  • Page 1 Network Video Recorder User Manual V4.03...

  • Page 2: Safety Instruction

    Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measures are divided into “Warnings” and “Cautions” Warnings: Serious injury or death may be caused if any of these warnings is neglected.
  • Page 3 should not be exposed to where a laser beam equipment is used  Use a blower to remove dust from the lens cover  Use a soft, dry cloth to clean the surface of the camera. Stubborn stains can be removed using a soft cloth dampened with a small quantity of detergent solution, then wipe dry ...

  • Page 4: Table Of Contents

    Content 1. Product Introduction........................1 1.1 Introduction...........................1 1.2 Product Key Functions......................1 2. Hardware............................5 2.1 Panel Buttons and Lights Instructions...................5 2.2 Using a USB Mouse....................... 7 2.3 Hard Disk Installation......................8 2.3.1 MS-N7000 series Hard Disk Installation..............8 2.3.2 MS-N8000 series Hard Disk Installation..............11 3.
  • Page 5 3.7.3 Live View Parameter....................57 3.8 System Settings........................58 3.8.1 General Setting......................58 3.8.2 Network Settings......................59 3.8.3 Disk Management....................64 3.8.4 Holiday Configuration....................66 3.8.5 User Account Settings....................67 3.8.6 Upgrade........................69 3.8.7 Save/Load Configuration..................70 3.8.8 Auto Maintenance....................72 3.9 Shutdown..........................72 3.9.1 Logout........................73 3.9.2 Reboot........................

  • Page 6: Product Introduction

    1. Product Introduction 1.1 Introduction Milesight NVR Series are positioned at management and storage application of HD video data, and own multi-disc management systems, front end HD device management system, HD video analysis system and high-capacity system for video. It adopts the technology of high flow capacity data network transmitting&transmission, with multi-channel video decoding, to achieve...

  • Page 7: Other Functions

    alarm, motion and alarm, etc.  Support 12 recording time periods with separate recording types.  Support pre-record and post-record time for motion detection or snapshot, alarm  recording or snapshot, motion and alarm recording, motion or alarm recording. And support pre-record for manual and timing.
  • Page 8 MS-N5016-UH/ MS-N7016-UH/ MS-N8032-UH/ Model MS-N1009-UT MS-N5032-UH MS-N7032-UH MS-N8064-UH Network Video Input 16/32 16/32 32/64 Max. Stream 90Mbps 160/320Mbps 160/320Mbps 320Mbps Video/Audio Input Network Audio Input 16/32 16/32 32/64 Analog Audio Input 1*RCA 1*RCA 1*RCA － HDMI Output VGA Output －...
  • Page 9 Model MS-N1009-UPT MS-N5016-UPT MS-N7032-UPH Network Video Input Max. Stream 90Mbps 160Mbps 320Mbps Video/Audio Input Network Audio Input Analog Audio Input 1*RCA － HDMI Output VGA Output － Audio Output 1*RCA 1*RCA － 30fps@D1 (704×576) 30fps@720P (1280×720) Video/Audio Synchronous 30fps@1080P Output Preview (1920×1080) 30fps@3MP...

  • Page 10: Hardware

    2. Hardware 2.1 Panel Buttons and Lights Instructions (1) MS-N1000-UT Series: MS-N1009-UT MS-N1009-UT (2) MS-N5000-UH Series: MS-N5016-UH/MS-N5032-UH (3) MS-N7000-UH Series: MS-N7016-UH/MS-N7032-UH File Format：MS-QR-JS-04 Rev1.0 Durability Date：1Years...
  • Page 11 (4) MS-N8000-UH Series: MS-N8032-UH/MS-N8064-UH (5) MS-N1000-UPT Series: MS-N1009-UPT (6) MS-N5000-UPT Series: MS-N5016-UPT File Format：MS-QR-JS-04 Rev1.0 Durability Date：1Years...

  • Page 12: Using A Usb Mouse

    (7) MS-N7000-UPH Series: MS-N7032-UPH Note： The PoE ports of PoE NVR series only support Milesight network cameras. 2.2 Using a USB Mouse Item Click Description Live view: select the channel and show the toolbar of live view. Single- click Menu: select and confirm.

  • Page 13: Hard Disk Installation

    2.3 Hard Disk Installation 2.3.1 MS-N7000 series Hard Disk Installation Step1. Unscrew the back and both sides’ screws to open the upper lid. F-2.5.1 F-2.5.2 F-2.5.3 File Format：MS-QR-JS-04 Rev1.0 Durability Date：1Years...
  • Page 14 Step2. Install the hard disks into NVR with screws shown in below pictures. (SATA Slots of hard disk should be toward inside NVR.) F-2.5.4 F-2.5.5 F-2.5.6 Step3. Join the power and data connectors to corresponding hard disk. File Format：MS-QR-JS-04 Rev1.0 Durability Date：1Years...
  • Page 15 F-2.5.7 F-2.5.8 F-2.5.9 File Format：MS-QR-JS-04 Rev1.0 Durability Date：1Years...

