- Page 1 Quick Start Guide V 4.03 www.milesight.com...
-
Page 3: Table Of Contents
6. Ready to Start ......................33 7. Access to NVR ......................34 7.1 Search the NVR via Smart Tools ................ 34 7.2 Via WEB ......................35 7.2.1 Log-in ......................35 7.2.2 Live View ....................36 7.3 Via Monitor ....................... 37 www.milesight.com... -
Page 4: Package Contents
Quick Start Guide 1.Package Contents Mini (PoE) NVR: MS-N10090-UT MS-N10090-UNT MS-N1009-UPT Contents Screwdriver Quick Start Guide Power Adaptor Power Adaptor Power Cord HDD Screw www.milesight.com... -
Page 5: Power Adaptor
Pro/PoE 7000 Series Pro 8000 Series Contents Quick Start Guide Mouse Power Cord x 1 (Pro 5000) Power Adaptor x 12 x 16 x 32 HDD Screw HDD Bracket HDD Bracket Screw Mounting Bracket Mounting Bracket Mounting Bracket Mounting Bracket Screw www.milesight.com... -
Page 6: Hardware Overview
Quick Start Guide 2.Hardware Overview Mini NVR: 80mm 120mm 80mm Mini PoE NVR: 115mm 180mm 115mm www.milesight.com... - Page 7 Quick Start Guide Pro/PoE 5000 Series: Pro/PoE 7000 Series: Pro 8000 Series: www.milesight.com...
-
Page 8: Interfaces
Quick Start Guide 3.Interfaces MS-N1009-UT: MS-N1009-UNT: www.milesight.com... - Page 9 Quick Start Guide MS-N1009-UPT: Pro 5000 Series: www.milesight.com...
- Page 10 PoE Port 1/3/5/7 Power Button Alarm Out AC 100-240V PoE Port 2/4/6/8 50-60HZ HDMI Grounding Audio Out Pro 7000 Series: RS-232 Power HDMI Audio In Alarm Out Lock Hole LAN1 AC 100-240V 50-60HZ LAN2 Alarm In Audio Out Grounding www.milesight.com...
- Page 11 Quick Start Guide PoE 7000 Series: RS-232 Alarm Out Audio In PoE Port AC 100-240V HDMI Lock Hole 50-60HZ Power PoE Port 2/4/6/8/10/12/14/16 Grounding Audio Out Alarm In Pro 8000 Series: AC 100-240V 50-60HZ Power Button www.milesight.com...
- Page 12 Quick Start Guide Lock Hole Audio In HDMI 2 HDMI 1 eSATA Alarm Out LAN 1 RS-232 LAN 2 VGA 2 Alarm In Grounding VGA 1 Audio Out www.milesight.com...
-
Page 13: Installation
Quick Start Guide 4. Installation 4.1 Mini (PoE) NVR 1000 Series Installation Step1: Remove the screws at the bottom panel and pull up the casing. Step2: Insert SATA HDD in the slot as required. (Mini NVR) - Page 14 Quick Start Guide (Mini PoE NVR) Note: MS-N1009-UT supports two SATA HDD (2.5”), MS-N1009-UNT and Mini PoE NVR supports one SATA HDD (3.5”). Step3: Secure the HDD with screws. (Mini NVR) www.milesight.com...
- Page 15 Quick Start Guide (Mini PoE NVR) Step4: Put back the casing and tighten the screws. www.milesight.com...
-
Page 16: Pro/Poe Nvr 5000 Series Installation
Quick Start Guide 4.2 Pro/PoE NVR 5000 Series Installation Step1: Using a cross screwdriver to remove the screws at the back panel in an anticlockwise direction. (Pro 5000 Series) (PoE 5000 Series) www.milesight.com... - Page 17 Quick Start Guide Step2: Slide the upper casing to the right first and lift it up. Step3: The internal structure of Pro/PoE 5000 is shown as below. (Pro 5000 Series) www.milesight.com...
- Page 18 Quick Start Guide (PoE 5000 Series) Step4: Hard Disk Installation: Lock the hard disk with the HDD bracket. 6 screws for each hard disk installation. Step5: Secure the HDD brackets with hark disks in the casing. 4 screws for each www.milesight.com...
- Page 19 Quick Start Guide HDD bracket. (Pro 5000 Series) (PoE 5000 Series) Step6: After that, check if all the screws are tightened. Then connect the www.milesight.com...
- Page 20 Quick Start Guide power cable and data cable to each HDD. (Pro 5000 Series) (PoE 5000 Series) Step7: Pull down the upper casing and slide it to the left. www.milesight.com...
- Page 21 Quick Start Guide Step8: Retighten the screws on the back. (Pro 5000 Series) www.milesight.com...
- Page 22 Quick Start Guide (PoE 5000 Series) www.milesight.com...
