Quick Start Guide
V 4.08
www.milesight.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NVR Series and is the answer not in the manual?

Questions and answers

Related Manuals for Milesight NVR Series

Summary of Contents for Milesight NVR Series

  • Page 1 Quick Start Guide V 4.08 www.milesight.com...

  • Page 3: Table Of Contents

    6. Ready to Start ......................37 7.Access to NVR ......................38 7.1 Search the NVR via Smart Tools ................ 38 7.2 Via WEB ......................40 7.2.1 Log-in ......................40 7.2.2 Live View ....................43 7.3 Via Monitor ....................45 www.milesight.com...

  • Page 4: Package Contents

    Quick Start Guide 1.Package Contents Mini (PoE) NVR: MS-N1004-UC/UPC MS-N1009-UT MS-N1009-UNT MS-N1009-UPT Contents Quick Start Guide Warranty Card (MS-N1004-UC) Power Adaptor (MS-N1004-UPC) Power Adaptor (MS-N1004-UPC) Power Cord X 10 HDD Screw www.milesight.com...
  • Page 5 Pro 8000 Series Contents Quick Start Guide Warranty Card Mouse Power Cord x 1 (Pro 5000 Series) Power Adaptor x 12 x 20 x 36 HDD Screw HDD Bracket HDD Bracket Screw Mounting Bracket Mounting Bracket Mounting Bracket Mounting Bracket Screw www.milesight.com...
  • Page 6 Quick Start Guide SATA Cable x 1 (Pro 7000 Series) HDD Power Cable x 2 (MS-N7032-UPH) Terminal www.milesight.com...

  • Page 7: Hardware Overview

    Quick Start Guide 2.Hardware Overview Mini NVR Series: MS-N1004-UC: MS-N1009-UT: www.milesight.com...
  • Page 8 Quick Start Guide MS-N1009-UNT: Mini PoE NVR Series: MS-N1004-UPC: MS-N1009-UPT: www.milesight.com...
  • Page 9 Quick Start Guide Pro/PoE 5000 Series: Pro/PoE 7000 Series: MS-N7016-UH/MS-N7032-UH/MS-N7016-UPH: MS-N7032-UPH: www.milesight.com...
  • Page 10 Quick Start Guide Pro 8000 Series: www.milesight.com...

  • Page 11: Interfaces

    Quick Start Guide 3. Interfaces MS-N1004-UC: MS-N1004-UPC: MS-N1009-UT: www.milesight.com...
  • Page 12 Quick Start Guide MS-N1009-UNT: MS-N1009-UPT: MS-N5008-UT/MS-N5016-UT: www.milesight.com...
  • Page 13 Quick Start Guide MS-N5008-UPT: MS-N5016-UPT: MS-N7016-UH/MS-N7032-UH: www.milesight.com...
  • Page 14 Quick Start Guide MS-N7016-UPH: MS-N7032-UPH: MS-N8032-UH/MS-N8064-UH: www.milesight.com...
  • Page 15 Quick Start Guide www.milesight.com...

  • Page 16: Installation

    Quick Start Guide 4.Installation 4.1 Mini (PoE) NVR 1000 Series Installation Step1: Remove the screws at the bottom panel and pull up the casing. (MS-N1004-UPC/MS-N1004-UC) (MS-N1009-UPT/MS-N1009-UT/MS-N1009-UNT)
  • Page 17 Quick Start Guide Step2: Insert SATA HDD in the slot as required. (MS-N1004-UPC/MS-N1004-UC) (MS-N1009-UPT/MS-N1009-UNT) (MS-N1009-UT) www.milesight.com...
  • Page 18 Quick Start Guide Note: MS-N1009-UT supports two SATA HDD (2.5”), MS-N1004-UPC/UC and MS-N1009-UNT/UPT support one SATA HDD (3.5”). Step3: Secure the HDD with screws. (MS-N1004-UPC/MS-N1004-UC) (MS-N1009-UPT/MS-N1009-UNT) (MS-N1009-UT) www.milesight.com...
  • Page 19 Quick Start Guide Step4: Put back the casing and tighten the screws. (MS-N1004-UPC/MS-N1004-UC) (MS-N1009-UPT/MS-N1009-UT/MS-N1009-UNT) www.milesight.com...

