  • Page 1 Network Video Recorder User Manual V5.02...
  • Page 2 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measures are divided into “Warnings” and “Cautions” Warnings: Serious injury or death may be caused if any of these warnings is neglected. Cautions: Injury or equipment damage may be caused if any of these cautions are neglected.
  • Page 3 Cautions Make sure that the power supply voltage is correct before using the camera Do not store or install the device in extremely hot or cold temperatures, dusty or damp locations, and do not expose it to high electromagnetic radiation Only use components and parts recommended by manufacturer Do not drop the camera or subject it to physical shock To prevent heat accumulation, do not block air circulation around the camera...

  • Page 4: Table Of Contents

    Contents 1. Product Introduction ........................7 1.1 Introduction .......................... 7 1.2 Product Key Functions ......................7 2. Hardware ............................10 2.1 Panel Buttons........................10 2.2 Using a USB Mouse ......................13 2.3 Hard Disk Installation ......................13 2.3.1 MS-N7000 series Hard Disk Installation..............13 2.3.2 MS-N8000 series Hard Disk Installation..............
  • Page 5 3.7.1 General ........................62 3.7.2 Network ........................62 3.7.3 Disk Management ....................69 3.7.4 Holiday ........................71 3.7.5 User ......................... 72 3.7.6 Upgrade ........................74 3.7.7 Save/Load Configuration ..................74 3.7.8 Maintenance ......................76 3.7.9 Auto Reboot ......................76 3.8 Status ..........................77 3.8.1 Device Information ....................
  • Page 6 4.6.5 Event Status ......................130 4.6.6 Packet Capture Tool ....................130 4.7 Logs ..........................131 4.8 Logout ..........................131 5. Services ............................132...

  • Page 7: Product Introduction

    1. Product Introduction 1.1 Introduction Based on embedded Linux operation system, Milesight NVR Series manages and stores HD video data. It owns multi-disc management systems, front end HD device management system, HD video analysis system and high-capacity system for video. Also, it adopts the technology of high flow capacity data network transmitting &...
  • Page 8 HDD Management Support S.M.A.R.T technology. Support RAID technology. Recording/Snapshot and Playback Support holiday schedule. Support recycle and non-recycle recording mode. Support multiple recording types, including timing, alarm, motion detection, motion or alarm, motion and alarm, etc. Support 12 recording time periods with separate recording types. Support pre-record and post-record time for motion detection, alarm recording, motion and alarm recording, motion or alarm recording.
  • Page 9 Network Support remote search, playback and download of video files. Support remote acquiring and configuring of parameters. Support remote import and export of device parameters. Support P2P remote access. Support IPv4 and IPv6. Support remote acquiring of device status, system log and alarm status. Support remote operate system maintenance by format of hard disk, upgrade and auto reboot, etc.

  • Page 10: Hardware

    2. Hardware 2.1 Panel Buttons Model Hardware/Interface UI-1009-A (Firmware version: 71.xx.xx.xx): 4K H.265 Mini NVR 1000 Series UI-1009-NA: UI-5016-B: 4K H.265 Pro NVR 5000 Series...
  • Page 11 UI-5032-B: UI-7016-B/UI-7032-B: 4K H.265 Pro NVR 7000 Series UI-8032-B: 4K H.265 Pro NVR 8000 Series...
  • Page 12 UI-1009-PA: UI-5016-PB: 4K H.265 PoE NVR Series UI-7032-PB:...

  • Page 13: Using A Usb Mouse

    2.2 Using a USB Mouse Item Click Description Live view: select the channel and show the toolbar of live view. Single- click Menu: select and confirm. Switch between single screen to multi-screen when in live view Double-click mode and playback mode. Left Button (1) Control rotation direction in PTZ mode.

  • Page 15: Ms-N8000 Series Hard Disk Installation

    2.3.2 UI-8000 series Hard Disk Installation Step1. Unscrew the back and both sides’ screws to open the upper lid. Step2. Uninstall the upper hard disk panel. Step3. Install the hard disks into NVR with screws shown in below pictures.(SATA slots of hard disks should be toward inside NVR) Step4.
  • Page 16 Note: 1. The SATA slots are in SHORT HALF side and the SATA slot toward inside NVR. 2. The data connector sequence of UI-7000 series is different from UI-8000 series’.

