LANCOM 1722 VoIP – LANCOM 1723 VoIP – LANCOM 1724 VoIP – LANCOM 1823 VoIP
Please observe that only the MAC addresses of the WLAN cards at the

other end of the connections are to be entered here! Not the access
point's own MAC address, and not the MAC addresses from any other
interfaces that may be present in the access points.
You will find the WLAN MAC address on a sticker located under each of the
antenna connectors. Only use the string that is marked as the "WLAN MAC"
or "MAC-ID". The other addresses that may be found are not the WLAN MAC
address but the LAN MAC address.
Connecting point- to-point remote stations by station name
When configuring point-to-point connections, an alternative to the MAC
addresses is to use the station names of the remote stations.
First of all the station name is entered into the point-to-point settings in the
Wireless Routers or Access Points.
LANconfig: Wireless LAN
Point to point
WEBconfig: Setup
For models with multiple WLAN modules, the station name can be

entered separately for each physical WLAN interface.
In the point-to-point configuration, select the identification by station name
and enter the name of the corresponding station.
Chapter 8: Advanced wireless LAN configuration
General Physical WLAN settings
Interfaces WLAN interpoint settings
93
