. Loosen 3 nuts of Upper insulation compressor fixing bolts 3 nuts of compressor Lower insulation Screw for 3 nuts of compressor grounding...
Page 195 '10 • HM-T-149 Service Component replacement FDCW100VNX Control PCB (PWB1) 3. Disconnect all connectors C o n t r o l P C B CNA2 CNW2 CNA1 CNT3 CNFAN1 CNT1 CNEEV2 CNEEV1 CNTH CNIP CNPS 4. Pinch the head of locking supports and remove the control PCB.
Page 196 '10 • HM-T-149 Service Component replacement FDCW100VNX Inverter PCB (PWB2) 1. Loosen 7 screws and remove the control PCB layer. 1 screw Note: Be sure to do this work after elapsing 3 minutes from power OFF. 6 screws 2. Disconnect the connectors Control PCB layer 9 screws of CNI2, CNI4 and CNACT1...
Page 197 '10 • HM-T-149 Service Component replacement FDCW100VNX Noise filter PCB (PWB3) 1. Loosen 6 screws and disconnect the cables 2. Disconnect the connector Note: Be sure to do this work after elapsing 3 minutes from power OFF. Noise filter PCB Control PCB layer 6 screws Connector...
Page 198: Fdcw140Vnx
'10 • HM-T-149 Service Component replacement FDCW140VNX Fan and fan motor (FMo1& FMo2) 1. Loosen the screws and remove the fan grille for upper fan (FMo1) and/or lower fan (FMo2). 4 screws each 2. Loosen the nut and remove the fan propeller for upper fan (FMo1) and/or lower fan (FMo2) 1 nut...
Page 199 '10 • HM-T-149 Service Component replacement FDCW140VNX Fan and fan motor (FMo1& FMo2) 4. Detach the clamps and cut Clamps off the straps Straps 5. Loosen 4 screws 6. Remove the fan motor (FMo1 and/or FMo2) 4 screws Compressor (CM) 1.
Page 200 '10 • HM-T-149 Service Component replacement FDCW140VNX Compressor (CM) 2. Untie the strings and remove the top and side insulations Tho-D 3 Cut off the strap and pull out the sensor (Tho-D) Insulation (top section) Outer insulations (side section) Inner insulations (side section) 4.
Page 201 '10 • HM-T-149 Service Component replacement FDCW140VNX Control PCB (PWB1) 1. Unscrew and disconnect the cable 2. Cut the strap and take the cable out from CT hole as shown in the photo Note: Be sure to do this work after elapsing 3 minutes from power OFF.
Page 202 '10 • HM-T-149 Service Component replacement FDCW140VNX Inverter PCB (PWB2) 1. Loosen 2 screws on the bar 2. Loosen 7 screws and remove side pannel 2 screws (small) 6 screws (short) 1 screws (long) 3. Loosen 4 screws and remove the bar for easy access to the inverter PCB layer Note: Be sure to do this...
Page 203 '10 • HM-T-149 Service Component replacement FDCW140VNX Inverter PCB (PWB2) 4. Loosen a screw on the capacitor and disconnect the red and blue cables which are connected to the control 5. Disconnect the fasten terminals of red and white cables which are connected to the control PCB.
Page 204 '10 • HM-T-149 Service Component replacement FDCW140VNX Noise filter PCB (PWB3) 1. Loosen 6 screws and disconnect the cables 2. Disconnect the connector Note: Be sure to do this work after elapsing 3 minutes from power OFF. Noise filter PCB Control PCB layer 6 screws Connector...
Page 205: Components
'10 • HM-T-149 Components Components - 204 -...
Page 206 '10 • HM-T-149 Components Indoor unit Indoor unit Circulation pump (GP10) Dimensions <All models> General NOTE The pump must not be operated dry, as this damages the bearings extremely quickly. Electrical connections When the electrical connection is correct, the indicator lamp illuminates green continuously.
Page 207 Air in the system. Dirt in the pump. - Open and clean the pump. Worn bearings. - Replace the pump. Technical specifications Circulation pump <HMS140V> <HMA100V, HMA100VM> Max pressure height Max pressure height Max volume flow 3000ℓ/h Max volume flow 3500ℓ/h Min/max temperature -10 °C* to +95 °C...
