OVERVIEW
Intelect® Transport Combo

Description of Ultrasonic Field

The spatial distribution of the radiated field is essentially a collimated beam of the ultrasonic energy having a cross-sectional area of 8.5 cm 2
2
for the 10 cm sound head when measured at a point 5 mm from the transducer face.
2
The energy distribution within the radiated field is 3.0 W/cm peak and it takes a generally conic shape, having decreasing intensity at
progressively increasing distance from the face of the transducer. This field distribution applies for the radiation emitted into the equivalent
of an infinite medium of distilled, degassed water at 86° F and with the line voltage variations in the range of 10% of the rated line voltage.
19
