Icons
Indicates video loss
Indicates motion detection alarm
Indicates the current channel is recording. The recording may have been started
manually, from a schedule, motion detection, alarm, and/or triggered from
motion and alarm.
Indicates exception alarm and recording.
Use the Right Button of the Mouse in Live View
Item
Menu Enter main menu
The channel chosen will spread the whole screen. You could also reveal this
Single Screen
function by double clicking the channel
Sub Screen Ctrl Switch to sub screen to operate(only for MS-N8000 series)
Previous Screen Switch to the previous screen
Next Screen Switch to the next screen
Sequence Enable single/multi-screen cruise in live view mode
Sub Sequence Enable single/multi-screen cruise for sub screen(only for MS-N8000 series)
Logout Click it to log out current user account
Quick Operation for Live View
Enter the live view interface; left click the channel, the quick menu will appear. Quick menu
operations include recording manually, snapshot, PTZ, audio, digital zoom, and image
configuration.
Quick Menu Instructions for Main Output Live View
