Step2. Select a desired channel and date
Select playback layout and channel. Click the date in red when there are recorded files of the
selected channels, the record type with recording data will be show as below, and then click
to playback.
Note:
1. The day in red has recording files; please select the date in red to playback.
2. Up to 16 channels can be selected to playback synchronously.
Video Playback Tool Bar Description
The tool bar can display multi-event record. It shows that in this record period what kind of event
has happened. The symbolic meaning of each color is shown below:
Blue—Timing Green --- Motion
Red --- Alarm Black --- Emergency
And take this bar above for example, it means in this recording period there are motion and
timing event which have triggered.
Button Description Button
Rewind
Reverse
Step
File Format：MS-QR-JS-04 Rev1.0
F-3.2.1
F-3.2.2
Description Button
Stop
Forward
Step
Durability Date：1Years
Descriptio Button Description
n
Play Pause
Fast Fast
Backward Forward