  • Page 20: Pro/Poe Nvr 5000 Series Installation

    Quick Start Guide 4.2 Pro/PoE NVR 5000 Series Installation Step1: Using a cross screwdriver to remove the screws at the rear panel in an anticlockwise direction. (Pro 5000 Series) (PoE 5000 Series) www.milesight.com...
  • Page 21 Quick Start Guide Step2: Slide the upper casing to the right first and lift it up. Step3: The internal structure of Pro/PoE 5000 Series is shown as below. (Pro 5000 Series) www.milesight.com...
  • Page 22 Quick Start Guide (PoE 5000 Series) Step4: Hard Disk Installation: Lock the hard disk with the HDD bracket. 6 screws for each hard disk installation. www.milesight.com...
  • Page 23 Quick Start Guide Step5: Secure the HDD brackets with hark disks in the casing. 4 screws for each HDD bracket. (Pro 5000 Series) (PoE 5000 Series) www.milesight.com...
  • Page 24 Quick Start Guide Step6: After that, check if all the screws are tightened. Then connect the power cable and data cable to each HDD. (Pro 5000 Series) (PoE 5000 Series) www.milesight.com...
  • Page 25 Quick Start Guide Step7: Pull down the upper casing and slide it to the left. Step8: Retighten the screws on the rear panel. (Pro 5000 Series) www.milesight.com...

  • Page 26: Pro/Poe Nvr 7000 Series Installation

    Quick Start Guide (PoE 5000 Series) 4.3 Pro/PoE NVR 7000 Series Installation Step1: Using a cross screwdriver to remove the screws at the rear panel in an anticlockwise direction. (Pro 7000 Series) www.milesight.com...
  • Page 27 Quick Start Guide (PoE 7000 Series) Step2: Slide the upper casing to the right first and lift it up. Step3: The HDD bracket is rotatable and can be taken down by pulling up and rotating one side of it. www.milesight.com...
  • Page 28 Quick Start Guide (Pro 7000 Series) (PoE 7000 Series) Step4: To install HDD more conveniently, you can： 1) Remove the bracket. www.milesight.com...
  • Page 29 Quick Start Guide (Pro 7000 Series) 2) Install the HDD on the bracket. 3) After securing the HDD on bracket, insert the bracket back to the NVR. www.milesight.com...
  • Page 30 Step5: Check if all the 16 screws in HDD bracket are screwed tightly, if not, screw them tightly in an clockwise direction. And fix the bracket with a screw in the middle of bracket. Then connect the power cable and data cable to each HDD. (PoE 7000 Series) www.milesight.com...
  • Page 31 Quick Start Guide Step6: Pull down the upper casing and slide it to the left. Step7: Retighten the screws on the rear cover. (Pro 7000 Series) www.milesight.com...

  • Page 32: Pro Nvr 8000 Series Installation

    Quick Start Guide (PoE 7000 Series) 4.4 Pro NVR 8000 Series Installation Step1: Using a cross screwdriver to remove the screws at the rear panel in an anticlockwise direction. (Pro 8000 Series) www.milesight.com...
  • Page 33 (Pro 7000 has only one HDD bracket and Pro 8000 has two, while the installation steps are the same). Step4: The HDD bracket is rotatable and can be taken down by pulling up and rotating one side of it. www.milesight.com...
  • Page 34 As the enlarged drawing shows: Step6: After securing each HDD with 4 screws, stuck the side with screw nuts in the bracket’s slots and then slide down to fix the HDD in the bracket. Screw www.milesight.com...
  • Page 35 Step7: Repeat the above steps to install HDD in the bracket. Remember to check if you have screwed tight. Step8: Secure the 16 screws in HDD and fix the bracket with a screw in the middle of it. Then connect the power cable and data cable to each HDD. www.milesight.com...
  • Page 36 Quick Start Guide Step9: Pull down the upper casing and slide it to the left. Step10: Retighten the screws on the rear panel. www.milesight.com...
  • Page 37 Quick Start Guide (Pro 8000 Series) www.milesight.com...