Page 208: ShuttleValves(Qm30,Qm31,Qn11)
'10 • HM-T-149 Components Indoor unit Shuttle valves (QM30, QM31, QN11) Actuator on 3 way valve Actuator on 2 way valve Flow B - AB = 0 % B - AB = 100 % Flow B - A = 100 % B - A = 0 % A - AB = 100 % A - AB = 0 %...
Page 209 '10 • HM-T-149 Components Indoor unit Technical data 2 way valve Technical specifications actuator V415B LR230A-002 LI Connection G1˝ ext Voltage AC 100-240 V Length 74 mm Frequency 50/60 Hz KVS value Output 1.5 W Electrical connections 3 × 0.75 mm Run time 35 s / 90 °...
Page 210: ParticleFilter(Hq1)
'10 • HM-T-149 Components Indoor unit Particle filter (HQ1) Safety valve (FL2) Mesh size 0.8 mm Connection inlet G1/2˝ int Connection outlet G3/4˝ int Connection G1˝ ext Opening pressure 2.5 bar Length 118 mm KVS value Summary Part no. Component Symbol HMA100 HMS140...
Page 211: Outdoor Unit
'10 • HM-T-149 Components Outdoor unit Outdoor unit Compressor Expansion valve Discharge gas Suction gas Coil (stator) Terminal block Permanent magnet (rotor) Rotor (motor) Needle valve Stator (motor) Refrigerant Crankshaft Cylinder Accumulator Rotor Refrigerant Low pressure sensor 4-way valve From discharge Electric signal Valve Pressure sensitive...
Page 212: Temperature Sensor
'10 • HM-T-149 Components Temperature sensor Temperature sensor Sensor placement Tho-S, Tho-R1, Tho-R2 (kΩ) BT 1 BT12 BT15 100 (ºC) Temperature Tho-A (kΩ) Tho-A Tho-S Tho-D Tho- BT19 Tho-R2 AMS 10 ACVM 270 Temperature sensor, outdoor air (external) (ºC) Temperature sensor, supply Temperature Temperature sensor, heat exch.
Page 213 '10 • HM-T-149 Components Component positions Component positions Indoor unit Component image HMA100V, HMA100VM XL15 XL13 XL14 QM20 QM30 QM31 QN11 QA10 AA22-R26 AA22-R25 AA22-R24 AA22 BT30 AA21 AA23 BT24 BT19 - 212 -...
Page 214 '10 • HM-T-149 Components Component positions HMS140V QN11 QM30 QM31 AA23 AA22-R26 FD1-QA41 AA22-R25 AA22-R24 XL22 XL21 XL14 AA22 QM20 XL13 AA21 BT12 BT15 - 213 -...
Page 215 '10 • HM-T-149 Components Component positions HT30 - 214 -...
Page 216 '10 • HM-T-149 Components Component positions MT300 FD1-BT30 BT19 X101 X100 BT24 - 215 -...
Page 217 '10 • HM-T-149 Components Component positions MT500 - 216 -...
Page 218 '10 • HM-T-149 Components Component positions List of components Sensor, thermostats Temperature sensor, tank water Pipe connections BT19 Temperature sensor, immersion heater Climate system supply Temperature sensor, external heat source BT24 Climate system return BT30 Thermostat, standby mode Cold water Temperature limiter Hot water Docking in...
Page 219: OutdoorUnit
'10 • HM-T-149 Components Component positions Outdoor unit FDCW140VNX Component image PWB3 PWB1 FDCW71VNX PWB2 PWB2 PWB1 FMo1 63H1 PWB3 63H1 EEV-C FMo1 QM35 EEV-H QM36 EEV-C QM35 FMo2 QM36 EEV-H List of components FDCW100VNX Solenoid for 4-way valve 63H1 High pressure switch Compressor motor PWB3...
Page 220: Accessories　 Accessories
'10 • HM-T-149 Components Accessories Accessories Accessories MH-RG 10 Drain Pan heater VCC22 Drain pan heater to outdoor module Room sensor. Reversing valve, cooling for operation in colder climates. Part no. MCD291A001 Part no. MCD291A002 Part no. PCZ006A033C ESV 22 ACK22 Extra mixing valve group.