  • Page 17: Local Operation

    3. Local Operation 3.1 Wizard Setting By default, the Setup Wizard will start once the NVR has been loaded. You can click check-box to turn off the Wizard when startup. The Setup Wizard will guide you to complete important settings, which makes NVR more user-friendly. Step1.
  • Page 18 Step2. Date and time setting Select the Time Zone and date via NTP or you can set date and time manually. Step3. Network setting Input the IP Address, Subnet Mask, Gateway and Preferred DNS Server. Internal NIC IPv4 Address option is only for PoE NVR Series.
  • Page 19 Step4. Disk Management Automatically detect the hard disk installed in NVR, and it supports formatting hard disk. You can create RAID in this page as well. Note: RAID is only supported on Pro NVR 7000 series, PoE NVR 7000 series and Pro NVR 8000 series Click to set up RAID for selected disk.
  • Page 20 Step6. Record The user can start all channels recording by clicking Step6. Login Input the user name and password to login the system.

  • Page 21: Live View

    3.2 Live View 3.2.1 Live View Main Menu and Tool Bar can pop up and hide automatically at the right side or bottom of the interface. Icons Descriptions Icons Descriptions Lock/Unlock the tool bar One screen layout 4 screen layout 8 screens layout 1+7 screens layout 9 screens layout...
  • Page 22 Icons Descriptions It indicates video loss It indicates motion detection alarm It indicates that the current channel is recording. Right click in the Live View and the quick operation menu pops up. Item Descriptions Menu Display Main Menu The selected channel will be full screen. You could go back to previous screen layout Single Screen Sub Screen Ctrl Switch to sub screen to operate (Only for Pro NVR 8000 Series)
  • Page 23 Close menu Fisheye Mode: Click to expand Fisheye Mode panel, then set installation mode and display mode for Milesight Fisheye camera. Installation Mode: Ceiling Mount/ Wall Mount/ Table Mount Display Mode: Fisheye View/ 360 Panorama View/ 180 Panorama View/ 4PTZ/ Fisheye + 3PTZ/...

  • Page 24: Layout

    3.2.2 Layout Step1. Select a layout format. Step2. Set desired channels. Click to close a channel. Select a window and then select a desired channel to add in. Click to save the settings or click to reset the layout.

  • Page 25: Playback

    3.3Playback 3.3.1 Video Playback Playback supports to playback video according to recorded time and to play recorded video files in specified time period. Synchronous playback of multi-channel is supported. Step1. Select screen layout, channels date and recording type. Select playback layout and channels. User can click for quick selecting channels.
  • Page 26 Video Playback Tool Bar Description The tool bar can display multi-event record. It shows that in this record period what kind of event has happened. The symbolic meaning of each color is: Blue—Timing Green --- Motion --- Alarm Purple --- Emergency And take this bar above as an example, it means that in this recording period, timing and motion event have been triggered.

  • Page 27: Video Files Backup

    3.3.2 Video Files Backup Recorded files can be backed up by various devices, including USB flash drives (USB flash disk, USB HDD, USB writer) and eSATA, etc. Step1. Select Recorded files. Select the channel and date you want to backup, then select the start time at timeline and click it will change into which means cut begins.
  • Page 28 Step2. Click , select Backup media and click Step3. The window will prompt: Please wait… Step4. When all backup files have been exported, ‘Backup Successfully’ will be prompted. Note: The download time of files depends on the time length of video you want to backup.

  • Page 29: Picture Playback

    3.3.3 Picture Playback Step1. Search and look for the snapshot files saved in HDD by selecting channels, start time and end time, click...
  • Page 30 Step2. Enter Picture Info List and look up the pictures. Click to play the selected picture, or click to auto play pictures. Icons Descriptions Icons Descriptions Play backward Play Previous picture Next picture Download picture Back to search interface...

  • Page 31: Picture Files Backup

    3.3.4 Picture Files Backup Step1. Select pictures you want to backup in picture playback interface. Step2. Click and select backup media to save picture.

  • Page 32: Camera Settings

    Method1. Add camera through Device Search interface. ‘Settings’ à ‘Camera’ à ‘Device Search’. 1. Select IP Range, NIC and Protocol, which includes ALL, ONVIF and MSSP. MSSP: You can search out all Milesight camera which has different network segment in the LAN.
  • Page 33 2. Click button to search cameras at the same LAN with NVR. 3. Select one channel, click button, input password and click button to finish.
  • Page 34 TCP or UDP transport protocol for it. Click to finish batch adding. Note: The steps for adding the third party PoE cameras plugged into Milesight PoE NVR: ① Set camera’s IP segment to the same as NVR PoE NIC before plugging to PoE NVR;...
  • Page 35 RTSP: You can add any IP cameras with RTSP protocol streams (Port: 554). It needs you to input complete resource path of the IP camera to add it. Take Milesight device for example, the resource path of main stream is “rtsp://IP:port/main” and secondary stream is...
  • Page 36 MSSP: You can add Milesight cameras which are in the same LAN with MSSP protocol. Step2. Check the connection status. After adding the IP channels, click button on Camera Management interface, then appears under Status. If it doesn’t appear, you need to check if the network is connected or whether the user name or password is correct or not.
  • Page 37 Select Parameters page to re-edit parameters of this channel. Click [OK] to save the configuration. Batch configuring camera Click , select multiple channels and set parameters of cameras.
  • Page 38 Step4. Delete camera. You can delete this channel by clicking , or you can select multiple devices and then click to delete. Step5. Configure PoE Channel (Only for PoE NVR) 1. Connect camera to PoE port, it will detect the camera automatically. 2.

