Analog interface

6-pin RJ11 socket
14.2.6

Ethernet interface 10/100Base-TX

8-pin RJ45 socket, corresponding to ISO 8877, EN 60603-7
Connector
Connector
Pin
1
2
3
4
5
6
7
8
Chapter 14: Appendix
Pin IAE
1
2
3
4
5
6
IAE
T+
T-
R+
PoE/G
PoE/G
R-
PoE/-48 V
PoE/-48 V
–
–
a
b
–
–