Page 221: WindProtection
'10 • HM-T-149 Components Accessories Wind protection (prepared on site) At the site where the following conditions meet, wind protection for outdoor unit is required to avoid capactity drop or abnormal stop for protection. ● Natural wind directly blows into outdoor unit. ●...
Page 222 '10 • HM-T-149 Components Accessories Rear wind guard φ8 5−φ6 30゜ Side wind guard 212.5 45゜ 4−φ6 258.5 - 221 -...
Page 223 '10 • HM-T-149 Components Accessories < For FDCW100VNX> Front wind guard (screw position) 2−φ3 4−φ6 Attachment Attachment (detail) 2−φ8 4−φ3 -0.1 17.5 Prepare a pair of symmetrical attachment. - 222 -...
Page 224 '10 • HM-T-149 Components Accessories Rear wind guard 4−φ6 Use M5×13 self-drilling screw to attach it where screw hole is not available. 15゜ Side wind guard 4−φ6 Use M5×13 self-drilling screw to attach it where screw hole is not available. 30゜...
Page 225 '10 • HM-T-149 Components Accessories < For FDCW140VNX> Front wind guard Appearance is as same as FDCW100VNX but two pieces are required. Rear wind guard 13−φ6 (A mark) Use M5×13 self-drilling screw to attach it where screw hole is not available. B mark (3 places) Side wind guard Use M5×13 self-drilling screw to attach it...
Page 226 Air-Conditioning & Refrigeration Systems Headquarters 16-5, 2-chome, Kounan, Minato-ku, Tokyo, 108-8215, Japan Fax : (03) 6716-5926 Because of our policy of continuous improvement, we reserve the right to make changes in all specifications without notice. © Copyright MITSUBISHI HEAVY INDUSTRIES, LTD.
Page 227 Manual No. '10 HM-T-149A • TECHNICAL MANUAL (Amendment Edition) AIR TO WATER HEAT PUMP INDOOR UNIT HMA100V HMA100VM HMS140V OUTDOOR UNIT FDCW71VNX FDCW100VNX FDCW140VNX TANK UNIT HT30 MT300 MT500 The information which is revised is mentioned in this document. Please refer to 10 HM-T-149 about the points which is not mentioned in this technial manual.』...
Page 228 Contents Item page Reference ('10・HM-T-149) 1.Installation requirements 2.Dimensions 2-5 14,15,17,18 3.Electrical circuit diagram 6-21 22-37 4.Temporary hot water 5.Installation space 6.Connection between indoor unit and outdoor unit 24,25 57,71 7.Assembly 26-28 8.Dimensioning expansion vessel Initial pressure and max height difference 9.Manual shunting 10.Connecting the climate system 11.Connecting the hot water heater Connecting hot water tank to HMS140V 12.Connection of external heat source 33,34 13.Setting max power, electric heater (R25 on AA22) 14.Summary of the function of the terminals on PCB AA22 15.Commissioning 16.Setting system flow heating 17.Menu 9.1.10 and menu 9.1.11 18.Menu 9.3.5 19.External heat source 40-43 118-121 20.Actuator operation according to the operation mode 21.Heating curve 45,46 22.Defrosting 23.Error code (E45,E51,E59) 48-50 168,173,177...
Page 229 '10 • HM-T-149A Technical data Installation requirements Installation requirements HMA00V, HMA00VM HMS40V FDCW7VNX FDCW00VNX FDCW40VNX Max pressure, climate system 0.25 MPa (2.5 Bar) 65 ℃ Max temperature, climate system 65 ℃ Max temperature in indoor unit 65 ℃ Max temperature from external heat source Max supply temperature with compressor at outdoor temp.
Page 230 '10 • HM-T-149A Technical data Dimensions Dimensions Indoor unit HMA100V HMA100VM Back (42) 32 32 Symbol contents 95 65 52 Climate system supply 22 mm Climate system return 22 mm Cold water 22 mm Hot water 22 mm External heat source in...