  • Page 39: Device Search

    3.4.2 Device Search Select Protocol and NIC, then set the IP range, and click to quickly search the IP devices that support selected protocol at the same LAN with NVR. Select channels and batch editing their IP information.

  • Page 40: Ptz Configuration

    3.4.3 PTZ Configuration Advanced Choose a channel and set the PTZ parameters. Besides, you can click to copy the same configuration to other channels. Note: 1. Settings for a PTZ camera must be configured before it can be used. Make sure that the PTZ and RS-485 of the NVR are connected properly.
  • Page 41 Configuration [Preset] Preset can be set to move your PTZ camera to a desired preset position. The preset position is the preparation for Patrol. Step1. Use the PTZ direction key to rotate the position of preset. Then choose a preset number and click to save a preset position.
  • Page 42 Step2. Click to add preset position (up to 48 positions could be added). Set the parameters of preset positions, including preset position number, scan time and scan speed, then click Step3. Select a preset position, click and select in the dialog box to delete it. Step4.
  • Page 43 [Pattern] The camera will patrol back and forth in a constant speed. There is only one start point and one end point. Step1. Select a pattern and click . Up to 4 patterns could be set. Step2. Drag the mouse or click 8 direction keys by mouse to rotate PTZ. Step3.

  • Page 44: Privacy Mask

    3.4.4 Privacy Mask Milesight NVR supports to set privacy mask. It is used to cover some privacy area which is not proper to appear on monitor. You can add a privacy mask by following steps: Step1. Select channel and enable privacy mask.

  • Page 45: Osd Configuration

    3.4.5 OSD Configuration You can set OSD (On Screen Display) on NVR, and the OSD will be synchronized to Camera. Step1. Select channel. Step2. Select Video Stream, including All Streams, Primary Stream and Secondary Stream. Step3. Enable video title and timestamp. Show Video Title: Enable it and the video title will be shown on screen.

  • Page 46: Image Enhancement

    3.4.6 Image Enhancement You can set Image Enhancement on NVR, and the configuration will be synchronized to Camera. Step1. Select channel. Step2. Set the configuration. Day/Night Mode: Set the Day/Night mode for the channel. Day to Night Value: Set the Minimum illumination intensity to trigger Night Mode. Night to Day Value: Set the Maximum illumination intensity to trigger Day Mode.

  • Page 47: Record

    3.5 Record 3.5.1 Preparation for Record Step1. Ensure your NVR has been installed and the HDD has been initialized, please check it on “Settings” -> ”Disk Management” interface. Step2. Ensure that the HDD has sufficient storage space. Double click the Recycle Mode and select it to ON.

  • Page 48: Preparation For Record

    3.5.2 Record Shedule Step1. Select channel. Step2. Set record schedule. Method 1: Click to edit schedule. Select Day, Record Type and Time to finish editing. Method 2: Select operation type: Timing, Motion, Alarm, Motion&Alarm or Erase. Then drag a square in the time table to set record effective time.
  • Page 49 Step3. Click to copy the same record configuration to other channels. Batch Settings Step1. Click to enter Batch Settings interface. Step2. Select channels and click to start always record. Step3. Select channels and click to stop record.

  • Page 50: Advanced

    3.5.3 Advanced Make advanced configuration for selected channels. Click to copy the same configuration to other channels.. Channel: Select the channel which will be set. Pre Record : Enable/Disable pre-record. It will start recording before the event is triggered. Duration Time: Event pre-record duration time. Post Record: Enable/Disable post record.

  • Page 51: Event Settings

    3.6 Event Settings 3.6.1 Motion Detection Step 1. Enable Motion Detection. Select channel , Sensitivity and click to enable Motion Detection. Step2: Set the area for triggering motion detection. You can set the area by dragging a square on live view window. Note: The motion detection area will be synchronized to Camera.
  • Page 52 Step 3. Set Action for motion detection alarm by clicking Record: Record when alarm is triggered. The user can set effective schedule as following two ways: ① Select the operation type: Motion, Motion&Alarm or Erase. Then drag a square on the time table for time setting, it will be more convenient by clicking to set or clear all time settings.
  • Page 53 Email Linkage: NVR will send an email to the address you set before. The user can set effective schedule as following two ways: ① Select the operation type, Email and Erase. Then drag a square on the time table for time setting, it will be more convenient by clicking to set or clear all time settings.
  • Page 54 Alarm Output: Trigger alarm output when alarm is triggered. Others: Trigger other channels record when alarm is triggered. Step 5. Click to copy the same configuration to other channels.

