1.8 Set-up Connection
No matter which connection or mode is in use, you can always use
switch between RS-232 and Ethernet when both cables are connected.
1.8.1 Auto-Detect Mode
When a connection via RS-232 is desired, simply connect the RS-232 cable.
When Ethernet connection is desired, simply connect the Cat. 5 cable.
If you connect both cables, the default connection is via RS-232. That is, the RS-232
connection will override Ethernet connection.
1.8.2 LAN Mode (8500 Only)
If the 8500 Ethernet Cradle is set with "LAN" enabled, only the Ethernet connection is
allowed.
Note: To enable "Auto-detect", toggle the DIP switch to your left on the 8500 Ethernet
Cradle; and vice versa.
Chapter 1 Introducing the Ethernet Cradle
13
cradle commands
to