Page 231 '10 • HM-T-149A Technical data Dimensions HMS140V Front Symbol contents Climate system supply 28 mm Climate system return 28 mm XL3 Liquid line refrigerant 3 / 8˝ XL4 Gas line refrigerant 5 / 8˝ XL2 Tank circuit supply 28 mm XL22 Tank circuit return 28 mm...
Page 232 '10 • HM-T-149A Technical data Dimensions MT300 Front 505050 Symbol contents XL3 Cold water G1 ext. (1'') XL4 Hot water G1 ext. (1'') XL8 External heat source in R1 int XL9 External heat source out R1 int XL23 XL23 Circulation supply G1 ext.
Page 233 '10 • HM-T-149A Technical data Dimensions MT500 Back φ759 Front XL24 XL23 φ668 Symbol contents G ext. （ 1˝ ） Cold water G ext. （ 1˝ ） Hot water External heat source in G int External heat source out G int XL23 Circulation supply 28 mm...
Page 234 (1)-② (2)-② Note: Meaning of (1)-② is that No. (1) wire is connected to the same No. of wire shown in the wiring diagram ②. (1) means the wiring No. ② means the wiring diagram No. such as HMA100V ②...
Page 235 (1)-① (1' )-③ (2' )-③ (2)-① (L)-① (E)-① (3)-⑤ (4)-⑤...
Page 236 (1' )-② (2' )-② (A)-① (B)-① (F)-① (G)-①...
Page 238 (3)-② (J)-① (4)-② (K)-①...
Page 239 (A)-③ (B)-③ (L)-② (1)-② (2)-② Note: Meaning of (1)-② is that No. (1) wire is connected to the same No. of wire shown in the wiring diagram ②. (1) means the wiring No. ② means the wiring diagram No. such as HMA100VM ②...
Page 240 (1' )-③ (1)-① (2' )-③ (2)-① (L)-① (E)-① (3)-⑤ (4)-⑤...
Page 241 (1' )-② (2' )-② (B)-① (C)-① (F)-① (G)-①...
Page 243 (3)-② (J)-③ (4)-② (K)-③...
Page 244 (1)-② (2)-② (FA1:2)-② (X1:26)-④ (SF1:P2)-② (X4:11)-④ (X4:12)-① (SF1:4)-② （HT30，MT300，MT500） Note: Meaning of (1)-② is that No. (1) wire is connected to the same No. of wire shown in the wiring diagram ②. (1) means the wiring No. ② means the wiring diagram No. such as HMA100VM ②...
Page 245 (1)-① (2)-① (FA1:2)-① (SF1:P2)-① (SF1:1)-③ (SF1:4)-① (1' )-③ (2' )-③...
Page 246 (1' )-② (1'' )-④ (2' )-② (2'' )-④ (SF1:1)-② (X3:1)-① (3)-⑥ (4)-⑥...
Page 247 (1'' )-③ (2'' )-③ (X1:26)-① (X3:3)-① (X4:11)-①...
Page 249 (3)-③ (J)-① (4)-③ (K)-①...
Page 250 The water heater’s safety valve sometimes releases a little water after hot water usage. This is because the cold water, <HMA100V, HMA100VM> which enters the heater to replace the hot water, expands when heated causing the pressure to rise and the safety valve to open.
Page 251 3.The unit should be installed on a） Gauge manifold Connected indoor unit model HMA100V-270 (71VNX, 100VNX), HMS140V (140VNX) or TV interference. of the unit to face a wall of of the unit in a position the stable and level foundation.
Page 253 '10 • HM-T-149A Installation Outdoor unit installation - 57 -...
Page 254: General Information
3. Hang indoor unit on bracket. Current sensor, 3 phase Safety valve with manometer (HMA100V(M) only) The enclosed kit is located behind the front service cover in indoor unit. Assembly ■ It is recommended that indoor unit is installed in a room with existing floor drainage, most suitably in a utility room or boiler room.
Page 255 '10 • HM-T-149A Installation Indoor unit installation Installation space HMA100V,HMA100VM <Front> <Top> 220mm 1,000mm Back Front HMS140V <Front> <Top & left side> 500mm 1,000mm 500mm Back Front HT30 <Right side> 600mm - 59 -...
