Quick Start Guide
V 4.03
www.milesight.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO 5000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Milesight PRO 5000

Summary of Contents for Milesight PRO 5000

  • Page 1 Quick Start Guide V 4.03 www.milesight.com...

  • Page 3: Table Of Contents

    6. Ready to Start ......................34 7. Access to NVR ......................35 7.1 Search the NVR via Smart Tools ................ 35 7.2 Via WEB ......................36 7.2.1 Log-in ......................36 7.2.2 Live View ....................38 7.3 Via Monitor ....................... 39 www.milesight.com...

  • Page 4: Package Contents

    Quick Start Guide 1.Package Contents Mini (PoE) NVR: Mini NVR Mini PoE NVR Contents Screwdriver Quick Start Guide Power Adaptor Power Adaptor Power Cord HDD Screw www.milesight.com...
  • Page 5 Quick Start Guide Pro/PoE NVR: Pro/PoE 5000 Pro/PoE 7000 Pro 8000 Contents Quick Start Guide Mouse Power Cord x 1 (Pro 5000) Power Adaptor x 12 x 16 x 32 HDD Screw HDD Bracket HDD Bracket Screw Mounting Bracket Mounting Bracket...

  • Page 6: Hardware Overview

    Quick Start Guide 2.Hardware Overview Mini NVR: Screws LED Indicator Ventilation Hole Interface Panel Mini PoE NVR: Screws LED Indicator Ventilation Hole Interface Panel www.milesight.com...
  • Page 7 Quick Start Guide Mini NVR: 80mm 120mm 80mm Mini PoE NVR: 115mm 180mm 115mm www.milesight.com...

  • Page 8: Pro/Poe

    Quick Start Guide Pro/PoE 5000: Pro/PoE 7000: Pro 8000: www.milesight.com...

  • Page 9: Interfaces

    Quick Start Guide 3.Interfaces Mini NVR: HDMI DC 12V Power Reset Mini PoE NVR: PoE Port 1/2/3/4 HDMI Power www.milesight.com...
  • Page 10 Quick Start Guide Pro 5000: www.milesight.com...
  • Page 11 Quick Start Guide PoE 5000: Alarm In PoE Port 1/3/5/7 Power Button Alarm Out AC 100-240V PoE Port 2/4/6/8 50-60HZ HDMI Grounding Audio Out www.milesight.com...
  • Page 12 Audio In Alarm Out Lock Hole LAN1 AC 100-240V 50-60HZ LAN2 Alarm In Audio Out Grounding PoE 7000: RS-232 Alarm Out Audio In PoE Port AC 100-240V HDMI Lock Hole 50-60HZ Power PoE Port 2/4/6/8/10/12/14/16 Grounding Audio Out Alarm In www.milesight.com...
  • Page 13 Quick Start Guide Pro 8000: AC 100-240V 50-60HZ Power Button Lock Hole Audio In HDMI 2 HDMI 1 eSATA Alarm Out LAN 1 RS-232 LAN 2 VGA 2 Alarm In Grounding VGA 1 Audio Out www.milesight.com...

  • Page 14: Installation

    Quick Start Guide 4. Installation 4.1 Mini (PoE) NVR 1000 Series Installation Step1: Remove the screws at the bottom panel and pull up the casing. Step2: Insert SATA HDD in the slot as required. (Mini NVR)
  • Page 15 Quick Start Guide (Mini PoE NVR) Note: Mini NVR supports two SATA HDD (2.5”). Mini PoE NVR supports one SATA HDD (3.5”). Step3: Secure the HDD with screws. (Mini NVR) www.milesight.com...
  • Page 16 Quick Start Guide (Mini PoE NVR) Step4: Push down the casing and tighten the screws. www.milesight.com...

  • Page 17: Pro/Poe Nvr 5000 Series Installation

    Quick Start Guide 4.2 Pro/PoE NVR 5000 Series Installation Step1: Using a cross screwdriver to remove the screws at the back panel in an anticlockwise direction. (Pro 5000) (PoE 5000) www.milesight.com...
  • Page 18 Quick Start Guide Step2: Slide the upper casing to the right first and lift it up. Step3: The internal structure of Pro/PoE 5000 is shown as below. (Pro 5000) www.milesight.com...
  • Page 19 Quick Start Guide (PoE 5000) Step4: Hard Disk Installation: Lock the hard disk with the HDD bracket. 6 screws for each hard disk installation. www.milesight.com...
  • Page 20 Quick Start Guide Step5: Secure the HDD brackets with hark disks in the casing. 4 screws for each HDD bracket. (Pro 5000) (PoE 5000) www.milesight.com...
  • Page 21 Quick Start Guide Step6: After that, check if all the screws are tightened. Then connect the power cable and data cable to each HDD. (Pro 5000) (PoE 5000) www.milesight.com...
  • Page 22 Quick Start Guide Step7: Pull down the upper casing and slide it to the left. Step8: Retighten the screws on the back. (Pro 5000) www.milesight.com...
  • Page 23 Quick Start Guide (PoE 5000) www.milesight.com...

