3.5.3 Alarm Input

Alarm Input function is supported in some specific models. Please make sure your NVR has such
function first.
Step1. Select Main Menu-Event-Alarm Input.
Step2. Set Alarm input channel, Alarm Name, Alarm Type and Record Channels.
[Alarm Input NO]: The channel which has input signal;
[Alarm Name]: Set a name for the alarm;
[Alarm Type]: Select alarm type: NO or NC;
[Trigger Channels Record]: Once the channel in the [Alarm Input No] has alarm input, which
channels will be triggered to record. Refer to 3.4 Record Settings;
Step3. Set action for alarm input.
File Format：MS-QR-JS-04 Rev1.0
F-3.5.16
F-3.5.17
F-3.5.18