Page 256 '10 • HM-T-149A Installation Indoor unit installation MT300 <Front> 600mm(For replacement of an immersion heater) MT500 600mm(For replacement of an immersion heater) - 59 -...
Page 257 '10 • HM-T-149A Installation Indoor unit installation Dimensioning expansion vessel Revised (refer to following page) Internal volume in HMA00V and HMA00VM for calculating expansion vessel is 280 ℓ . The expansion vessel’s volume must Emptying the vessel be at least 5 % of the total volume. HMS40V has 8 ℓ...
Page 258 2.Turn the mixing valve to the desired position by hand. 3.When recovered, press a button to unhook, so that the valve is controlled by a system. In the emergency mode, the valve position should be set as follows <HMA100V, HMA100VM> <Valve position of emergency mode> QM30 QM31...
Page 259 HT30 doesn't have a port for FL2. Safety valve should be Pump capacity diagram installed on site. <HMA100V, HMA100VM> ■ HMS140V needs to connect a buffer vessel on the hot water tank even if hot water supply is not necessary.
Page 260 '10 • HM-T-149A Installation Iutdoor unit installation Connecting the hot water heater <MT500> Connecting hot water tank to HMS140V XL4 (to hot For HMS40V, it is necessary to connect hot water tank or domestic water) baffer vessel. XL24 (from XL21 ■...
Page 261 For the ones controlled independently, temperature sensor of it should be placed on BT24 to manage the water temperature. For details, see page 8 to 2 of '10 ・ HM-T-49 (Tapered thread, R1) <HMA100V, HMA100VM> (Parallel screw, G1) BT24 (Tapered thread, R1)
Page 262 (Parallel thread, G1) (Parallel thread, G1) Waste exchanger part (HMA100V, HMA100VM only) Indoor unit has a waste at the exchange section. A hose routes any waste water past the product’s electronics to minimise the risk of damage. If necessary, a hose extension can be connected.
Page 263 3 phase 1 phase brown blue black grey (R25) output(kW) (Menu 8.3..2) yellow/green HMA100V HMA100VM HMS140V HMA100V HMS140V Indoor unit C(Factory setting) Connection between indoor unit and tank Setting max boiler temperature (R26 on AA22) (HMS140V only) The setting of the different maximum boiler temperatures is Cable between indoor unit and tank must be connected between made on the knob (R26) on the PCB (AA22).
Page 264 '10 • HM-T-149A Installation Iutdoor unit installation Summary of the function of Current External sensor External thermostat (3phase thermostat the terminals on PCB AA22 only) on timer on timer system 1 system 2 Tariff A Tariff B L1 L2 L3 Outdoor sensor Optional other than...
Page 265 '10 • HM-T-149A Installation Start-up and inspection NOTE NOTE Be sure to bleed air in the climate system completely. If it is not shown, set the Menu 8.1.1 to “ Service”. The circulation pump may become damaged. 4. Check the supply and return line temperatures in Menu 2.5. Filling the hot water coil Adjust the circulation pump speed in Menu 2.1.5 so that the difference between these temperatures is according to the...
Page 266 '10 • HM-T-149A Control Control Menu 9.1.8 [S] Min CompFreq act/set Menu 9.2.4 [S] Reg. amplification Select the min compressor frequency here. Both actual and set P section for additional heat control. values are shown. Setting range: 0 – 10.0 FDCW71 FDCW100 FDCW140 Default value: 1.5...
Page 267 '10 • HM-T-149A Control Control Menu 9.3.4 [S] Heating system 2 Menu 9.3.9 [S] Operating state Usage of heating system 2 is defined in this menu. If “Off” is Describes the operating status of Hydrolution. selected in Menu 9.3.3 only “Off” or “Heat” can be selected Shutdown: Additional heater and heat pump are shutdown due (accessory required).
Page 268 '10 • HM-T-149A System description External heat source External heat source Function By connecting a solar heat collector via intermediate heat exchanger to indoor unit or tank, the solar heat can produce hot water and heating for the house. If the solar panel does not produce necessary heat, the outdoor unit and the imnersion heater generate heat.