  • Page 16: Ms-N8000 Series Hard Disk Installation

    2.3.2 MS-N8000 series Hard Disk Installation Step1. Unscrew the back and both sides’ screws to open the upper lid. F-2.5.10 F-2.5.11 F-2.5.12 Step2. Uninstall the upper hard disk panel. File Format：MS-QR-JS-04 Rev1.0 Durability Date：1Years...
  • Page 17 F-2.5.13 Step3. Install the hard disks into NVR with screws shown in below pictures.(SATA slots of hard disks should be toward inside NVR) F-2.5.14 F-2.5.15 File Format：MS-QR-JS-04 Rev1.0 Durability Date：1Years...
  • Page 18 F-2.5.16 F-2.5.17 Note: The SATA slots are in SHORT HALF side and the SATA slot toward inside NVR. Step4. Join the power connectors to corresponding hard disks.(Install lower hard disk panel before upper one) F-2.5.18 File Format：MS-QR-JS-04 Rev1.0 Durability Date：1Years...
  • Page 19 F-2.5.19 Step5. Join the data connectors to corresponding hard disk.(Check the connection by below sequence) F-2.5.20 Note: The data connector sequence of MS-N7000 series is different from MS-N8000 series’. File Format：MS-QR-JS-04 Rev1.0 Durability Date：1Years...

  • Page 20: Local Operation

    3. Local Operation 3.1 Wizard Setting By default, the Setup Wizard will start once the NVR has loaded. The Setup Wizard will guide you to complete important settings to make sure the device function well. You can choose if the Setup Wizard starts or not every time when the device powered.
  • Page 21 Step3. Network setting Input the IP Address, Subnet Mask, Gate Way and Preferred DNS Server. Internal NIC IPv4 Address option is only for PoE NVR. F-3.1.3 Step4. Disk Management Detect the hard disk installed in the NVR automatically, support format hard disk in this page. You can create RAID in this page as well.

  • Page 22: Playback

    F-3.1.6 Step6. Login Input the user name and password to login the system. F-3.1.7 3.2 Playback To play and backup the recorded files in specified time period. 3.2.1 Video Playback It can support playback according to recorded time. Play recorded video files in specified time period;...
  • Page 23 F-3.2.1 Step2. Select a desired channel and date Select playback layout and channel. Click the date in red when there are recorded files of the selected channels, the record type with recording data will be show as below, and then click to playback.

  • Page 24: Video Files Backup

    Previous Next 4 Timeline Timeline Cams Cams Backward Forward Timeline Timeline Timeline Playback Zoom In Zoom Out Position Timeline Timeline Audio On Audio Off Cutting Cut Off Snapshot Backup 3.2.2 Video Files Backup Regular recorded files can be backed up by various devices, such as USB flash drives (USB flash disk, USB HDD, USB writer), eSATA etc.

  • Page 25: Picture Playback

    F-3.2.6 Step4. The pop-up window will prompt: Please wait… F-3.2.7 Step5. When all backup files have been exported, ‘Backup Success’ will be prompted. F-3.2.8 Note: The file upload time depends on the time of video you want to backup. 3.2.3 Picture Playback Search and look for the snapshot files saved in HDD.

  • Page 26: Picture Files Backup

    Step2. Enter Picture Info List and look up the pictures. Click to play the desired pictures, or click to auto play the picture. F-3.2.10 Picture Playback Tool Bar Description Button Description Button Description Button Description Button Description Backward Previous Play Next Picture Play Picture...

  • Page 27: Camera Settings

    Step2. Select backup media and click to save picture. F-3.2.12 3.3 Camera Settings Before configuration, please ensure that the camera is connected to the same network as your NVR and that the network setting for your NVR is properly setup. 3.3.1 Camera Management Step1.
  • Page 28 F-3.3.2 2. Click [search] button to quickly search the IP devices in LAN with different types: All, ONVIF, MSSP. F-3.3.3 3. Double click the channel, input password and click [Add] button. F-3.3.4 Or Check to bulk adding the IP cameras if they are with same password. File Format：MS-QR-JS-04 Rev1.0 Durability Date：1Years...
  • Page 29 “rtsp://IP:port/sub”, and the tertiary stream is “rtsp://IP:port/third”. The details about adding format are shown in F-3.3.8; MSSP: If your IP camera is a Milesight device, you can select this protocol to add cameras.  The detail formats are shown in F-3.3.9;...
  • Page 30 F-3.3.7 ONVIF F-3.3.8 RTSP F-3.3.9 MSSP Step3. Check the connection status After adding the IP channels, click [Refresh] button, the [status] will show [connected] as below. If not, you need to check if the network is connected or whether the user name, password is correct or not.
  • Page 31 F-3.3.10 Step4. Configure IP Channel 1. After successfully adding the channel, click or double-click this channel to re-edit the channel info, address, and password, etc. F-3.3.11 Note: By default, the user name and password entered here are the default user name and password. The management port is 80 and the default Transport protocol is UDP.