  • Page 55: Video Loss

    3.6.2 Video Loss Step1. Select a channel. Step2. Set Action for video loss by clicking Audible Warning: NVR will trigger an audible beep when motion is detected. The user can set effective schedule as following two ways: ① Select the operation type: Email or Erase. Then drag a square on the time table for time setting, it will be more convenient by clicking to set or clear all time settings.
  • Page 56 Email Linkage: NVR will send an email to the address you set before. User can set effective schedule as following two ways: ① Select the operation type: Email or Erase. Then drag a rectangle on the time table for time setting, it will be more convenient by clicking to set or clear all time settings.

  • Page 57: Alarm Input

    3.6.3 Alarm Input Alarm Input function is supported by UI-5016-B, UI-7016-B, UI-7032-B, UI-8032-B, UI-5016-PB, and UI-7032-PB. Step1. Set Alarm input Number, Alarm Name and Alarm Type. Alarm Input No.: The channel which has input signal. Alarm Name: Set a name for the alarm. Alarm Type: Choose NO or NC alarm type for the alarm.
  • Page 58 Audible Warning: NVR will trigger an audible beep when alarm is triggered. User can set effective schedule as following two ways: ① Select the operation type: Audible or Erase. Then drag a square on the time table for time setting, it will be more convenient by clicking to set or clear all time settings.

  • Page 59: Alarm Output

    Alarm Output: Trigger alarm output when alarm is triggered. PTZ Action: Trigger PTZ action when alarm is triggered. PTZ action includes Preset and Patrol. User can set effective schedule as following two ways: ① Select the operation type: Email or Erase. Then drag a square on the time table for time setting, it will be more convenient by clicking to set or clear all time settings.
  • Page 60 3.6.4 Alarm Output Alarm Output function is supported by UI-5016-B, UI-7016-B, UI-7032-B, UI-8032-B, UI-5016-PB, and UI-7032-PB. Step 1. Set Alarm output channel, Alarm Name, Alarm Type and Record Channels. Alarm Output No.: The channel which will output the alarm signal. Alarm Name: Set a name for the alarm.

  • Page 61: Exception

    Step3: Copy alarm output settings to other output interface by clicking 3.6.5 Exception Step1. Select Exception Type. Network Disconnected: Loss of network. HDD Full: HDD full. It usually happens when recycle Mode is OFF. Record Failed: Recording fails, including HDD Failed, HDD Full and so on. HDD Failed: Failed to recognize HDD.

  • Page 62: Settings

    3.7 Settings 3.7.1 General It is to setup the general parameters of NVR, including Device Name, Device ID, HDMI Resolution, Language, System time, etc. Event Popup Duration Time: The display duration time for Motion Detection popup screen. Boot Wizard: Enable it to pop up boot wizard after rebooting. Local Authentication: Enable it to authenticate the user after rebooting.

  • Page 63: Network

    3.7.2 Network 3.7.2.1 Basic The system supports two IP address format: IPv4 and IPv6 IPv4 Enable IPv4 DHCP to auto search IP. When enable DHCP function, you can not modify IP/ Subnet mask/ Gateway. Disable IPv4 DHCP to modify IP/ Subnet mask/ Gateway manually. IPv6 Manual/ Router Advertisement/ DHCPv6 are available.
  • Page 64 Check DDNS check-box to enable it, then select a DDNS Server and input the user name, password and host name. Do not forget to save the configuration. Milesight has its own DDNS server. Please do port forwarding for HTTP port and RTSP port before enabling Milesight DDNS.
  • Page 65 3.7.2.4 Email Email will send receivers a screenshot when the alarm is triggered. User name: The E-mail address you choose to send emails. Please input full email address into it. Password: The password of the E-mail. SMTP Server: The SMTP Server of your E-mail. SMTP Port: The port of SMTP Server, it’s usually 25.
  • Page 66 Failed to initialize P2P Unactivated P2P is disabled Unknown error Other error Note: 1. Please make sure that NVR is available for internet before enabling. 2. If your NVR firmware version is not 7x.7.0.9-r2 or above, please contact Milesight to registered P2P first.
  • Page 67 3.7.2.6 SNMP SNMP is an abbreviation of Simple Network Management Protocol, which is convenient for NVR to be monitored and managed in the whole network environment. The SNMP is widely used in many network devices, software and systems. Before setting the SNMP, please download the SNMP software and manage to receive the NVR information via SNMP port.
  • Page 68 Secure Shell (SSH) has many functions; it can replace Telnet, and also provides a secure channel for FTP, POP, even for PPP. Note: The default SSH port is 22. Only for Milesight R&D debugging. HTTP Port The default HTTP port is 80. Please modify HTTP ports according to actual application.