-
Page 23: Pro/Poe Nvr 7000 Series Installation
Quick Start Guide 4.3 Pro/PoE NVR 7000 Series Installation Step1: Using a cross screwdriver to remove the screws at the back panel in an anticlockwise direction. (Pro 7000 Series) (PoE 7000 Series) www.milesight.com... - Page 24 Quick Start Guide Step2: Slide the upper casing to the right first and lift it up. Step3: The HDD bracket is rotatable and can be taken down by pulling up and rotating one side of it. (Pro 7000 Series) www.milesight.com...
- Page 25 Quick Start Guide (PoE 7000 Series) Step4: To install HDD more conveniently, you can： 1) Remove the bracket. (Pro 7000 Series) www.milesight.com...
- Page 26 Step5: Check if all the 16 screws in HDD bracket are screwed tightly, if not, screw them tightly in an clockwise direction. And fix the bracket with a screw in the middle of bracket. Then connect the power cable and data cable to each HDD. www.milesight.com...
- Page 27 Quick Start Guide (PoE 7000 Series) Step6: Pull down the upper casing and slide it to the left. Step7: Retighten the screws on the back. www.milesight.com...
-
Page 28: Pro Nvr 8000 Series Installation
Quick Start Guide (Pro 7000 Series) (PoE 7000 Series) 4.4 Pro NVR 8000 Series Installation Step1: Using a cross screwdriver to remove the screws at the back panel in an www.milesight.com... - Page 29 Step2: Slide the upper casing to the right first and lift it up. Step3: Using the screwdriver to remove the screw in the middle of HDD bracket in an anticlockwise direction (Pro 7000 has only one HDD bracket and www.milesight.com...
- Page 30 Step4: The HDD bracket is rotatable and can be taken down by pulling up and rotating one side of it. Step5: Secure the HDD with 4 screws. Don’t screw tight and leave about 4mm distance at the side of each screw nut. As the enlarged drawing shows: www.milesight.com...
- Page 31 Step6: After securing each HDD with 4 screws, stuck the side with screw nuts in the bracket’s slots and then slide down to fix the HDD in the bracket. Screw tight with screwdriver. Step7: Repeat the above steps to install HDD in the bracket. Remember to check if you have screwed tight. www.milesight.com...
- Page 32 Step8: Secure the 16 screws in HDD and fix the bracket with a screw in the middle of it. Then connect the power cable and data cable to each HDD. Step9: Pull down the upper casing and slide it to the left. www.milesight.com...
- Page 33 Quick Start Guide Step10: Retighten the screws on the back. (Pro 8000 Series) www.milesight.com...
-
Page 34: Connection Overview
Quick Start Guide 5. Connection Overview Connect different devices to the interfaces of NVR, taking Mini (PoE) NVR and PoE 7000 NVR for example: (Mini NVR) (Mini PoE NVR) www.milesight.com... - Page 35 Quick Start Guide (PoE 7000 Series) www.milesight.com...
-
Page 36: Ready To Start
NVR and PoE 7000 NVR for example: (Mini NVR Series) (PoE 7000 Series) Note: Milesight 4-CH/8-CH/16-CH Plug and Play NVR features 4/8/16 independent PoE Ports. The software can automatically detect and configure the network cameras just after being plugged the cable, greatly eliminating the need for much time and expertise, and achieving a virtually hassle-free installation process. -
Page 37: Access To Nvr
If the IP address of the NVR is unknown, please use the Smart Tools to search the IP address. Smart Tools can automatically detect online Milesight NVRs connected in the LAN. You can get the IP address of the NVR by searching in the Tools. -
Page 38: Via Web
. After that, the log-in page will pop up; Step3: (You can choose the language before logging in) Input the correct user name and password. Click on the Log-in button to enter the Live View page. (Default user name and password of NVR are “admin” and “ms1234”.) www.milesight.com... -
Page 39: Live View
After logging in the NVR, you can add cameras to the NVR through the camera settings. After adding cameras, please click on the Live View button to get the preview. (Default user name and password of network camera are “admin” and “ms1234”.) Details are shown as follows: www.milesight.com... -
Page 40: Via Monitor
There is another way to access to NVR which you can use the HDMI cable to let the NVR combine with monitor. (Default user name and password of NVR are “admin” and “ms1234”.) After running the NVR, you can do some configurations according to the www.milesight.com... - Page 41 Quick Start Guide wizard. Details are shown as follows: Password Modifying Time Setting Network Setting www.milesight.com...
- Page 42 Quick Start Guide Hard Disk Setup www.milesight.com...
- Page 43 Quick Start Guide Camera Adding Record Setting Also you can skip the wizard to login directly. www.milesight.com...
- Page 44 Quick Start Guide Then add cameras in Camera interface. Details are shown as follows: Camera Management Camera Search www.milesight.com...
- Page 45 Quick Start Guide After adding cameras successfully, you can back to the Live View to preview. www.milesight.com...
- Page 46 Quick Start Guide NVR Series Thank you for choosing Milesight Product © 2018 Milesight Technology Co., Ltd. www.milesight.com...