Page 269 '10 • HM-T-149A System description External heat source ↑ Connected to X3:2 and X3:4 with the jumper wire on X3:2-3 removed. For details, see page 75. Function Hydrolution engages additional heat source when the compressor output is not sufficient for the house demand. When the additional heat source is connected, valves QM 30 and QM31 shift to the heating system.
Page 270 '10 • HM-T-149A System description External heat source ↑ Connected to X3:2 and X3:4 with the jumper wire on X3:2-3 removed. For details, see page 75. Function Hydrolution engages additional heat source when the compressor output is not sufficient for the house demand. When the additional heat source is connected, valves QM 30 and QM31 shift to the heating system.
Page 271 '10 • HM-T-149A System description External heat source Wood Function By connecting a wood-fired boiler via accumulator tank to indoor unit or tank, hot water and heat to the house can be produced by If there is no heat in the accumulator tank, heat and hot water are produced by the heat pump or by internal electric heater according to the selected operating mode.
Page 272 Actuator operation according to the operation mode Outdoor unit side Indoor unit side Electric Circulation Cooling State Function Compressor Outdoor fan 4-way valve Shunt valve Ball valve Ball valve status heater pump shift valve FMo1 QN11 QM30 QM31 QN12 Heating Switching Heating Closed...
Page 273 '10 • HM-T-149A Service Operation control function by the indoor unit controller Supply water temperature control in heating Target supply water temperature can be seen in Menu 2.0 (for heating system 1) and 3.0 (for heating system 2). For dual system, the target temperature for downstream heating system must be lower than that for upstream heating system. Heating curve Heating curve is the basic principle to decide the target supply water temperature for heating.
Page 274 '10 • HM-T-149A Service Operation control function by the indoor unit controller Heating curve offset It is possible to offset the heating curve chosen in the menu above in order to obtain higher target supply water temperature. The offset for heating system 1 can be set using the knob on the controller. The set value can be seen in Menu 2.1.1. The figure below shows the case that heating curve 9 is chosen with heating curve offset +2.
Page 275 '10 • HM-T-149A Service Operation control function by the outdoor unit controller Model 71-140 Defrosting Defrosting start conditions If all of the following defrosting condition A or condition B are met, the defrosting operation starts. For model 140, SV1 is open when 4 way valve switches, and closed when low pressure keeps 0.55MPa or higher for 5 seconds or longer.
Page 276 '10 • HM-T-149A Service Troubleshooting guide E45 - Inverter communication error Is the communication between the control PCB and the inverter Correct the connection PCB OK? Are JSW10, 11 on the inverter Set JSW10, 11 correctly PCB all set correctly ? Note (1): See page 180 &...
Page 277 '10 • HM-T-149A Service Troubleshooting guide E51 - Inverter and fan motor error - 173 -...
Page 278 '10 • HM-T-149A Service Troubleshooting guide E59 - Inverter error - 177 -...
Page 279 '10 • HM-T-149A Service DIP switches, FDCW71VNX Dip switch setting FDCW71VNX (1) Control PCB Control PCB Factory setting Remarks Switches Parts No. CNTH SW3-1* * See below table CNI1 * See below table SW3-2* CNW2 Keep OFF SW3-3 Keep ON CNIP SW3-4 Keep ON...
Page 280 '10 • HM-T-149A Service DIP switches, FDCW100VNX, FDCW140VNX FDCW100VNX, 140VNX (1) Control PCB Control PCB Factory setting Switches Remarks 100VNX 140VNX Keep as factory setting JSW1-1 CNA2 Keep as factory setting JSW1-2 Keep as factory setting JSW1-3 Keep as factory setting JSW1-4 Keep as factory setting SW4-1...
Page 281 '10 • HM-T-149A Components Temperature sensor Temperature sensor Sensor placement Tho-S, Tho-R1, Tho-R2 (kΩ) BT 1 BT12 BT15 100 (ºC) Temperature Tho-A (kΩ) Tho-A Tho-S Tho-D Tho- BT19 Tho-R2 AMS 10 ACVM 270 Temperature sensor, outdoor air (external) (ºC) Temperature sensor, supply Temperature Temperature sensor, heat exch.
