SPECIFICATIONS

ELECTROMAGNETIC COMPATIBILITY TABLES

Guidance and manufacturer's declaration – electromagnetic emissions
The Intelect Transport Combo is intended for use in the electromagnetic environment specified below. The
customer or the user of the Intelect Transport Combo should assure that it is used in such an environment.
Emission tests
RF emissions Group 1
CISPR 11
RF emissions Class A
CISPR 11
Harmonic emissions Class A
IEC 61000-3-2
Voltage fluctuations Complies
IEC 61000-3-3
Compliance Electromagnetic environment -
guidance
The Intelect Transport Combo uses
RF energy only for its internal
function. Therefore, its RF
emissions are very low and are not
likely to cause any interference in
nearby electronic equipment.
The Intelect Transport Combo is
suitable for use in all
establishments, including
domestic establishments and
those directly connected to the
public low-voltage power supply
network that supplies buildings
used for domestic purposes.
Guidance and manufacturer's declaration – electromagnetic immunity
The Intelect Transport Combo is intended for use in the electromagnetic environment specified below. The
customer or the user of the Intelect Transport Combo should assure that it is used in such an environment.
Immunity test IEC 60601
test level
Electrostatic discharge ±6kV contact
(ESD)
±8kV air
IEC 61000-4-2
Electrical fast ±2kV for power supply
transient/burst lines
IEC 61000-4-4 ±1kV for input/output
lines
Surge ±1kV differential mode
IEC 61000-4-5 ±2kV common mode
Voltage dips, short <5% U
T
interruptions and voltage (>95% dip in U
variations on power cycle
supply input lines
40% U
T
IEC 61000-4-11 (60% dip in U
cycles
70% U
T
(30% dip in U
cycles
<5% U
T
(>95% dip in U
Power frequency 3 V/m
(50/60Hz) magnetic field
IEC 61000-4-8
NOTE U is the a.c mains voltage prior to application of the test level.
T
29
Intelect® Transport Combo
Compliance level Electromagnetic
environment - guidance
±6kV contact Floors should be wood,
concrete or ceramic tile. If
±8kV air floors are covered with
synthetic material, the
relative humidity should
be at least 30%.
±2kV for power supply Mains power quality
lines should be that of a typical
commercial or hospital
±1kV for input/output environment.
lines
±1kV differential mode Mains power quality
should be that of a typical
±2kV common mode commercial or hospital
environment.
<5% U Mains power quality
T
) for 0.5 (>95% dip in U ) for 0.5 should be that of a typical
T T
cycle commercial or hospital
environment. If the user
40% U of the Intelect Transport
T
) for 5 (60% dip in U ) for 5 Combo requires
T T
cycles continued operation
during power mains
70% U interruptions, it is
T
) for 25 (30% dip in U ) for 25 recommended that the
T T
cycles Intelect Transport Combo
be powered from an
<5% U uninterrupted power
T
) for 5 sec (>95% dip in U ) for 5 sec supply or a battery.
T T
3 V/m Power frequency
magnetic fields should be
at levels characteristic of
a typical location in a
typical commercial or
hospital environment.