  • Page 32: Camera Search

    F-3.3.13 Step5. Configure PoE Channel(Only for PoE NVR) 1. Connect camera to PoE port, it will detect the camera automatically. 2. If the camera's password is "ms1234", it will change the camera into the same network segment with internal NIC IPv4 address and then the camera will be connected automatically. 3.
  • Page 33 ONVIF: Search the cameras that support ONVIF protocol and in the same network segment  with NVR. MSSP: Search the Milesight cameras in LAN even with different network segments.  Step3. Add IP Camera Double click the channel, input password and click [Add] button.

  • Page 34: Ptz Configuration

    Or you can bulk adding the IP cameras if they are with same password. Click [OK] to finish bulk adding. F-3.3.18 3.3.3 PTZ Configuration 3.3.3.1 PTZ control Parameters Configuration Enter configuration interface by clicking Main Menu  Camera  PTZ Configuration, select “Configuration”...

  • Page 35: Advanced Configuration

    3.3.3.2 Advanced Configuration Main Menu  Camera PTZ Configuration, select “Advanced” page. There are two patrol ways can be set: Pattern and Path. Note: 1. IP channel does not support configuration and calling of presets, patrols and patterns. 2. The functioning of presets patrols and patterns need front PTZ decoder to support. 1.
  • Page 36 Pattern The camera will patrol according to the key points. The total time and patrol speed of the path is variable. Step1. Select a pattern. Up to 6 paths could be set. F-3.3.22 Step2. Click to add key points. Set the key point parameters (including preset point number, scan time and scan speed) and click [OK].
  • Page 37 Scan speed is the rotate speed of speed dome from one preset point to the next. 4. Track Patrol The camera will patrol back and forth in a constant speed. There are only a start point and an end point. Step1.

  • Page 38: Privacy Mask

    Vertical Movement Adjustment Zoom Adjustment Focus Adjustment 3.3.4 Privacy Mask Milesight NVR support privacy mask. It used to cover some privacy area which is not proper to appear on monitor. Entering Privacy Mask interface by clicking: Main Menu CameraPrivacy Mask. F-3.3.26 You can add a privacy mask by following steps: Step1.

  • Page 39: Osd Configuration

    F-3.3.27 Step3. Copy the privacy area to the other channels by click the “copy” button on the bottom of the windows; F-3.3.28 Step4. Select “Apply” to save the settings. 3.3.5 OSD configuration You can set OSD (On Screen Display) on NVR, and the OSD will be synchronized on IPC. Entering OSD Configuration interface by clicking: Main Menu...

  • Page 40: Image Enhancement

    Step1. Select channel by clicking the channel number on the right-top, the selected channel will change into gray and the channel number will change into yellow; Step2. Enable video title and timestamp: [Video Title]: Set the video title for the channel; [Title Position]: Set the position for the video title: Top-Left or Top-Right;...

  • Page 41: Record Settings

    F-3.3.32 Step1. Select channel by clicking the channel number on the right-top, the selected channel will change into gray and the channel number will change into yellow; Step2. Set the configuration; [Day/Night Mode]: Set the Day/Night mode for the channel; [Day to Night Value]: Set the Minimum illumination intensity to trigger Night Mode;...

  • Page 42: Record Mode

    Step2. Ensure that HDD has sufficient storage space. Enter disk management interface by clicking System Setting →Disk Management. Select [Recycle Mode] to ON in the case of insufficient capacity of HDD. F-3.4.2 3.4.1 Record Mode Step1. Enter record mode menu by clicking Main Menu → Record → Record Mode. There are three record modes: No Recording/Always Record/Record by Schedule.
  • Page 43 Method1. General Setting Step1. Enter Record schedule interface by clicking Record Settings→Record Schedule F-3.4.4 Step2. Select desired channel (e.g. Channel 1)and click [Edit] button F-3.4.5 Step3. Set record schedule Select a day from the drop-down list of [Day], and select [Record Type] to setup the recording period, up to 12 periods can be set.
  • Page 44 Step4. Click [Copy] to copy settings to other weekdays, and then click [Apply] to confirm the setting. F-3.4.7 Step5. After above steps, this channel with show as below: F-3.4.8 Step6. Copy the recording settings to other channels Select [Copy] to copy the same settings to other channels. And click [OK] to save the configuration.
  • Page 45 menu. Method2.Set record schedule by drag the mouse Step1. Enter Record schedule interface by clicking Record Settings→Record Schedule F-3.4.10 Step2. Click desired channel and record type show as below: F-3.4.11 Step3. Drag the mouse to draw certain areas in recording setting zone and then click[Apply] to save the configuration.

