6. System Setup and Operation

How to Realize the Text Overlay Setting

How to Realize the Text Overlay Setting
1. Push the MENU button, turn the knob, choose [TEXT OVERLAY] and
enter [TEXT OVERLAY] menu items, push the knob to confirm.
2. Turn the knob, choose ―TEXT OVERLAY‖ option, choose ON, and
enable the TEXT OVERLAY function.
3. Push the MENU button, return to [TEXT OVERLAY], turn the knob,
OLED screen displays menu options, select 13 modes in PRESET, or
select BLEND MODE, which includes two modes:
Mode 1: Graphic content locate at the top and is non-transparent,
background transparency is controlled by double-image transparency;
Mode 2: Graphic content is controlled by double-image transparency,
the background is completely transparent.
Rotate the knob and choose the mode.
4. Push the MENU button, return to [TEXT OVERLAY], turn the knob,
choose ABOVE/BELOW to select the layer position for IMAGE B.
5. Push the MENU button, return to [TEXT OVERLAY], turn the knob,
choose BLEND LEVEL, and set the image display transparency,
the regulating range is among 0 to 16.
6. Push the MENU button, return to [TEXT OVERLAY], turn the knob,
choose the color value:
RED: The value range of color RED that to be set, regulating range
VSP 198CVS
ADJUST
->TEXT OVERLAY
SYSTEM
LANGUAGE/语言
*TEXT OVERLAY
PRESET
BLEND MODE
BLEND LEVEL
User Manual
>>
>>
>>
ENG
ON
USER MODE
MODE1
0
99
