10. Install the retract servo.
Metal connector
11. Finish the nose air retract.

INSTALLING THE ELEVATOR servo

1. Remove the covering from over the precut servo
box on the elecator.
2. Install two servo to the elevator as shown.
3. Repeat step 1 - step 6 from the ailleron to the
elevator servo.
Remove the covering
29
30
Servo lead
31
7
SUPER CONSTELLATION
32
33
34
35