  • Page 46: Advanced Settings

    configuration. F-3.4.13 3.4.3 Advanced settings You can set the advanced settings there. F-3.4.14 Illustration for Parameters [Channel Selection]: Select the channel which will be set. [Post Record]: Enable/Disable post record after the event is over [Duration Time]: Event pre-record duration before event alarm [Audio Record]: Select to record audio or not [Record Stream Type]: Select Main stream or sub stream for record Lastly choose you can choose the copy button to copy the settings of record for other channels.

  • Page 47: Event Settings

    F-3.4.15 3.5 Event Settings 3.5.1 Video Loss Your NVR can be setup to detect video loss and trigger an action. Step1. Enter video loss configuration interface by clicking Main Menu→Event→Video Loss . F-3.5.1 Step2. Select a desired channel and click [Edit] to configure video loss. F-3.5.2 Step3.
  • Page 48 detected. [Never]: Your NVR will not trigger any actions when [Never] button is checked. No matter the [Audible Warning] or [Email Linkage] check-boxes are checked or not. [Always]: Your NVR will always trigger actions when [Always] button is checked. Please make sure [Audible Warning] or [Email Linkage] is checked.
  • Page 49 F-3.5.5 Note: Time periods cannot overlap with each other. Step4. Click [Copy] to copy the video loss schedule to other weeks, and then click [OK]. F-3.5.6 Step5. Select actions you want when video loss is detected. [Trigger Alarm Output]: Select whether trigger the alarm output or not when video loss is detected.

  • Page 50: Motion Detection

    F-3.5.7 3.5.2 Motion Detection Your NVR can be setup to motion detect and trigger an action. You can set the motion detection on NVR or on IPC web, both sides’ settings will be synchronous in both devices. Step1. Enter motion detection setting interface by clicking Main Menu → Event → Motion Detection.
  • Page 51 F-3.5.10 And meanwhile the area will be synchronized in IPC. Step3. Select the schedule, sensitivity and trigger area for motion detection. [Enable IPC’s Motion]: If it is enabled here, motion detect will take effect 7*24h ; If it is not enabled, motion detect will take effect as the schedule which is set on the camera web [All Set]: Set all area as the trigger area;...
  • Page 52 [Never]: Your NVR will not trigger any actions when [Never] button is checked. No matter the [Audible Warning] or [Email Linkage] check-boxes are checked or not. [Always]: Your NVR will always trigger actions when [Always] button is checked. Please make sure [Audible Warning] or [Email Linkage] is checked.
  • Page 53 Note: Time period cannot overlay with each other Step6. Click [Copy] to copy the motion detection schedules to other weekdays. F-3.5.15 Step7. Select actions you want when motion is detected [Trigger Alarm Output]: Select whether trigger the alarm output or not when video loss is detected.

  • Page 54: Alarm Input

    F-3.5.16 3.5.3 Alarm Input Alarm Input function is supported in some specific models. Please make sure your NVR has such function first. Step1. Select Main Menu-Event-Alarm Input. F-3.5.17 Step2. Set Alarm input channel, Alarm Name, Alarm Type and Record Channels. F-3.5.18 [Alarm Input NO]: The channel which has input signal;...
  • Page 55 F-3.5.19 You need to set 1.Effective time 2.Action on this Action Interface: 1. Effective time: F-3.5.20 You can set three different modes for effective time: [Never]: Will have no action triggered if it is checked; [Always]: Will always trigger the action if checked; [By Schedule]: Will take effect by the schedule you set.

  • Page 56: Alarm Output

    Lastly need to APPLY these settings to take effect. 3.5.4 Alarm Output Alarm Output function is supported on MS-N5016, MS-N5116, MS-N8016, MS-N8032. Step 1. Select Main Menu-Event-Alarm Output: F-3.5.22 Step 2. Set Alarm output channel, Alarm Name, Alarm Type and Record Channels: F-3.5.23 [Alarm Output NO]: The channel which will output the alarm signal;...

  • Page 57: Exception

    2.by click the “Edit Time” button. Lastly need to APPLY these settings to take effect. 3.5.5 Exception Milesight NVR support exception alarm hint for1. Network Disconnected; 2.HDD Full; 3.Record Fail; 4.HDD Error; Step1. Enter Exception by clicking Main Menu-Event-Exception;...

  • Page 58: Device Information

    3.6.1 Device Information Step: Enter Device information menu by clicking Main MenuStatusDevice Information It will show you information in F-3.6.1, including: Device ID, Device Name, Hardware Version, Software Version, and Serial Number. F-3.6.1 3.6.2 Network Status Step: Enter Network Status menu by clicking Main MenuStatusNetwork Status It will show you information in F-3.6.2, including: Connection, Mode, DHCP, MTU(B), IP Address, Net mask, Gateway, MAC, Preferred DNS Server, Alternate DNS Server, Receive Rate, and Send Rate.

