SPECIFICATIONS

SOUND HEAD SPECIFICATIONS

1 cm 2 Sound Head
Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.3 MHz (all +/- 5%)
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0 watt to 2 watts
Effective Radiating Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0.7 cm
Maximum beam non-uniformity ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.0:1
Beam Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Collimating
2
2 cm Sound Head
Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 MHz, 3.3 MHz (all +/- 5%)
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0 watt to 4 watts
Effective Radiating Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.4 cm
Maximum beam non-uniformity ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.0:1
Beam Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Collimating
Head Warming Feature
The Head Warming feature of an Intelect Transport Combo
utilizes Ultrasound output resulting in warming of the Sound
Head to increase patient comfort.
With Head Warming enabled, ultrasound is emitted without
pressing the Start button. The Applicator LED will not illuminate
during the Head Warming period. US Channel will indicate "Head
Warming".
Output . . . . . . . . . . . . . . . . . . . . . . .0 - 50% Cycling of maximum power
Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.3 MHz
Sound Head Temperature . . . . . . . . 85 °F - 110 °F (29.4 °C - 43.3 °C)
5 cm 2 Sound Head
Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 MHz, 3.3 MHz (all +/- 5%)
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 watt to 10 watts
2 – 1 cm 2 Effective Radiating Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3.5 cm
Maximum beam non-uniformity ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.0:1
Beam Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Collimating
10 cm 2 Sound Head
Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 MHz, 3.3 MHz (all +/- 5%)
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 MHz: 0 watt to 20 watts
2 – 2 cm 2
(0 to 15 watts if 2 channels of electrotherapy are used simultaneously)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.3 MHz: 0 watt to 10 watts
Effective Radiating Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.8 cm
Maximum beam non-uniformity ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.0:1
Beam Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Collimating
Do not apply the Ultrasound Applicator to the patient during the Head
Warming period. Applicator must remain in Applicator Hook duing the
Head Warming period.
28
Intelect® Transport Combo
2 – 5 cm 2
2 – 10 cm 2