  • Page 38: Connection Overview

    Quick Start Guide 5.Connection Overview Connect different devices to the interfaces of NVR, taking Mini (PoE) NVR Series (MS-N1009-UT & MS-N1009-UPT) and PoE 7000 NVR Series (MS-N7016-UPH) for example: (Mini NVR Series (MS-N1009-UT)) (Mini PoE NVR Series (MS-N1009-UPT)) www.milesight.com...
  • Page 39 Quick Start Guide (PoE 7000 Series (MS-N7016-UPH)) www.milesight.com...

  • Page 40: Ready To Start

    Quick Start Guide 6. Ready to Start Press the power button, the LED Indicator will light steadily when it is connected to a power source, taking Mini NVR Series (MS-N1009-UT) and PoE 7000 NVR Series (MS-N7016-UPH) for example: (Mini NVR Series (MS-N1009-UT))

  • Page 41: Access To Nvr

    If the IP address of the NVR is unknown, please use the Smart Tools to search the IP address. Smart Tools can automatically detect online Milesight NVRs connected in the LAN. You can get the IP address of the NVR by searching in the Tools.
  • Page 42 Click ‘Save’ and it will show that the activation was successful. Note: (1) Password must be 8 to 32 characters long, contain at least one number and one letter. (2) You need to upgrade Smart Tools version to V2.4.0.1 or above to activate the NVR. www.milesight.com...

  • Page 43: Via Web

    If the network segment of the computer and that of the NVR are different, you need to change the IP address of computer to 192.168.5.0 segment, here are two ways as below: Start Control Panel Network and Internet Connection Network www.milesight.com...
  • Page 44 Click “Advanced”, and then click “IP settings”  “IP address”  “Add”. In the pop-up window, enter an IP address that in the same segment with Milesight network camera ( e.g. 192.168.5.61, but please note that this IP address shall not conflict with the IP address on the existing network);...
  • Page 45 And you can also set three security questions for your device after activation. Then, you can log in the device with You can log in to the NVR with the username(admin) and a custom password. www.milesight.com...

  • Page 46: Live View

    7.2.2 Live View After logging in the NVR, you can add cameras to the NVR through the camera settings. After adding cameras, please click on the Live View button to get the preview. Details are shown as follows: www.milesight.com...
  • Page 47 Quick Start Guide Note: About other configurations, you can refer to the user manual of NVR. www.milesight.com...

  • Page 48: Via Monitor

    Details are shown as follows: If the NVR’s firmware version is V7x.9.0.3 or above, you need to set the password to activate the NVR when using it for the first time. You can also set three security questions after activating the NVR. www.milesight.com...
  • Page 49 2) You can click the “forget password” in login page to reset the password by answering three security questions when you forget the password. 3) If the NVR’s firmware version is lower than V7x.9.0.3, you can directly log in the NVR with default user name(admin) and default password(ms1234) Password Modifying www.milesight.com...
  • Page 50 Quick Start Guide Time Setting Network Setting Hard Disk Setup www.milesight.com...
  • Page 51 Quick Start Guide Click RAID to set up RAID for selected disk. RAID is available for Pro/PoE 7000 Series and Pro 8000 Series. Note: RAID will be available after it was enabled and the device rebooted. Camera Adding www.milesight.com...
  • Page 52 Quick Start Guide Record Setting Also you can skip the wizard to login directly. www.milesight.com...
  • Page 53 Quick Start Guide Then add cameras in Camera interface. Details are shown as follows: Camera Management Camera Search 1. Select IP Range, NIC and Protocol, which includes ALL, ONVIF and MSSP. www.milesight.com...
  • Page 54 4. Check checkbox to batch adding the network cameras if they are with the same password, you can choose TCP or UDP transport protocol for it. Click OK to finish batch adding After adding cameras successfully, you can back to the Live View to preview. www.milesight.com...
  • Page 55 Quick Start Guide NVR Series Thank you for choosing Milesight Product © 2019 Milesight Technology Co., Ltd. www.milesight.com...