  • Page 59: Disk Status

    Frame Rate, Bit rate, Resolution and Status. The PoE Channel Status is only for PoE NVR, it will show you the connection status of PoE ports. F-3.6.3 3.6.4 Disk Status Step: Enter disk status menu by clicking Main MenuStatusDisk Status It will show you information in F-3.6.4, including: Port, Vendor, Status, Total(GB), Free(GB), HDD Type, In Use, and Recycle Mode.

  • Page 60: Live View Settings

    F-3.6.5 3.6.5.2 Camera Event Status Step: Enter camera event page by clicking Main MenuStatusEvent Status. It will show you the camera event status in F-3.6.6. If the shows in red, it means the corresponding project is active. F-3.6.6 3.7 Live View Settings 3.7.1 Live View Watching a Live View There are multiple icons on each channel displayed in live view mode, indicating the recording...
  • Page 61 Icons Descriptions Indicates video loss Indicates motion detection alarm Indicates the current channel is recording. The recording may have been started manually, from a schedule, motion detection, alarm, and/or triggered from motion and alarm. Indicates exception alarm and recording. Use the Right Button of the Mouse in Live View F-3.7.1 Item Description...

  • Page 62: Layout Configuration

    Icon Description Icon Description Icon description Image Manually recording PTZ Control configure Electronic Sound on/off Snapshot manually Amplification Close 3.7.2 Layout Configuration Step1. Enter layout configuration menu by clicking Main Menu  Live View  Layout configuration F-3.7.2 You can choose single screen/4/8/1+7/9/12/1+11/14/16/32 screens for layout configuration according to the model and your need.

  • Page 63: System Settings

    F-3.7.4 Item Description Borderline Borderline ON/OFF Channel Name Display the channel name Channel Name Color To change the color of the channel name Sequence Interval Set sequence interval in live view mode To configure channel order of all layouts Separately Configure Layout respectively Skip Blank Page Skip blank page in sequence mode...

  • Page 64: Network Settings

    3.8.2 Network Settings 3.8.2.1 Basic Configuration Step: Enter the network setting menu to set the network parameters by clicking Main MenuSystem SettingsNetwork, select “Basic” page Basic configuration includes working mode, IP address, subnet mask, gateway, MTU, DNS server, Internal NIC IPv4 Address, etc. F-3.8.2 Note: Check the DHCP check-box if there has a DHCP server running in networks.

  • Page 65: Email Configuration

    F-3.8.3 Note: 1. PPPoE user name and password can be obtained from your service provider. Once the setup is completed, a connected status will be shown. 2. PPPoE function is not available for 4K/H.265 series NVR. 3.8.2.3 DDNS Configuration If your NVR is setup to use PPPoE to connect public network, you may need to use DDNS (Dynamic Domain Name System) to solve the problems from dynamic IP address.
  • Page 66 Email Set the Sender E-mail Address, User Name, Password, and SMTP Server: F-3.8.5 [User name]: The E-mail address you choose to send emails. [Password]: The password of the E-mail. [SMTP Server]: The SMTP Server of your E-mail. [Port]: The port of SMTP Server, it’s usually 25. [Sender Name]: Named by yourself for the Sender E-mail.
  • Page 67 F-3.8.7 3.8.2.5 P2P You can use M-VMS to watch the remote live view by P2P. With the introduction of P2P, you can watch the NVR Live view from WAN without do any port forwarding on the router. Right click on the live view and choose MenuSystemNetworkP2P, you will see the image like below: F-3.8.8 Step1.
  • Page 68 Network Error. Check the network condition. Register failed. MAC address doesn’t register the P2P. Unknown Error. Need to contact with Milesight Support. 3.8.2.6 More Step: Enter More configuration page by clicking Main Menu  System Settings  Network → More F-3.8.9 Push Message Enable With this option enabled, you can receive the alarm message on the mobile application(M-VMS).

  • Page 69: Disk Management

    Service port is used to remote access when add NVR by mobile device. The default service port is 1100. Please modify service port according to actual application. Note: 1. This option is not available for 4K/H.265 series NVR. 2. You can add this port when using P2P/port mapping/LAN IP to add NVR, the 4K/H.265 series NVR use port 80 to add.
  • Page 70 disks for recovery purposes, the total available storage will be twice smaller compared to RAID 0. RAID 5: The check code will store in each disk. Should one of the disks be damaged, it can use the data and check code from other disks to recover the data on the damaged disk. RAID 10: Combines RAID 1 and RAID 0 configurations –...

  • Page 71: Holiday Configuration

    Note: 1. RAID* stands for RAID0/RAID1/RAID5/RAID10. 2. The hot spare disk will be automatically used for rebuilding when array is in Degraded status. 3. Currently RAID the capacity can not support larger than 16TB. 3.8.3.3 S.M.A.R.T Detection Step: Enter S.M.A.R.T configure page by clicking Main Menu  System Settings  Disk Management→S.M.A.R.T S.M.A.R.T detection is a monitoring system of HDD that detects and reports on various indicators of anticipating failures of HDD.

