LANCOM 1722 VoIP – LANCOM 1723 VoIP – LANCOM 1724 VoIP – LANCOM 1823 VoIP
Chapter 2: Installation
Orange
Orange /
red
Red
Connection status at the analog exchange line:
Analog (⌧)
Off
Green
Orange
Orange
Orange /
red
Red
ETH LAN connector status in the integrated switch:
Off
Green
Green
Red
WLAN link Provides information about the WLAN connections via the internal WLAN
modules. The following can be displayed for WLAN link:
Off
Green
Green
40
On (permanently) Handset off-hook.
Blinking Hardware error
On (permanently) Calibration interrupted or temporary error (e.g. in case of
shutdown due to temperature)
Interface switched off.
On (permanently) Analog exchange line is switched on.
Blinking Call being established from exchange towards LANCOM.
The line is "ringing" at the LANCOM.
On (permanently) The LANCOM has an analog connection—the handset of
an analog device is off-hook.
Blinking Hardware error
On (permanently) No line voltage available (cable may be interrupted)
No networking device attached
On (perma- Connection to network device operational, not data traffic
nently)
Flickering Data traffic
Flickering Data packet collision
No WLAN network defined or WLAN module deacti-
vated. The WLAN module is not transmitting beacons.
At least one WLAN network is defined and WLAN mod-
ule activated. The WLAN module is transmitting bea-
cons.
Inverse flashing Number of flashes = number of connected WLAN sta-
tions and P2P wireless connections, followed by a pause
(default).
Alternatively, the frequency of the flashed can indicate
the input sensitivity.
