FP Postbase Mini Operator's Manual page 16

16
PostBase Mini
Test print (example)
• Lower the operating panel back into posi-
tion.
PostBase Mini calibrates the cartridge ...
... and prompts you to perform a test print.
• Place an empty envelope at the right hand
edge of the letter slot and push in as far as
it goes.
As soon as the sensor (in the back right hand
corner of the letter slot) detects the envelope,
the PostBase Mini grips the envelope tightly
and prints the test print.
• On the test print, determine the numbers
where
– the horizontal lines are as exactly next to
each other as possible and
– the vertical partial lines are as exactly
above each other as possible.
The ink cartridge is correctly aligned when
horizontal and vertical partial lines form one
line each at number 5.
• Confirm with the
When horizontal and / or vertical partial lines
do not form one line each at number 5:
• Press to continue the procedure of ink
cartridge alignment.
button.
