Chapter 2 - Configuring The Ethernet Cradle - CipherLab 8001 User Manual

C 2
H A P T E R
Configuring the Ethernet Cradle
The Ethernet Cradle can be configured through the provided Main Menu over Ethernet
connection. You can configure related networking parameters, as well as working mode or
type over the networks.
1. Connect a Cat. 5 crossover cable from the cradle to the computer
2. Connect the power supply cord from the Ethernet cradle to a nearby outlet.
If you forgot the current IP of the cradle, you will need to press the "IP Reset" switch
when connecting the power cord to the cradle.
This toggle switch is right next to the RJ-45 port at the back panel of the Ethernet
Cradle. The IP address of the cradle will be reset to 192.168.1.1 (default) temporarily
for configuration.
Note: This default IP is used for accessing the Main Menu and will not override the
3. Run a telnet client program on your computer and connect to the cradle via port 8000.
4. The Main Menu is displayed for configuring the cradle. Proceed with related settings
for a specific working mode.
current IP.
Ethernet Cradle as a telnet server
Current IP or default 192.168.1.1
Port: 8000
Default Settings:
Working mode set to Modem Mode
DHCP enabled
15
