C 5
H A P T E R
Firmware Upgrade
The Ethernet Cradle allows for firmware upgrade over the Ethernet connection or the
terminal. We suggest that you first download the kernel program (Kernel.SHX), and then
the user program (User.SHX).
Warning:

5.1 Over Ethernet Connection

1. Connect a Cat. 5 crossover cable from the cradle to the computer.
When in "Auto-detect" mode, you must disconnect the RS-232 connection or use
command
2. Connect the power supply cord from the Ethernet Cradle to a nearby outlet.
If you forgot the current IP of the cradle, you will need to press the "IP Reset" switch
when connecting the power cord to the cradle.
This toggle switch is right next to the RJ-45 port at the back panel of the Ethernet
Cradle. The IP address of the cradle will be reset to 192.168.1.1 (default) temporarily
for configurations.
Note: This default IP is used for accessing the Main Menu and will not override the
3. Run CipherLab utility on your computer and connect to the cradle via port 3000 for
updating firmware.
DO NOT upgrade firmware unless the version of new firmware is greater
than that of your cradle. For information of the current firmware version,
check the Main Menu for configuration.
to switch to Ethernet.
current IP you set.
UDP_Load.exe
Ethernet Cradle as a UDP server
Current IP or default 192.168.1.1
Port: 3000
35
cradle
