Echo Settings - CipherLab 8001 User Manual

24 8001/8300/8500 Ethernet Cradle User Guide

2.3.3 Echo Settings

Select "3" from the Setup Connection menu and press [Enter]. The following submenu will
be displayed.
Note: The cradle must be configured as a TCP server or UDP server.
Client Echo
Echo String
By default, this setting is disabled.
To enable Echo, type "1 1" and press [Enter].
When Echo is enabled, the cradle will send a predefined string to a remote device
(client) as soon as the connection is established. The client will then start to
communicate with the cradle after it receives the Echo String.
By default, the Echo String is "Connection OK!"
You can specify a new string, which allows 31 characters at most.
Type "2 NewString" and press [Enter].