Page 282: Installation Manual
PSB012D983 Installation and instruction sheet for MT500 and HT30 Emptying the vessel (Page 6 in installation manual) The vessel in indoor unit is emptied by opening the valve (QM1) and safety valve (FL2) on the tank. MT500 HT30 Note This installation and instruction sheet is a supplement sheet for installation manual and user's manual for HMS140V attached in the outdoor unit. Refer to the installation manual and instruction manual attached in outdoor unit for details.
Page 283 Connecting hot water heater / buffer vessel (Page 8 in installation manual) Electrical components (Tank) (Page 13 in installation manual) For MT500,install joints and relevant components as illustrated before connecting pipes. MT500 HT30 <T connection with Mamometer> <X connection> FD1-BT30 X100 X101 Fasten it on XL24 so that the Mamometer comes on top.
Page 284 '10 • HM-T-149A Components Component position HT30 X100 X101 XL24 SENSOR BT19 XL23 FD1-BT30 IMMERSION HEATER 9KW MT500 XL24 FD1-BT30 BT19 X101 BT24 X100 XL23 - 214, 216 -...
Page 285 16 ℓ /min complete description of menu settings for hot water temperatures. 24 ℓ /min Available volume <HMA100V, HMA100VM> Hot water volume Stop temp. HW(°C) Stop temp. HW (°C ) 8ℓ/min * This graph is based on the following conditions : Inlet water temperature : 15°C...
Page 286: Readjusting The Default Settings
'10 • HM-T-149A Installation Outdoor unit installation Readjusting the default settings Comfort setting with room sensor If the required room temperature is not obtained, readjustment If MH-RG10 is installed, operation mode is chosen not only by may be necessary. outdoor air temperature but also by room air temperature. Cold weather conditions Upper limit of the outdoor air temperature to operate in Heating mode can be set in Menu 8.2.3 Stop temp Heating.
Page 287 '10 • HM-T-149A Technical data Specifications Technical specifications Specifications Indoor Model HMA100V HMA100VM HMA100V HMA100VM HMS140V Outdoor Model FDCW71VNX FDCW100VNX FDCW140VNX 1 phase 230V 50Hz/ 1 phase 230V 50Hz/ 1 phase 230V 50Hz/ Power source 3 phase 230V 50Hz 3 phase 230V 50Hz...
Page 288 '10 • HM-T-149A Technical data Specifications Indoor Model HMA100V HMA100VM HMA100V HMA100VM HMS140V Outdoor Model FDCW71VNX FDCW100VNX FDCW140VNX Height 1300 Width (+67 with valve cover) Depth (+80 with foot rail) (+80 with foot rail) Weight Color Stucco White Sound Power level* dB(A) 64.5...
Page 289 '10 • HM-T-149A Control Start-up and inspection Checklist: Checks before commissioning Hot water Notes Checked Non-return valve Is it installed in right direction ? Safety valve Is it installed in cold water line ? Mixer valve Is it installed in right direction ? Heating Notes Checked...
Page 290 '10 • HM-T-149A System description Radiators - only heating Radiators - only heating HMA100V - FDCW100VNX (71VNX) 4-way valve 63H1 High pressure switch Compressor motor Current sensor EEV-C Expansion valve, cooling EEV-H Expansion valve, heating FMo1 Fan motor Low pressure sensor...
Page 291 '10 • HM-T-149A System description Principle of operation HMS140V (MT300)-FDCW140VNX Function Installation requirements The heat pump prioritises hot water charging. The compressor See page 9. output is adjusted according to the outdoor temperature. The circulation pump varies the flow to maintain a high charge temperature.
Page 292: Cooling Mode
'10 • HM-T-149A System description Underfloor heating and cooling Underfloor heating and cooling 4-way valve 63H1 High pressure switch Compressor motor Current sensor EEV-C Expansion valve, cooling EEV-H Expansion valve, heating FMo1 Fan motor Low pressure sensor Tho-A Temperature sensor, outdoor air Tho-D Temperature sensor, hot gas Tho-R1...
