LANCOM 1722 VoIP – LANCOM 1723 VoIP – LANCOM 1724 VoIP – LANCOM 1823 VoIP
The display of signal quality on the LEDs must be activated for the wireless
LAN interface (LANconfig: Wireless LAN
settings Operation). The faster the LED blinks the better the connection
(a blinking frequency of 1 Hz represents a signal quality of 10 dB, double the
frequency indicates that the signal strength is twice as high).
In LANmonitor the connection quality display is opened with the context
menu. Right-clicking with the mouse on 'Point-to-point' activates the option
'Adjusting Point-to-Point WLAN Antennas...'
The 'Point-to-point' entry is only visible in the LANmonitor if the mon-

itored device has at least one base station defined as a remote site for
a P2P connection (LANconfig: Wireless LAN
WLAN settings
In the dialog for setting up point-to-point connections, LANmonitor prompts
for the information required to establish the P2P connection:
Is the P2P connection configured at both ends (remote base station
defined with MAC address or station name)?
Is the point-to-point mode of operation activated?
Which access point is to be monitored? All of the base stations defined as
P2P remote sites in the device concerned can be selected here.
Chapter 8: Advanced wireless LAN configuration
General
Point- to-Point).
Physical WLAN
General Physical
89
