5. Communication Software Guideline
Software Operation
mode directly with quick preset layout button as following.

Aspect Ratio Toolbar

Users can select 4:3 , 16:9 or Normal in the pull-down options.
Note
Same as MENU
RATIO.

Signal Input Toolbar

The white area displays the name of input interface when the mouse is
over the interface image on the left. The green pane means current
selected interface.
When user selects a dual channel mode, select any channel image, click
on the toolbar interface the ICONS for the channel selection input interface,
i.e.: SDI, Composite1, Composite2, Composite3, S - Video, DVI, YPbPr,
VGA, green toolbar says it has chosen the current interface for channel 1
input interface, the default last single channel chosen interface for channel
2 input interface, the currently selected channel will be shown on the right
side of the source.
VSP 198CVS
ADJUST ASPECT
User Manual 69