  • Page 69: Disk Management

    3.7.3 Disk Management 3.7.3.1 Disk Configuration Select a disk and click to format the disk, set the recycle mode by double clicking the Mode. After that the disk will be ready. HDD Type: RAID* means RAID while LOCAL means normal disk mode. Recycle Mode: Enable recycle mode to enable the recycle for full disk.
  • Page 70 RAID Mode RAID (Redundant Array of Independent Disks) is a storage technology that combines multiple disk drive components into a logical unit. A RAID setup stores data over multiple hard disk drives to provide enough redundancy so that data can be recovered if one disk fails. Step1.

  • Page 71: Holiday

    3.7.3.2 S.M.A.R.T Detection S.M.A.R.T detection is a monitoring system of HDD that detects anticipating failures of HDD and reports them with various indicators. Test Type: Fast and Full are available. Self-evaluation: If the HDD is in good condition, it will pass the self-evaluation. 3.7.4 Holiday It can configure the record or image capture schedule for holidays of the current year.

  • Page 72: User

    3.7.5 User Note: 1. If the NVR firmware version out of the factory is xx.7.0.6 or above, the default user name is “admin” and the default password is “ms1234”; 2. If the NVR firmware is upgraded to xx.7.0.6 or above from a lower version, the default password will turn to “ms1234”...
  • Page 73 Edit user Select a user, when the background color changes into dark gray, click to edit user privileges. ① Local Privilege means that the privilege to the monitor connected with NVR. ② Remote Privilege means that the privilege to web settings. Click to modify password.

  • Page 74: Upgrade

    3.7.6 Upgrade Step1. Search for USB device, and select the corresponding firmware. Step2. Click confirm the upgrade. Note: The system will auto reboot after confirming upgrade. 3.7.7 Save/Load Configuration Backup/Restore Backup: Select a folder and then click to export configuration to USB device.
  • Page 75 Restore: Select a .cfg file and then click to import configuration to your NVR. Reset All parameters can be reset to default settings by clicking...

  • Page 76: Maintenance

    3.7.8 Maintenance The NVR will automatically delete your logs and photos after the retention period or permanently keep the Log and Photo according to your configuration. Permanent, 1 Month, 2 Months, 4 Months, 6 Months, 8 Months, 10 Months and 12 Months are available for these two options.

  • Page 77: Status

    3.8 Status You can have a quick view of the information of the device, network, camera, disk and event. This part is only for your rapid reference. If you want to make any configuration, please go to corresponding parts accordingly. 3.8.1 Device Information Device Information includes Device ID, Model, MAC Address, Hardware Version, Software Version, and Uptime.

  • Page 78: Camera Status

    3.8.3 Camera Status Camera Status includes Channel, Name, IP Address, Record, Frame Rate, Bit Rate, Frame Size and Status. PoE Port Status is only for PoE NVR, it will show you the current power and connection status of PoE ports. 3.8.4 Disk Status Disk Status includes Port, Vendor, Status, Total(GB), Free(GB), HDD Type, In Use and Recycle Mode.

  • Page 79: Event Status

    3.8.5 Event Status Alarm The user can check Alarm Input and Output list here if NVR has corresponded interface. will turn into when the corresponding alarm is triggered. Camera Event The user can check Camera Event here, including Video Loss, Motion and I/O. will turn into when the corresponding alarm is triggered.

  • Page 80: Logs

    3.8.6 Logs The user can check, search and export logs in Logs interface. By selecting the Start Time, End Time, Main Type and Sub Type, which can narrow down the scale of logs, you can search for logs that you need.

  • Page 81: Logout

    3.9 Logout Logout: Exit the current login account. Reboot: Restart the NVR. Shutdown: Close the NVR.

  • Page 82: Web Settings

    4. WEB Settings 4.1 Login Select Language on the top-right of interface. Input the user name, password and click Login to login NVR web page. Note: 1. If the NVR firmware version out of the factory is xx.7.0.6 or above, the default user name is “admin”...

  • Page 83: Menu

    4.2 Menu Icons Descriptions Hide or show secondary menu Live view Play back the video Make settings for Camera, Record, Event and System Check Device Information, Network Status, Camera Status, Disk Status and Event Status Check all operation logs Log out NVR...

  • Page 84: Live View

    4.3Live View 4.3.1 Camera List List and play added cameras on Camera List page. Select one window one camera to play. Or click to get all cameras’ live video. Icons Descriptions Icons Descriptions Play Primary Stream Play Secondary Stream Save View Play default view 1 screen mode 4 screens mode...

  • Page 85: Ptz

    4.3.2 PTZ Operating PTZ, Preset, Patrol and Pattern on PTZ page. 4.3.3 Image Configuration Adjust image Brightness, Contrast, Saturation, Sharpness and Noise Reduction Level on Image Configuration page.