  • Page 72: User Account Settings

    F-3.8.14 Step2. Edit the holiday schedule. Click to open holiday configuration page to modify holiday name, check the ‘Holiday Enable’ check-box, and then select [style] to setup Start/End date. Then click [OK] to save the configuration and return to holiday configuration page. Click [Apply] to confirm settings. Note: There are Month, Week and Date in “Style”...
  • Page 73 F-3.8.16 Note: If the NVR firmware version out of the factory is xx.7.0.6 or above, the default user name is “admin” and the default password is “ms1234”; If the NVR firmware is upgraded to xx.7.0.6 or above from a lower version, the default password will turn to “ms1234”...

  • Page 74: Upgrade

    F-3.8.18 Step4. Click to edit a user. F-3.8.19 3.8.6 Upgrade Your NVR supports firmware upgrade. Step1. Enter upgrade menu by clicking Main MenuSystem SettingsUpgrade. F-3.8.20 Step2. Search for device, and select the .bin file. File Format：MS-QR-JS-04 Rev1.0 Durability Date：1Years...

  • Page 75: Save/Load Configuration

    F-3.8.21 Step3. Click [Upgrade] button to confirm the upgrade. F-3.8.22 Note: The system will auto reboot after confirming upgrade. 3.8.7 Save/Load Configuration 3.8.7.1 Backup/Restore Your NVR supports backup and restore configuration. Step1: Enter profile menu clicking Main Menu  System  Save/Load ConfigurationBackup/Restore.
  • Page 76 F-3.8.23 Step2. Select a folder and then click [Backup] to export configuration to USB device. F-3.8.24 Step3. Select a .cfg file and then click [Restore] to import configuration to your NVR. F-3.8.25 3.8.7.2 Reset You can reset all parameters to default settings. Enter reset menu by clicking Main MenuSystemSave/Load Configuration...

  • Page 77: Auto Maintenance

    F-3.8.26 3.8.8 Auto Maintenance F-3.8.27 You can set the Log and Photo Retention period for Log and Photo.Once is expired, it will automatically delete by NVR. The retention period is ranged from 1 to 12 months, if you don’t want those files be deleted, you can select Permanent. 3.9 Shutdown F-3.9.1 File Format：MS-QR-JS-04 Rev1.0...

  • Page 78: Logout

    3.9.1 Logout Click [Logout] to exit the current logon account. 3.9.2 Reboot Click [Reboot] to restart the NVR. 3.9.3 Shutdown Click [Shutdown] to close the NVR. 3.9.4 Close Click [Close] to exit. File Format：MS-QR-JS-04 Rev1.0 Durability Date：1Years...

  • Page 79: Web Settings

    4. WEB Settings 4.1 Login Input the user name and password. F-4.1.1 Note: If the NVR firmware version out of the factory is xx.7.0.6 or above, the default user name is “admin” and the default password is “ms1234”; If the NVR firmware is upgraded to xx.7.0.6 or above from a lower version, the default password will turn to “ms1234”...

  • Page 80: Play View

    F-4.1.2 Quick Operation Icon Description Icon Description Icon description Snapshot by Stop All Live View Start All Live View manually Front Page Next Page Sound off/on Full Screen Window 1 Window 4 Window 8 Window 9 4.2.2 Play View Enter the live view interface; click Live ViewCamera List. Choose the View1 or View2 to play; F-4.1.3 File Format：MS-QR-JS-04 Rev1.0 Durability Date：1Years...

  • Page 81: Ptz

    4.2.3 PTZ Enter Camera List interface by clicking Live ViewPTZ F-4.1.4 4.2.4 Video Parameters Enter Video Parameters by clicking Live ViewVideo Parameters F-4.1.5 4.3 Playback To play and backup the recorded files in specified time period. 4.3.1 Playback It can support playback according to recorded time. Play recorded files in specified time period. Step1.
  • Page 82 Select playback layout and channel. Click the date in red when there are recorded files of the selected channels, the record type with recording data will be show as below, and then click to playback. Note: The day in red has recording files; please select the date in red to playback. F-4.3.1 Video Playback Tool Bar Description The tool bar can display multi-event record.

  • Page 83: Video Files Backup

    4.3.2 Video Files Backup Recorded files can be cut and backed up from WEB. Step1. Enter playback interface, select the date and time to playback F-4.3.2 Step2. Select Recorded files for Backup. Select the channel and date you want to backup, then select the start time at time line and click , it will change into which means cut begins.

  • Page 84: Picture Files Backup

    4.3.3 Picture Files Backup Step1. Enter record files path settings interface by clicking Settings→Local Configuration Choose Playback Picture Path. F-4.3.3 Step2. Pause first when you want backup a special scene during video playback. Step3. Click to save picture.Then backup picture can be found the files path set before. F-4.3.4 4.4 Log Select special period and type logs by Search tools.

