NOMENCLATURE
Sound Head
The aluminum face of the applicator that contacts the patient's skin. It covers a transducer mechanism that converts electrical
energy to mechanical energy in the form of a vibrating crystal.
LED Indicator (Output Power)
When illuminated, this green light signifies that ultrasound energy is being distributed through the applicator.
Applicator
The hand held assembly used to deliver ultrasonic energy. The applicator includes the sound head, transducer, and related
electronics.
Accessory Panel
The Accessory Panel serves as a port of connection for the electrodes and ultrasound applicator.
Channel 1 Lead Wire Connection
This port serves as the connection point between the unit and the Channel 1 Lead Wire.
Channel 2 Lead Wire Connection
This port serves as the connection point between the unit and the Channel 2 Lead Wire.
Ultrasound Applicator Connection
This port serves as the connection point between the unit and the ultrasound applicator.
START
Select Start to begin a treatment session.
Parameter Display/Enter
Select this button to display the parameters of the waveform during treatment. Also, this button is used to accept the highlighted
selection.
INTENSITY
Use the up or down arrow on the INTENSITY button to increase or decrease output power.