  • Page 86: Playback

    4.4 Playback To play and backup the recorded files. 4.4.1 How to playback It supports playback according to recorded time. Play recorded files in specified time period. Step1. Select channel and date. Step2. Select record types: Timing, Motion Detection or Emergency. Step3.
  • Page 87 Video Playback Tool Bar Description The tool bar can display multi-event record. It shows that in this record period what kind of event has happened. The symbolic meaning of each color is shown below: Blue—Timing Green --- Motion --- Alarm Purple --- Emergency And take this bar above as an example, it means in this recording period, timing and motion event...

  • Page 88: Video Files Backup

    4.4.2 Video Files Backup Recorded files can be cut and backed up from WEB. Step1. In playback interface, select camera, the date and time to playback. Step2. Select Recorded files for Backup. Click , then select start time and end time by dragging the vertical line on the time bar. Step3.

  • Page 89: Picture Files Backup

    4.4.3 Picture Files Backup Step1. Browse a file path in Local Configuration interface. Step2. Pause first when you want to backup a special scene during video playback. Step3. Click to save the picture.Then the backup picture can be found in the files path you set before.

  • Page 90: Settings

    4.5 Settings 4.5.1 Local Configuration Local Configuration includes Record File Path, Preview Picture Path, Playback Preview Path, Connection Type, Play Mode and Primary Stream When Fullscreen option. 4.5.2 Camera Before configuration, please ensure that camera is connected to the same network as your NVR and the network setting for your NVR is properly setup.
  • Page 91 Method1. Add IP Channel in Device Search interface. ‘Settings’ à ‘Camera’ à ‘Device Search’. 1. Select IP Range, NIC and Protocol, which includes ALL, ONVIF and MSSP. MSSP: You can search out all Milesight camera which has different network segment in the LAN. 2. Click...
  • Page 92 Note: The steps for adding the third party PoE cameras plugged into Milesight PoE NVR: ① Set camera’s IP segment to the same as NVR PoE NIC before plugging into PoE NVR; ② Select PoE for NIC in Device Search interface, click to search out cameras;...
  • Page 93 RTSP: You can add any IP cameras with RTSP protocol streams (Port: 554). It needs you to input complete resource path of the IP camera to add it. Take Milesight device for example, the resource path of main stream is “rtsp://IP:port/main” and second stream is...
  • Page 94 MSSP: You can add Milesight cameras which are in the same LAN with this protocol. Step2. Check the connection status. After adding the IP channels, click on Camera Management interface, then appears under Status. If it doesn’t appear, you need to check if the network is connected or whether the user name, password is correct or not.
  • Page 95 You can delete this channel by clicking , or you can select multiple devices and then click to delete. Batch configuring camera Click , select multiple channels and set cameras parameters. Note: The user name and password entered here are the default user name and password. The management port is 80 and the default Transport protocol is UDP.
  • Page 96 Step5. Configure PoE Channel(Only for PoE NVR) 1. Connect camera to PoE port, it will detect the camera automatically. 2. If the camera's password is "ms1234", it will be successfully authenticated and be changed into the same network segment with internal NIC IPv4 address, then the camera will be connected successfully.
  • Page 97 4.5.2.2 Device Search Select Protocol and NIC, set the IP range, then click to quickly search the IP devices that support selected protocol at the same LAN with NVR. Select channels and batch editing their IP information.
  • Page 98 4.5.2.3 PTZ Configuration Select a channel and set the PTZ parameters. You can select [Copy to Camera] to copy the same configuration to other channels. Note: 1. The PTZ protocol and address of IP channel must be consistent with those of the PTZ decoder.
  • Page 99 4.5.2.4 Privacy Mask Milesight NVR support to set privacy masks. It is used to cover some privacy area which is not proper to appear on monitor. You can add a privacy mask by following steps: Step1. Select channel and enable privacy mask.
  • Page 100 4.5.2.5 OSD Configuration You can set OSD (On Screen Display) on NVR, and the OSD will be synchronized to Camera. Select channel and finish the info and save. [Video Stream]: Select stream. All Streams, Primary Stream and Secondary Stream are available. [Show Video Title]: Enable it and the video title will be shown on screen.
  • Page 101 4.5.2.6 Image Enhancement You can set Image Enhancement on NVR, and the configuration will be synchronized to Camera. Step1. Select channel. Step2. Set the configuration. Day/Night Mode: Set the Day/Night mode for the channel. Day to Night Value: Set the Minimum illumination intensity to trigger Night Mode. Night to Day Value: Set the Maximum illumination intensity to trigger Day Mode.