  • Page 85: Settings

    F-4.4.1 4.5 Settings 4.5.1 Local Configuration Step1. Enter Local Configuration interface by clicking SettingsLocal Configuration. F-4.5.1 Step2. Choose Languages. F-4.5.2 Step3. Set paths then save configurations. File Format：MS-QR-JS-04 Rev1.0 Durability Date：1Years...

  • Page 86: Camera

    4.5.2 Camera Before configuration, please ensure that the IP device is connected to the same network as your NVR and that the network setting for your NVR is properly setup. 4.5.2.1 Camera Management Step1. Enter Local Configuration interface by clicking SettingsCamera. F-4.5.3 Step2.
  • Page 87 F-4.5.5 3. Click the channel, click [Add] button, input password and click [OK] button to finish or click [Cancel] button to cancel. 4. Or Check to bulk adding the IP cameras if they are with same password. F-4.5.6 Method2. Add IP Channel in camera management interface 1.
  • Page 88 “rtsp://IP:port/main” and the second stream is “rtsp://IP:port/sub”. The details about adding format are shown in F-4.5.9; 3. MSSP: If your IP camera is a Milesight device you can select this protocol to add cameras in the same LAN. The detail formats are shown in F-4.5.10;...
  • Page 89 F-4.5.11 Step4. Configure IP Channel After successfully adding the channel, click to re-edit the channel info, address, and password, etc. F-4.5.12 Select [Parameters] page to re-edit this channel parameters. Click [Save] to save the configuration F-4.5.13 You can delete this channel by clicking , or you can select multiple devices and then click delete.
  • Page 90 NVR; switch Protocol into [ONVIF] to search the IP devices that support ONVIF at the same network segment with NVR, or switch Protocol into [MILESIGHT] to search the IP devices that support MILESIGHT at the same LAN with NVR.
  • Page 91 F-4.5.17 F-4.5.18 Step3. Click the channel, click [Add] button, input password and click [OK] button to finish or click [Cancel] button to cancel, or Check to bulk adding the IP cameras if they are with same password. F-4.5.19 4.5.2.3 PTZ Configuration Step: Enter configuration interface by clicking SettingsCameraPTZ Configuration Select a channel and set the PTZ parameters.
  • Page 92 Settings for a PTZ camera must be configured before it can be used. Make sure that the PTZ and RS-485 of the NVR are connected properly. 4.5.2.4 Privacy Mask Milesight NVR support privacy mask. It is used to cover some privacy area which is not proper to appear on monitor. You can add a privacy mask by following steps: Step1.
  • Page 93 Step5. Select “Save” to save the settings. Note: [Start Point X] and [Start Point Y] decide the point of the area starts, [Mask Width] and [Mask Height] decide the size of the area. 4.5.2.5 OSD Configuration You can set OSD (On Screen Display) on NVR, and the OSD will be synchronized on IPC. Entering OSD Configuration interface by clicking: Settings...

  • Page 94: Record

    [Day to Night Value]: Set the Minimum illumination intensity to trigger Night Mode; [Night to Day Value]: Set the Maximum illumination intensity to trigger Day Mode; [IR Light Sensor Value]: Shows the current value of IR light sensor; [WDR/HLC]: Click to configure Wide Dynamic Range or High Light Control; [Power Line Frequency]: 50Hz and 60Hz are available;...
  • Page 95 4.5.3.1 Record Mode Step1. Enter record mode menu by clicking Settings→Record→Record Mode. There are three record modes: No Recording/Always Record/Record by Schedule. You can select the desired one for every channel. F-4.5.26 [No Record]: NVR will not record if you choose this column; [Always Record]: It will always record the chosen channel;...
  • Page 96 F-4.5.28 F-4.5.29 Click and check to copy to other channels. 4.5.3.3 Advanced Select the desired channel and set record time personally, Click and check to copy to other channels. File Format：MS-QR-JS-04 Rev1.0 Durability Date：1Years...

  • Page 97: System

    F-4.5.30 Illustration for Parameters [Channel Selection]: Select the channel which will be set. [Post Record ]: Enable/Disable post record after the event is over [Duration Time]: Event post-record duration before event alarm [Audio Record]: Select to record audio or not [Record Stream Type]: Select Main stream or sub stream for record Lastly, you can choose the copy button to copy the settings of record to other channels.