Page 293 '10 • HM-T-149A System description Fan convectors - heating and cooling Fan convectors - heating and cooling 4-way valve 63H1 High pressure switch Compressor motor Current sensor EEV-C Expansion valve, cooling EEV-H Expansion valve, heating FMo1 Fan motor Low pressure sensor Tho-A Temperature sensor, outdoor air Tho-D...
Page 294 '10 • HM-T-149A System description Dual system - heating and cooling Dual system - heating and cooling 4-way valve 63H1 High pressure switch Compressor motor Current sensor EEV-C Expansion valve, cooling EEV-H Expansion valve, heating EP21-BT2 Temperature sensor, supply 2 FMo1 Fan motor EP21-BT3...
Page 295 '10 • HM-T-149A System description Underfloor heating and fan convectors- heating and cooling Underfloor heating and fan convectors- heating and cooling 4-way valve 63H1 High pressure switch Compressor motor Current sensor EEV-C Expansion valve, cooling EEV-H Expansion valve, heating EP21-BT2 Temperature sensor, supply 2 FMo1 Fan motor...
Page 296 '10 • HM-T-149A Service Operation control function by the indoor unit controller Protection control Current protection 1) Maximum current limit control for the outdoor unit (by indoor unit control) When the operation current of the outdoor unit comes close to the limit, request compressor speed is retained in order to keep the current.
Page 297 '10 • HM-T-149A Service Alarm list Alarm list Alarm with automatic reset Alarm Alarm text on the Triggers alarm Resets alarm display When condenser supply (BT12) is less than 5°C. When condenser supply is greater than 14°C. Low condenser out High KF When condenser supply is greater than 60°C and When condenser supply is lower than 51°C.
Page 298 Air in the system. Dirt in the pump. - Open and clean the pump. Worn bearings. - Replace the pump. Technical specifications Circulation pump <HMS140V> <HMA100V, HMA100VM> Max pressure height Max pressure height Max volume flow 3000ℓ/h Max volume flow 3500ℓ/h Min/max temperature -10 °C* to +95 °C...
Page 299: Electrical Installation
■ If the building is equipped with an earth-fault breaker, Hydrolution should be equipped with a separate one. Electrical components ■ Connection must not be carried out without the permission <HMA100V, HMA100VM> of the electricity supplier and under the supervision of a qualified electrician. 5.5 mm ■...
Page 300 '10 • HM-T-149A Installation Indoor unit installation <HMS140V> <MT300> BT30 - FD1 X101 X100 <MT500> AA22 BT30 - FD1 S1 109 X101 -X101 -X100 X100 Explanation Symbol Type Scale length of <HT30> conductor (mm) HMA100 HMS140 X100 AA22 X101 Cable gland Cable gland BT30 - FD1 Terminal block, incoming...
Page 301 The temperature limiter (FD1) cuts the current supply to the markings. electrical heater if the temperature rises up between 90 and 100°C and can be manually reset. <HMA100V, HMA100VM> 400 V 3NAC Resetting 400 V 3NAC The temperature limiter (FD1) is accessible behind the front cover.
Page 302 '10 • HM-T-149A Installation Indoor unit installation Contact for changing the room temperature External mixing valve (EP21-QN11, accessory) An external contact such as a room thermostat or a timer can Connection and function are described in the Installation be connected to indoor unit to change the flow temperature and instructions for accessory ESV 22.
Page 303 Close the filling valve (QM1). QM20 6. Open the valve to expansion vessel when air vent is completed (HMS140V only). <HMA100V, HMA100VM> QM20 Venting the climate system 1. Vent indoor unit through the safety valve (FL2) and the rest of the heating system through the relevant venting valves.
Page 304 '10 • HM-T-149A Installation Start-up and inspection Checking external heat source controlled by the signal from indoor unit 1. Check if the signal wire is connected as instructed. 2. Select “Ext. 1 step” in Menu 9.2.8. 3. Select operating mode “Add. heat only” by holding in the operating mode button for 7 seconds.
Page 305 Air-Conditioning & Refrigeration Systems Headquarters 16-5, Konan 2-chome, Minato-ku, Tokyo, Japan Fax : (03) 6716-5926 Because of our policy of continuous improvement, we reserve the right to make changes in all specifications without notice. © Copyright MITSUBISHI HEAVY INDUSTRIES, LTD.
