SPECIFICATIONS

ULTRASOUND TECHNICAL SPECIFICATIONS

Sound Heads . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 cm
Duty Cycles
Pulsed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10%, 20%, and 50%
Continuous . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .100%
Pulse Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 Hz
Output accuracy . . . . . . . . . . . . . . . . . . +/- 20% above 10% of maximum
Amplitude . . . . . . . . . . . . . . . . . . . . . .0 to 2.5 W/cm
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0-3 W/cm
Temporal Peak to Average Ratios
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2:1, +/- 20%, for 50% Duty Cycle
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5:1, +/- 20%, for 20% Duty Cycle
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9:1, +/- 20%, for 10% Duty Cycle
Modulation Modulation
Frequency
(Hz)
100
2 2 2
, 2 cm , 5 cm , 10 cm
2
in Continuous mode,
2 in pulsed modes
Pulse Duration
On Times (ms)
Period
10% 20%
(ms)
10.000 1.000 2.000
2
Maximum Treatment Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30 Minutes
Output
Pulsed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 MHz or 3.3 MHz signal,
modulated 100% by the 100 Hz rectangular wave with the selected
Continuous . . . . . . . . . . . . . . . . . . . . . . . . . . 1 MHz or 3.3 MHz, nominal signal
that is activated as long as the timer is operating.
Timer Accuracy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .+/-0.2 Minutes
50% 100% 10%
5.000 Continuous 9.000
27
Intelect® Transport Combo
Off Times (ms)
20% 50% 100%
8.000 5.000 0.000
Duty Cycle.