  • Page 98: Basic Configuration

    4.5.4.2 Network Settings 4.5.4.2.1 Basic Configuration Step: Enter the network setting menu to set the network parameters by clicking SettingsSystemNetwork Settings, select “Basic” page Basic configuration includes working mode, IP address, subnet mask, gateway, MTU, DNS server, etc. F-4.5.32 Note: Check the DHCP check-box if there has a DHCP server running in networks.
  • Page 99 4.5.4.2.3 DDNS Step: Enter DDNS configuration menu by clicking SettingsSystemNetwork, Select “DDNS” page If your NVR is setup to use PPPoE to connect public network, you may need to use DDNS (Dynamic Domain Name System) to solve the problems from dynamic IP address. Check the DDNS check-box to enable the feature. Select “DDNS Server”, and input user name, password and host name, and then confirm.
  • Page 100 Marked Words Description Network Error. Check the network condition. Register failed. MAC address doesn’t register the P2P. Unknown Error. Need to contact with Milesight Support. 4.5.4.2.6 More Step: Enter More configuration page by clicking SettingsSystemNetwork Settings→More File Format：MS-QR-JS-04 Rev1.0 Durability Date：1Years...
  • Page 101 F-4.5.37 Push Message Enable With this option enabled, you can receive the alarm message on the mobile application(M-VMS). SSH Port Setting Secure Shell (SSH) has many functions; it can replace Telnet, and also provides a secure channel for FTP, POP, even for PPP. Note: The default SSH port is 22.
  • Page 102 4.5.4.3 Disk Management Step: Enter disk configuration menu by clicking SettingsSystemDisk Management Configuration page contains the basic information of the disk, see F-4.5.38. Select a disk and click [Format] to format the disk. F-4.5.38 [RAID Mode]: Enable/Disable to open/close RAID function. [HDD Type]: Show RAID* means RAID, show LOCAL means normal disk mode.
  • Page 103 F-4.5.40 4.5.4.5 User Step1. Enter user setting menu by clicking SettingsSystemUser. Note: If the NVR firmware version out of the factory is xx.7.0.6 or above, the default user name is “admin” and the default password is “ms1234”; If the NVR firmware is upgraded to xx.7.0.6 or above from a lower version, the default password will turn to “ms1234”...

  • Page 104: Device Maintenance

    Step3. Edit user. Select a desired user and click, when the color below changes into blue, click [Edit Limit] to edit user privileges, click [Edit Password] to change password. Note: User name can be comprised of letters and figures. The user level is separated into User and Operator with different authority;...
  • Page 105 F-4.5.45 4.5.4.6.1 Auto Maintenance You can set the Log and Photo Retention period for Log and Photo. Once is expired, it will automatically delete by NVR. The retention period is ranged from 1 to 12 months, if you don’t want those files be deleted, you can select Permanent.

  • Page 106: Event

    F-4.5.47 4.5.4.6.6 Upgrade Click to select the firmware file, and check if reset configuration to factory defaults. Then click to upgrade. Note: The upgrading process will be 5 to 10 minutes, please don't disconnect power to the device during the process. The device reboots automatically after upgrading.
  • Page 107 Warning] or [Email Linkage] is checked. [By Schedule]: Schedule can be set for all week or any day of the week with up to 12 time periods per day. Video loss actions take effect in the scheduled period only. [Audible Warning]: Trigger an audible beep when video loss is detected [Email Linkage]: Send video loss note to specified email address when video loss is detected.(Please refer to 4.5.4.2.4 Email configuration for mail address setting) [Trigger Interval]: Set the interval between two events.
  • Page 108 [All Clear]: Clear all trigger area; [Sensitivity]: Set sensitivity for motion detection, range from 1 to 10.It will synchronize to IPC if you set sensitivity here; Step4. Click the [Action Edit] to edit action once motion is detected. Edit the schedule and action. F-4.5.51 [Audible Warning]: NVR will audible warning once motion is detected;...

  • Page 109: Status

    Step2. Select Exception Type. There are 4 kinds of alarm types. [Network Disconnected]: Loss of network; [HDD Full]: HDD is full. It usually happened when Recycle Mode is OFF. [Record Fail]: Record Failed, including HDD Error, HDD Full, no HDD and so on. [HDD Error]: HDD is Error.

  • Page 110: Camera Status

    It will show you information in F-4.6.2, including: Free bandwidth, Used bandwidth, Connection, Mode, DHCP, MTU(B), IP Address, Net mask, Gateway, MAC, Preferred DNS Server, Alternate DNS Server, Receive Rate, and Send Rate. F-4.6.2 4.6.3 Camera Status Step: Enter camera status menu by clicking SettingsStatusCamera Status It will show you information in F-4.6.3, including: Channel, Name, Enable, IP Address, Record, Frame Rate, Bit rate, Resolution and Status.

  • Page 111: Event Status

    F-4.6.4 4.6.5 Event Status Step: Enter event status menu by clicking SettingsStatusEvent Status It will show you information in F-4.6.5, including: Channel, Name, IP Address, Videoloss, Motion, I/O. Icon will light up as below: F-4.6.5 4.6.6 Packet Capture Tool Step: Enter packet capture tool status menu by clicking SettingsStatusPacket Capture Tool Print IP and Port, click the [Start] to start capture packet then click [End] to stop.

  • Page 112: Logout

    Click [Logout] to exit the current account. F-4.7.1 5. Services Milesight Technology Co., Ltd provides customers with timely and comprehensive technical support services. End-users can contact your local dealer to obtain technical support. Distributors and resellers can contact directly with Milesight for technical support.