  • Page 102: Record

    4.5.3 Record Preparation for Configuration Step1. Ensure your NVR has installed and initialized the HDD. Step2. Ensure that the HDD has sufficient storage space. Select [Recycle Mode] to "ON" in the case of insufficient capacity of HDD on Disk Management interface .
  • Page 103 4.5.3.1 Record Schedule Record Schedule Step1. Select Record Schedule. Step2. Select the desired channel. Step3. Set record schedule. Select record type includes Timing, Motion Detection, Alarm and Motion&Alarm, then set the time you want to record. It is convenient for you to set all or clear all schedule by clicking Also, you can click the time bar and reedit the record time...
  • Page 104 Click [Copy to Camera] to copy the same configuration to other channels. Batch Settings Record and Stop are available for user to set or clear always record schedule for selected channels.
  • Page 105 4.5.3.2 Advanced Make advanced configuration for selected channels. Click [Copy to Camera] and to copy the same configuration to other channels. Channel: Select the channel which will be set. Pre Record : Enable/Disable pre-record. It will start recording before the event is triggered. Duration Time: Event pre-record duration time.

  • Page 106: Event

    4.5.4 Event 4.5.4.1 Motion Detection Step 1. Enable Motion Detection. Select channel , Sensitivity and click to enable Motion Detection. Step2: Set the area for triggering motion detection. You can select an area by dragging the mouse to set the trigger area, and this area will be synchronized to camera.
  • Page 107 Step 3. Set Action for motion detection alarm by clicking Record: Record when an alarm is triggered. Select the operation type: Motion or Motion&Alarm. Then drag a line on the time table for time setting, it will be more convenient by clicking to set or clear all time settings.
  • Page 108 Email Linkage: NVR will send an email to the address you set before. Drag a line on the time table for time setting, it will be more convenient by clicking to set or clear all time settings. What’s more, you can click time bar to edit the time accurately. Click to copy time setting to other day.
  • Page 109 Step 5. Click [Copy to Camera] and to copy the same configuration to other channels. 4.5.4.2 Video Loss Step1. Select a channel Step2. Set Action for video loss. Audible Warning: NVR will trigger an audible beep when alarm is triggered. Drag a line on the time table for time setting, it will be more convenient by clicking to set or clear all time settings.
  • Page 110 Email Linkage: NVR will send an email to the address you set before. Drag a line on the time table for time setting, it will be more convenient by clicking to set or clear all time settings. What’s more, you can click time bar to edit the time accurately. Click to copy time setting to other day.
  • Page 111 4.5.4.3 Alarm Input Alarm Input function is supported by UI-5016-B, UI-7016-B, UI-7032-B, UI-8032-B, UI-5016-PB, and UI-7032-PB. Step1. Set Alarm input Number, Alarm Name and Alarm Type. Alarm Input No.: The channel which has input signal. Alarm Name: Set a name for the alarm. Alarm Type: Choose NO or NC alarm type for the alarm.
  • Page 112 Audible Warning: NVR will trigger an audible beep when alarm is triggered. Trigger Interval: The effective interval between two actions when event triggered. Click [Copy to Alarm] and to copy the same configuration to other channels. Email Linkage: NVR will send an email to the address you set before. Trigger Interval: The effective interval between two actions when event triggered.
  • Page 113 4.5.4.4 Alarm Output Alarm Input function is supported by UI-5016-B, UI-7016-B, UI-7032-B, UI-8032-B, UI-5016-PB, and UI-7032-PB. Step 1. Set Alarm output channel, Alarm Type, Delay and Alarm Name. Alarm Output No.: The channel which will output the alarm signal. Alarm Type: Select alarm type: NO or NC. Delay: Set the output time for alarm.
  • Page 114 4.5.4.5 Exception Step1. Select Exception Type. Network Disconnected: Loss of network. HDD Full: HDD full, it usually happens when Recycle Mode is OFF. Record Failed: Recording fails, including HDD Failed, HDD Full and so on. HDD Failed: Failed to recognize HDD. HDD Unformat: HDD is unformat.