  • Page 24: Pro/Poe Nvr 7000 Series Installation

    Quick Start Guide 4.3 Pro/PoE NVR 7000 Series Installation Step1: Using a cross screwdriver to remove the screws at the back panel in an anticlockwise direction. (Pro 7000) (PoE 7000) www.milesight.com...
  • Page 25 Quick Start Guide Step2: Slide the upper casing to the right first and lift it up. Step3: The HDD bracket is rotatable and can be taken down by pulling up and rotating one side of it. (Pro 7000) www.milesight.com...
  • Page 26 Quick Start Guide (PoE 7000) Step4: To install HDD more conveniently, you can： 1) Remove the bracket. (Pro 7000) www.milesight.com...
  • Page 27 Step5: Check if all the 16 screws in HDD bracket are screwed tightly, if not, screw them tightly in an clockwise direction. And fix the bracket with a screw in the middle of bracket. Then connect the power cable and data cable to each HDD. www.milesight.com...
  • Page 28 Quick Start Guide (PoE 7000) Step6: Pull down the upper casing and slide it to the left. Step7: Retighten the screws on the back. www.milesight.com...

  • Page 29: Pro Nvr 8000 Series Installation

    Quick Start Guide (Pro 7000) (PoE 7000) 4.4 Pro NVR 8000 Series Installation Step1: Using a cross screwdriver to remove the screws at the back panel in an www.milesight.com...
  • Page 30 Step2: Slide the upper casing to the right first and lift it up. Step3: Using the screwdriver to remove the screw in the middle of HDD bracket in an anticlockwise direction (Pro 7000 has only one HDD bracket and www.milesight.com...
  • Page 31 Step4: The HDD bracket is rotatable and can be taken down by pulling up and rotating one side of it. Step5: Secure the HDD with 4 screws. Don’t screw tight and leave about 4mm distance at the side of each screw nut. As the enlarged drawing shows: www.milesight.com...
  • Page 32 Step6: After securing each HDD with 4 screws, stuck the side with screw nuts in the bracket’s slots and then slide down to fix the HDD in the bracket. Screw tight with screwdriver. Step7: Repeat the above steps to install HDD in the bracket. Remember to check if you have screwed tight. www.milesight.com...
  • Page 33 Step8: Secure the 16 screws in HDD and fix the bracket with a screw in the middle of it. Then connect the power cable and data cable to each HDD. Step9: Pull down the upper casing and slide it to the left. www.milesight.com...
  • Page 34 Quick Start Guide Step10: Retighten the screws on the back. (Pro 8000) www.milesight.com...

  • Page 35: Connection Overview

    Quick Start Guide 5. Connection Overview Connect different devices to the interfaces of NVR, taking Mini (PoE) NVR and PoE 7000 NVR for example: (Mini NVR) (Mini PoE NVR) www.milesight.com...
  • Page 36 Quick Start Guide (PoE 7000) www.milesight.com...

  • Page 37: Ready To Start

    NVR and PoE 7000 NVR for example: (Mini NVR) (PoE 7000) Note: Milesight 4-CH/8-CH/16-CH Plug and Play NVR features 4/8/16 independent PoE Ports. The software can automatically detect and configure the network cameras just after being plugged the cable, greatly eliminating the need for much time and expertise, and achieving a virtually hassle-free installation process.

  • Page 38: Access To Nvr

    If the IP address of the NVR is unknown, please use the Smart Tools to search the IP address. Smart Tools can automatically detect online Milesight NVRs connected in the LAN. You can get the IP address of the NVR by searching in the Tools.

  • Page 39: Via Web

    . After that, the log-in page will pop up; Step3: (You can choose the language before logging in) Input the correct user name and password. Click on the Log-in button to enter the Live View page. (Default user name and password of NVR are “admin” and “ms1234”.) www.milesight.com...
  • Page 40 Quick Start Guide Note: 1. If the HTTP Port number is not the default number 80, please input the IP address as follows: http://IP:Port www.milesight.com...

  • Page 41: Live View

    After logging in the NVR, you can add cameras to the NVR through the camera settings. After adding cameras, please click on the Live View button to get the preview. (Default user name and password of network camera are “admin” and “ms1234”.) Details are shown as follows: www.milesight.com...

  • Page 42: Via Monitor

    There is another way to access to NVR which you can use the HDMI cable to let the NVR combine with monitor. (Default user name and password of NVR are “admin” and “ms1234”.) After running the NVR, you can do some configurations according to the wizard. Details are shown as follows: www.milesight.com...
  • Page 43 Quick Start Guide Password Modifying Time Setting Network Setting www.milesight.com...
  • Page 44 Quick Start Guide Camera Adding Also you can skip the wizard, then add cameras in Camera Management. Details are shown as follows: Camera Management www.milesight.com...
  • Page 45 Quick Start Guide Camera Settings After adding cameras successfully, you can choose the Live View to preview. Live View www.milesight.com...

  • Page 46: Thank You

    Quick Start Guide NVR Series Thank you for choosing Milesight Product © 2016 Milesight Technology Co., Ltd. www.milesight.com...
  • Page 48 www.milesight.com...