  • Page 115: System

    4.5.5 System 4.5.5.1 General Settings To setup the general parameters of NVR, including modify the Device Name, Device ID, set system time manually and auto logout, etc. 4.5.5.2 Network 4.5.5.2.1 Basic The system supports two IP address format: IPv4 and IPv6 IPv4 Enable IPv4 DHCP to auto search IP.
  • Page 116 Check DDNS check-box to enable it, then select a DDNS Server, input the user name, password and host name. Do not forget to save the configuration. Milesight has its own DDNS server. Please do port forwarding for HTTP port and RTSP port before enabling Milesight DDNS.
  • Page 117 4.5.5.2.4 Email Email will send receivers a screenshot when the alarm is triggered. User name: The E-mail address you choose to send emails. Please input full email address into it. Password: The password of the E-mail. SMTP Server: The SMTP Server of your E-mail. SMTP Port: The port of SMTP Server, it’s usually 25.
  • Page 118 Failed to initialize P2P Unactivated P2P is disabled Unknown error Other error Note: 1. Please make sure that NVR is available for internet before enabling. 2. If your NVR firmware version is not 7x.7.0.9-r2 or above, please contact Milesight to registered P2P first.
  • Page 119 4.5.5.2.6 SNMP SNMP is an abbreviation of Simple Network Management Protocol, which is convenient for NVR to be monitored and managed in the whole network environment. The SNMP is widely used in many network devices, software and systems. Before setting the SNMP, please download the SNMP software and manage to receive the NVR information via SNMP port.
  • Page 120 4.5.5.2.7 HTTPS Set in the interface to make sure getting access to NVR successfully via HTTPS, which is able to guarantee communication data security. The reliable and stable technology can secure the user information security and device safety. There are three certificate installation types: Create a Private Certificate Click “Create”...
  • Page 121 Direct Installation Click “Browse” to select a signed certificate locally and click “Install” to install it. Create a Certificate Request Firstly, click “Create” button. And then enter Country, Common Name and other information to create the certificate request; Download the certificate request and submit it to the trusted certificate authority for signature; After receiving the signed valid certificate, import the certificate to the device.
  • Page 122 Secure Shell (SSH) has many functions; it can replace Telnet, and also provides a secure channel for FTP, POP, even for PPP. Note: The default SSH port is 22. Only for Milesight R&D debugging. HTTP Port Setting The default HTTP port is 80. Please modify HTTP ports according to actual application.
  • Page 123 HTTPS Port The default HTTPS port is 443. Please modify HTTPS ports according to actual application. Note: 3. The default HTTPS port for IE browser is 443. 4. HTTPS port is used for remote network access for 4k/H.265 NVR Series. RTSP Port Setting Real Time Streaming Protocol (RTSP) is an application layer protocol in TCP/IP protocol system.
  • Page 124 4.5.5.3 Holiday It can configure the record or image capture schedule for holidays of the current year. Click to open holiday configuration page to modify holiday name, check the ‘Enable Holiday’ check-box, and then select [Type] to setup Start/End date. There are By0 Month, By Week, and By Date in [Type] mode.
  • Page 125 4.5.5.4 User Note: If the NVR firmware version out of the factory is xx.7.0.6 or above, the default user name is “admin” and the default password is “ms1234”; If the NVR firmware is upgraded to xx.7.0.6 or above from a lower version, the default password will turn to “ms1234”...
  • Page 126 Edit user Click a user, when the background color changes into blue, click to edit user privileges. ① Local Privilege means the privilege to the monitor connected with NVR ② Remote Privilege means the privilege to web settings. Click to change password. Delete user Select a user and click to delete a user.
  • Page 127 4.5.5.5 Maintenance Auto Maintenance You can set the Log and Photo Retention Period which is from 1 to 12 months or permanent. According to your configuration, the NVR will automatically delete your logs and photos after the retention period or permanently keep the Log and Photo. Reboot Click to reboot the NVR.

  • Page 128: Status

    Export Configuration File Click to backup current NVR settings. System Upgrade Click to select the firmware file, and you can check to reset configuration to factory defaults. Click to upgrade. Note: It will take 5 to 10 minutes to upgrade, please do not disconnect the device power during the process.

  • Page 129: Network Status

    4.6.2 Network Status Network Status includes three main parts: Receive Bandwidth, LAN1 and LAN2. 4.6.3 Camera Status Camera status includes Channel, Name, IP Address, Record, Frame Rate, Bit rate, Resolution and Status. 4.6.4 Disk Status Disk status includes Port, Vendor, status, Total(GB), Free(GB), Type, In Use and Recycle Mode. You also can check the Total Capacity (GB) and Free Capacity.

  • Page 130: Event Status

    4.6.5 Event Status Alarm Alarm shows the Alarm Input and Alarm Output status. turns into when alarm is triggered. Camera Event Camera Event shows camera event, including Video Loss, Motion and I/O. turns into when alarm is triggered. 4.6.6 Packet Capture Tool Input IP and Port,then click [Start] to start capture and click [End]to stop.

  • Page 131: Logs

    4.7 Logs In Log interface, you can check, search and export logs. By selecting the Main Type , Sub Type, Start Time and End Time which can narrow down the scale of logs, you can search for logs that you need and then export them locally.

  • Page 132: Services

    5. Services Milesight Technology Co., Ltd provides customers with timely and comprehensive technical support services. End-users can contact your local dealer to obtain technical support. Distributors and resellers can contact directly with Milesight for technical support. Technical Support Mailbox: support@milesight.com Web: http://www.milesight.com...
